System specifications
Table 6 System specifications of Router 3032
Item
Port
Processor
SDRAM
Flash Memory
Maximum power consumption
Power supply (external)
Dimensions (WxHxD)
Weight
Operating temperature
operating humidity
LEDs
There are eight LEDs on 3032 cover. The following table explains their meaning.
Table 7 LEDs of Router 3032
LED
LAN0/LAN1/LAN2/LAN3
ON means that link has been set up.
ADSL ACT
Blinking means that data is being sent from or
received at the interface.
OFF means ADSL is inactive.
Blinking means the interface is being trained.
Blinking means that the system is properly
working.
PWR
ON means that power is being supplied.
3032
descrip
tion
1 console port
1 ADSl over ISDN (ADSL Annex B)
Four 10/00M Ethernet ports
MPC859 50 Mhz
64MB
8MB
12W
input rated voltage: 100-240V a.c., 50/60Hz
Maximum tolerance: 90-264V a.c., 50/60Hz
Current:0.5A~1A
Output Voltage: 12V d.c.
Current: 4A
300mm (11.81in) X 1800mm (7.1in) X 45mm
(1.77in) (Maximum dimensions, which are the
highest arc points of the plastic panel.)
1kg
0 to 40*C
10 to 90% (noncondensing)
Description
OFF means that link is not set up.
Blinking means that data is being sent from
or received at the interface.
OFF means that no data is being sent from
or received at the interface.
ADSL LNK
ON means ADSL is active.
SYS
Always ON or OFF means that the system is
incorrectly working
OFF means that power is not being
supplied.
Router 3032 15
