Ethernet Port

Table 7 lists attributes of the Ethernet port.
Table 7 Attributes of the Fast Ethernet Port
Attribute Description
Connector RJ-45
Frame format Ethernet_II
Ethernet_SNAP
IEEE 802.2
IEEE 802.3
Operating mode 10/100 Mbps autosensing
Full duplex/half duplex
Network protocol IP (Internet Protocol)
Novell IPX (Internet Packet Exchange)
Synchronous/Asynchronous Serial Port
Table 8 lists attributes of the serial port.
Table 8 Attributes of the Serial Port
Description
Attribute Synchronous
Connector DB50
Port standard and V.24
operating mode (EIA/TIA-23
2)
DTE, DCE
Minimum baud 1200
rate (bps)
Maximum baud 64 k
rate (bps)
Services DDN leased line
Terminal access
Backup
Protocols PPP
MP
LAPB (Link Access Protocol-Balanced)
HDLC (High-level Data Link Control)
SDLC (Synchronous Data Link Control)
X.25
Frame Relay
The Router 3013 and Router 3015 offer ISDN BRI support. The Router 3013 has an
ISDN BRI S/T port and the Router 3015 has an ISDN BRI U port.
Figure 3 illustrates the Router 3013 and Router 3015 routers.
V.35 EIA/TIA-449, X.21 and
EIA-530
DTE, DCE DTE DCE
1200 1200 1200
2.048 M 2.048 M 2.048 M
Asynchronous
V.24 (EIA/TIA-232)
300
115.2 K
Modem dial-up
Backup
PPP
SLIP
MP
