Port Attributes; Console Port - 3Com Router 3012 Installation Manual

Table 4 Router 3012 LEDs (continued)
LED
SERIAL1
AUX
SYSTEM

Port Attributes

The Router 3012 provides a console port, an AUX port, a 10/100M Ethernet port
and a synchronous/asynchronous serial port. The attributes of these ports are
described in the following sections.

Console Port

Table 5 lists attributes of the console port.
Table 5 Attributes of the Console Port
Attribute
Connector
Port standard
Baud rate
Services
AUX Port
Table 6 lists attributes of the AUX port.
Table 6 Attributes of the AUX Port
Attribute
Connector
Port standard
Baud rate
Services
Protocols
Description
Off — The link is not connected.
Green — The link is connected.
Flashing green — Data is being transmitted over serial port 1.
Off — The link is not connected.
Green — The link is connected.
Flashing green — Data is being transmitted over the AUX port.
Flashing green — The system is operating normally.
Always green or off — The system is not operating normally.
Description
RJ-45
Asynchronous EIA/TIA-232
9.6 to 115.2 kbps (the default is 9.6 kbps)
Connects with character terminal
Connects with the serial ports of the local PCs and runs the terminal
emulation program on the PCs
Command line interface
Description
RJ-45
Asynchronous EIA/TIA-232
300 bps to 115.2 kbps
Modem dial-up
Backup
PPP (Point to Point Protocol)
SLIP (Serial Line Internet Protocol)
MP (Multilink PPP)
Router 3012 9
