Table 9 System Specifications for the Router 3013 and Router 3015 (continued)
Item Router 3013 Description
Operating 5 to 85% (noncondensing)
humidity
Table 10 lists and describes the LEDs on the front panel of the Router 3013 and
Router 3015.
Table 10 Router 3013 and Router 3015 LEDs
LED Description
POWER Off — The power is not on.
Green — The power is on.
100M ETH Off — The link is not connected.
Flashing green — Data is being transmitted over the Ethernet port.
SERIAL Off — The link is not connected.
Green — The link is connected.
Flashing green — Data is being transmitted over the serial port.
BRI Off — No data is being transmitted over the ISDN BRI port and two B
channels are free.
Flashing green — Data is being transmitted over the ISDN BRI port.
AUX Off — The link is not connected.
Green means — The link is connected.
Flashing green — Data is being transmitted over the AUX port.
SYSTEM Flashing green — The system is operating normally.
Always green or off — The system is not operating normally.
The Router 3013 provides a console port, an AUX port, a 10/100M Ethernet port,
a synchronous/asynchronous serial port, and an ISDN S/T port.
The Router 3015 provides a console port, an AUX port, a 10/100M Ethernet port,
a synchronous/asynchronous serial port, and an ISDN U port.
Console Port
Table 11 lists attributes of the console port.
Table 11 Attributes of the Console Port
Attribute Description
Connector RJ-45
Port standard Asynchronous EIA/TIA-232
Baud rate 9.6 to 115.2 kbps (9.6 kbps is the default)
Services Connects with terminal
Connects with serial ports of the local PCs and runs the terminal
emulation program on the PCs
Command line interface
Router 3015 Description
