System Specifications
Figure 3 Router 3013 and Router 3015
Figure 4 illustrates the back panel of the Router 3013 and 3015.
Figure 4 Back Panel of the Router 3013 and Router 3015
CON
OFF ON DC12V
CON
Power
port
switch
Power
AUX
input
port
socket
Table 9 lists system specifications for the Router 3013 and Router 3015.
Table 9 System Specifications for the Router 3013 and Router 3015
Item Router 3013 Description
Fixed ports 1 console port
1 10/100M Ethernet port
1 AUX port
1 synchronous/asynchronous
serial port
1 ISDN BRI S/T port
Processor MPC860T 50 MHz
SDRAM 64 MB
Flash memory 8 MB
Maximum 20 W
power
Power supply Input voltage and frequency: 100 to 240V AC (the actual range can be 80 to
(external) 264 V) 50/60 Hz
Input current: 0.5 A to 1A
Output voltage: 12 V
Output current: 4 A
Dimensions (W 251 X 42.5 X 187mm (9.9 X 1.7 X 7.4 in)
X H X D, the
highest arc
points of the
plastic panel)
Weight 0.75 kg (1.65 lb)
Operating 0 to 40 C (32 to 104
temperature
Power LED
Serial LED
BRI LED
AUX LED
System LED
AUX 100M ETH SERIAL
100M Grounding
screw
Ethernet
port
SERIAL0
Router 3015 Description
1 console port
1 10/100M Ethernet port
1 AUX port
1 synchronous/asynchronous serial port
1 ISDN BRI U port
0 F)
Router 3013 and Router 3015
100M Ethernet LED
BRI
BRI port
