Northcote Divider Unit
L1420
Assembly Difficulty
easy -
medium
- hard
V2
one-person job
24/01/2017
Thank you for shopping with GLTC, we hope you enjoy having this
product in your home.
We know assembling furniture, toys or accessories is not everyone's favourite
way to spend their time, so we've tried to make assembling this item as quick and
painless as possible.
Hopefully our efforts will have been worthwhile and you'll sail through the
whole process. But if it all feels a bit too much like hard work, then we do have
an assembly company we can recommend: the Flatpack Construction Company
offers a nationwide service and can be contacted on 0843 289 4951 or www.
flatpackconstruction.co.uk.
A few important pointers before you start:
•
Please read the instructions right through before you start, and check that all the
components have been included in the pack; we find separating all the hardware
into piles makes it easier to be sure that everything is present and correct.
•
Make sure you have the right tools. Allen keys are provided if required, but screw
drivers and other tools are not. You'll find details of the tools you need at the
beginning of the instructions.
•
It's a good idea to build the unit in the room where you are going to be using it, to
avoid the need to move it after it's been assembled.
•
Do not throw away any packing materials until assembly is complete, just in case
you accidentally discard smaller parts and hardware.
1
Advertisement
Related Manuals for Great Little Trading L1420
Summary of Contents for Great Little Trading L1420
- Page 1 Northcote Divider Unit whole process. But if it all feels a bit too much like hard work, then we do have L1420 an assembly company we can recommend: the Flatpack Construction Company offers a nationwide service and can be contacted on 0843 289 4951 or www.
-
Page 2: Safety Warnings
Safety Warnings: Customer Service: • Anti-tip furniture straps are recommended for use on the Northcote range. Anti- • If you find that any components are missing or damaged, please do not begin tip furniture straps (G5323) are available from gltc.co.uk. assembly and do not use the item. - Page 3 Component Check List: All Hardware You will need: (not supplied) Unit Side Panels (left & right) 8x Cam Dowels 8x Cam Locks 45mmL 14mmDia 8x Wooden Dowels 8x Shelf Fixings Philips Head Screwdriver 20mmL 15mmL 2x Shelf Panels Component Check List: Divider Unit 1x Unit Top (recessed groove at top) 1x Unit Base...
- Page 4 Assembly left Ensure that each cam lock’s arrow is STEP 1: pointing towards the drill hole on the side edge of the component. Lay the 2 x side panels (C) on a clean flat surface with the drill holes and groove facing up, in the position shown. Hardware for Step 1: Insert 4 x wooden dowels (#3) into the drill holes in the four corners of BOTH side panels (C).
- Page 5 left left STEP 3: STEP 4: Position unit base (B) over the left hand side panel (C) as shown, so that the recessed grooves on each panel are aligned. Guide the unit Position the unit top (A) over the shaped top edge of the side base (B) over the cam dowels and wooden dowels onto the lower edge panel (C) as shown, and so the recessed groove lines up on of the side panel (C) and into the drill holes on the edge of the panel.
- Page 6 STEP 5: STEP 6: Insert the divider panel (F) between the unit top (A) and unit base (B) as shown, ensuring that the Gently, slide the 2x back panels (E) into the recessed groove of the unit top (A) and base (B), ensuring it is protrusions on the divider panel are sitting securely in the corresponding recesses of the unit top (A) &...
- Page 7 Hardware for Step 8: 8x #4 Shelf Pegs right When in position, turn the four remain- ing cam locks (#2) on the unit top & base clockwise to lock in place. STEP 7: STEP 8: Position the remaining side panel (C) over the unit. Guide the cam dowels and wooden dowels on the side Turn the unit up the right way and insert the shelf pegs (#4) into the drill holes on each side of the divider panel into the drill holes on the edges of the unit top (A) and base (B).
- Page 8 Position the 2 x shelf panels (D) over the shelf pegs and press down firmly so that they are securely in place. or L1423 Northcote Open Base. Copyright© 2011 G.L.T.C. Ltd. All rights reserved. Great Little Trading Company and GLTC are registered trade marks of G.L.T.C. Limited.
