Cmsis Pack In Keil Μvision5 - Analog Devices EVAL-ADUCM10QSPZ User Manual

UG-1541
CMSIS PACK IN KEIL μVISION5
After the Keil μVision5® IDE is installed, open the application
and use the following steps to properly set up the
device from the IDE:
1. Open the CMSIS pack installer as shown in Figure 5.
When the pack installer is opened for the first time, it may
take a few minutes to update the pack installer.
Figure 5. Pack Installer
EVAL-ADUCM410QSPZ/EVAL-ADUCM410QSP1Z
2.
ADuCM410
3.
Figure 6. Pack Installer
Figure 7. ADuCM410 Device in Keil μVision5
Rev. 0 | Page 8 of 20
After the CMSIS pack installer has opened, click File >
Import. Select and import the ADuCM410 pack that is
included in the installation setup (see Figure 6).
With the ADuCM410 CMSIS pack installed, the
ADuCM410 device is supported by the Keil μVision5 IDE.
The ADuCM410 appears in the Device tab of the Keil
window, as shown in Figure 7.
User Guide
