ARDUINO CONNECTOR

The EVAL-ADUCM410QSPZ and EVAL-ADUCM410QSP1Z
have Arduino R3 headers directly compatible with Arduino
Uno and Arduino Zero. Using the EVAL-ADUCM410QSPZ
or EVAL-ADUCM410QSP1Z board with Arduino Uno or
equivalent is recommended. The Arduino pins used by the
EVAL-ADUCM410QSPZ or EVAL-ADUCM410QSP1Z board
are given in Table 3.
For more information on the ADuCM410 pins, refer to the
ADuCM410 data sheet and ADuCM410 hardware reference
manual (UG-1807).
Table 3. EVAL-ADUCM410QSPZ/EVAL-
ADUCM410QSP1Z Pin Connections to Arduino Pins
EVAL-ADUCM410QSPZ (CSP_BGA)/
EVAL-ADUCM410QSP1Z (WLCSP)
R3 Header Pins
Digital
P13 (Both EVAL-ADUCM410QSPZ and EVAL-
ADUCM410QSP1Z)
P1.2/SCL1
P1.3/SDA1
AREF
DGND
P0.0/SCLK0
P0.1/MISO0
P0.2/MOSI0
P2.0
P0.3/CS0
P2.1/IRQ2
P18 (EVAL-ADUCM410QSPZ) and
P16 (EVAL-ADUCM410QSP1Z)
P1.0/SIN1
P1.1/SOUT1
P0.6/SCL2
P0.7/SDA2
P1.4/SCLK1
P1.5/MISO1
P1.6/MOSI1
P1.7/CS1
EVAL-ADUCM410QSPZ/EVAL-ADUCM410QSP1Z
EVAL-ADUCM410QSPZ (CSP_BGA)/
EVAL-ADUCM410QSP1Z (WLCSP)
R3 Header Pins
Power
Arduino Pin
SCL
SDA
Analog
AREF
GND
SCK
MISO
MOSI
SS
GPIO
GPIO
RXD
TXD
GPIO
GPIO
GPIO
GPIO
GPIO
GPIO
Rev. 0 | Page 6 of 20
P19 (EVAL-ADUCM410QSPZ) and
P18 (EVAL-ADUCM410QSP1Z)
P0.1/MISO0
IOVDD0
P0.0/SCLK0
P0.2/MOSI0
RESET
DGND
P20 (EVAL-ADUCM410QSPZ) and
P19 (EVAL-ADUCM410QSP1Z)
Arduino or ADuCM410 Power
AGND
AGND
Arduino or ADuCM410 Power
Arduino or ADuCM410 Power
Arduino or ADuCM410 Reset
Arduino or ADuCM410 Power
No Connect
P21 (Both EVAL-ADUCM410QSPZ and EVAL-
ADUCM410QSP1Z)
AIN0
AIN1
AIN2
AIN3
AIN4
AIN14
User Guide
Arduino Pin
MISO
3.3V
SCK
MOSI
RESET
GND
7V VIN
GND
GND
5V
3V3
RESET
IOREF
No connect
ADC5
ADC4
ADC3
ADC2
ADC1
ADC0
