Summary of Contents for Fahl Tracheoport
- Page 1 Tracheoport ® Operating instructions 999.0700.B 2013-04 Index: 06 0482 Tracheoport ® Operating instructions 999.0700.B 2013-04 Index: 06 0482...
- Page 2 Tracheoport ATTENTION: Prior to starting the Tracheoport ® , please read these operating instructions carefully and keep them near the unit for later reference. Vertrieb: Andreas Fahl Medizintechnik-Vertrieb GmbH, August-Horch-Str. 4a – D-51149 Köln, Tel: 02203/2980-0 – Fax: 02203/2980-100 Tracheoport ATTENTION: Prior to starting the Tracheoport ®...
-
Page 3: Table Of Contents
2.3 For your safety ........................2 - 3 2.4 Intended use ..........................4 2.5 Technical specifications ......................4 Connecting, starting and operating the Tracheoport ® ............5 - 8 3.1 Functioning ..........................5 3.2 Starting the unit ......................... 6 Operating the unit ......................... 7 - 8 Cleaning and servicing ...................... -
Page 4: General
2.0 General 2.3 For your safety 2.1 Dispatch This Tracheoport ® was subjected to a thorough quality control The Tracheoport® has been designed acc. to EC-directions on medi- before shipment. Carefully inspect the device immediately cal products 93/42/EEC Annex IX and has been classified as suction for any signs of damage and check the contents of the car- unit of group IIa. - Page 5 Only use original accessories and spare parts. 2.3 For your safety (contin.) The Tracheoport® has been designed for aspirating body The Tracheoport® may only by used by persons in- fluids in medical ranges. structed in the use of this unit and being aware of the Never remove explosive gases and inflammable or contents of these operating instructions.
-
Page 6: Intended Use
Protection class Type BF Risk class Responsibility for the unit, for users, objects and affected Ambient conditions: persons is not assumed if the Tracheoport ® is used without ob- Transport/storage -10...+ 60°C serving the instructions in this manual. Operation -5...+ 40°C 20...80% humidity without condens. -
Page 7: Connecting, Starting And Operating The Tracheoport
3.0 Connecting, starting and operating the Tracheoport ® 3.1 Functioning The Tracheoport ® is a very handy small suction unit. It is driven by an electromotive, maintenance-free oscillating piston pump. During operation, the pump generates a vacuum within the hose system and the collection jar, thus removing secretions or fluids (e.g. by means of a suction catheter). The fluid is gathered in... -
Page 8: Starting The Unit
The Tracheoport® is supplied ready for operation. In order to have the battery fully charged, connect the charging power pack to the Take the unit out of the packaging. Check whether the mains and join it with the connection jack at the Tracheoport®. -
Page 9: Operating The Unit
3.0 Connecting, starting and operating the Tracheoport® 3.3 Operation When the Tracheoport® is used for mucus extraction from the upper respiratory tracts you should follow the following proce- dure: – Take Tracheoport® out of carrying case or from holder. – Put up the unit in vertical position. - Page 10 When the jar is filled, the overflow safety reacts and suction is stopped. Empty the jar as described in section 4.1. If secretion has penetrated the pump, the Tracheoport® has to be maintained by a service technician. Fig. 3 Finger tip...
-
Page 11: Cleaning And Servicing
4.0 Cleaning and servicing Cleaning and servicing Cleaning and disinfection The unit can be wiped with a moist (not wet) cloth. All hoses and collection jars can be cleaned, treated and B a s i c a l l y, a l l p a r t s w h i c h c o m e i n t o c o n - disinfected. As the inside of the suction hoses are difficult tact with secretion must be cleaned and disin- to clean and will discolour with time, it is recommended... - Page 12 4.0 Cleaning and servicing Ut is recommended to use following disinfectants for instruments and surfaces. Instructions by the respective manufacturer are to be observed. Recommended instrument disinfectans: Disinfectant Ingredients (per 100 g) Manufacturer GIGASEPT FF succinic acid dialdehyde 11.0 g Schülke &...
-
Page 13: Filter
4.0 Cleaning and servicing 4.4.1 General 4.4 Filter There is a bacterial filter (Fig. 4.1) at the lid of the Tra- cheoport® which a) protects the interior of the unit against contaminati- b) stops the flow of liquids due to its hydrophobic features. Together with the mechanical overflow safety this filter prevents sucking in of secretion into the interior of the unit, and, due to this, failure of the unit. - Page 14 4.0 Cleaning and servicing 4.4 Filter (contin.) When inserting a new filter, pay attention to direction of flow (indicated by cone connection). Recommendation: – In private use, the filter should be replaced at least weekly. If the unit shows a reduced performance the filter must be changed earlier! – In hospital use, the filter should be replaced every week! Attention: Please take care that there are always sufficient spare filters available.
-
Page 15: Trouble-Shooting List
5.0 Trouble-shooting The Tracheoport® was subjected to a thorough quality control before shipment. If there is, nevertheless, some malfunction, you possibly might solve this problem yourselves if you observe the following instructions: Problem Possible causes Remedy Unit does not start –... -
Page 16: Spare Parts And Accessories
6.0 Spare parts and accessories Fig. 5 Tracheoport ® Connection hose 5.2 Bacterial filter Collection jar lid complete 5.10 Collection jar Hose connector Suction hose 5.11 Finger tip 5.12 Suction catheter Mirror 5.10 Lamp 5.11 Support for hose/mirror 5.12 Cover for rinsing jar Fig. -
Page 17: Spare Parts And Accessories
6.0 Spare parts and accessories Spare parts for Tracheoport® Fig. Description Article-No. 2.0....Charging power pack ..................63505 5.1....Connection hose, silicone, ø 6mm ..............63506 5.2....Bacterial filter ....................63700 5.3....Collection jar lid complete................63501 5.4....Collection jar 0.5 l .................... 63502 5.4.... - Page 18 6.0 Spare parts and accessories Accessories for Tracheoport® Suction catheters, straight, central opening, 2 small lateral openings, length: 50 cm, each packed separately and sterile in packing lots of 100 pcs. Fig. Description Article-No. 5.8....Size: Charrière 6 - 18 ................68000 Car connection cable (12 V on board) ................63510...
-
Page 19: Maintenance And Repair
7.0 Maintenance and repair The Tracheoport® may only be opened and repaired by per- sons explicitly authorized by Fahl. Technical and hygienic pre-cautionary measures have to be observed. The manufacturer rejects liability for performance of the unit if it has been improperly repaired or if no original spare parts have been used. -
Page 20: Disposal
8.0 Disposal At the end of durability, dispose of the components of the Tracheoport®, observing the applicable waste-control regulations. In doing so, make sure that the materials are carefully separated. TheTracheoport® does not comprise any hazardous materials. The material of the housing can be completely recycled.
