B. Braun Omnitest plus Manual page 4

The Meter
Up button
Test strip ejector
Product label
Battery cover
6
Display Segments
Test strip port
Data transfer port
LCD display
Down button
Power +
Select button
Segment Meaning
The battery symbol means
the battery is low and
should be changed soon.
The "DEL" mark will
display when you can
delete results from the
meter memory.
Close the test strip
vial cap.
The "MEM" mark will
display while reviewing
the results.
The "SET" mark will
display during ALL meter
setting.
The "CODE" mark will
display while coding the
meter.
Segment Meaning
"AVG" is displayed when
average results are shown.
Control solution symbol
Alarm symbol
Buzzer symbol
Sample applying symbol
Test result unit
Temperature symbol
Year
Month
Day
0 - 12 o'clock
12 - 24 o'clock
7
