SPECIFICATIONS:

Model ........................................ 915XBISP
Frequency Range ...................... 900 To 930 mHz
Usable Range ............................ 880-940 mHz
*Gain .......................................... 15.2 dBi
Front to back .............................. 22 dB Typical
Beamwidth ............................... E=30° H=32°
Feed type ................................... Folded Dipole
Feed Impedance. ....................... 50 Ohms Unbalanced
VSWR ........................................ 1.2:1 Typical

FEATURES:

The NEW 915XBISP high performance Yagi, is the latest product to come out of M2's Engineering Lab. Using
our customers' suggestions, we have black powder coated the entire antenna creating a hard finish that is tougher than
conventional paint. Solid 5/16" aluminum rod is used for the element structure allowing for slight rain and snow
accumulation. Built on a 1" heavy duty boom and includes a heavy duty mounting clamp, allowing for a wide range of
masts sizes from 1 1/4" to 2".
The heart of the 915XBISP, the folded dipole, provides a virtual flat match for over 30 MHz. Again using our customers'
suggestions, the mating connector now faces down for ease of cable connection. The gain has been designed to roll-off
quickly above range limits to prevent receiver overload from high power services above 930 MHz.
The 915XBISP is a DC grounded antenna designed to work with many radios including Motorola Canopy, Vecima
Networks, Trango and many others.
M2 Antenna Systems, Inc. 4402 N. Selland Ave. Fresno, CA 93722
M2 Antenna Systems, Inc.
Model No: 915XBISP
NEW!
WITH HEAVY DUTY
FITS 1-1/4" TO 2" MAST
*Subtract 2.14 from dBi for dBd
Tel: (559) 432-8873 Fax: (559) 432-3059 Web: www.m2inc.com
©2015 M2 Antenna Systems Incorporated
Input Connector .......................... "N" Female
Polarity ....................................... VERT / HORZ
Power Handling .......................... 500 Watts
Boom Length / Dia ..................... 43-1/2" / 1"
Stacking Distance ...................... 22"
Mast Size .................................... 1-1/4" to 2"
Wind area / Survival ................... 0.4 Sq. Ft. / 100MPH
Weight / Ship Wt. ....................... 4 Lbs. / 5 Lbs.
915XBISP E-PLANE
915XBISP H-PLANE
10/02/15
Rev.00
