EZ Build Assembly and Installation
28300 WingMan 6'8" with 2" Receiver Plow Standard Operating System and E-73 12V Hydraulic Unit
28310 WingMan 7'6" with 2" Receiver Plow Standard Operating System and E-73 12V Hydraulic Unit
Meyer Products LLC reserves the right, under its continuing product
improvement program, to change construction or design details, specifications
and prices without notice or without incurring any obligation.
© 2018 Printed in the U.S.A.
and
www.meyerproducts.com• email info@meyerproducts.com
Meyer Products LLC
18513 Euclid Ave. • Cleveland, Ohio 44112-1084
Phone 216-486-1313
Form No. 1-1164R
October 2018
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Meyer WingMan 28300
Summary of Contents for Meyer WingMan 28300
- Page 1 28300 WingMan 6’8” with 2” Receiver Plow Standard Operating System and E-73 12V Hydraulic Unit 28310 WingMan 7’6” with 2” Receiver Plow Standard Operating System and E-73 12V Hydraulic Unit Meyer Products LLC reserves the right, under its continuing product improvement program, to change construction or design details, specifications and prices without notice or without incurring any obligation.
-
Page 2: Table Of Contents
4. The vehicle must be equipped with a “Heavy Duty Battery” (70 Amp, Hr. Min.), 550 C.C.A. and “Alternator” (60 Amp. Min.) to obtain maximum performance 5. Follow these instructions explicitly. Warranty does not apply to a Meyer product which has been negligently or improperly assembled or installed . -
Page 3: Illustrated Parts Lists
• Bolt H 5/8-11 x 3” Gr. 5 Parts indented are included in the carton, bag or assembly under which they are indented. Meyer Products LLC reserves the right, under its continuing product improvement program, to change construction or design details, specifications and prices without notice or without incurring any obligation. - Page 4 28300 and 28310 E-73 Assembly 27 & 28...
- Page 5 • Locknut 1/2-13 Parts indented are included in the assembly under which they are indented. Meyer Products LLC reserves the right, under its continuing product improvement program, to change construction or design details, specifications and prices without notice or without incurring any obligation.
-
Page 6: Attaching Plow To Ez Build Assembly
Attaching Plow to EZ Build Assembly Liberally coat Pivot Pins (54) with Coolube Multi-Purpose Premium Grease Attach Plow Markers (43) to moldboard using 5/16-18 x 1” Bolt (44), 5/16” Part No. 15181. Flatwasher (46) and 5/16-18 Locknut (45) Attach Pivot Bar (6) to Moldboard with Pivot Pins (54), 5/8” flatwashers (52) and insert Cotter Pins (53). -
Page 7: Vehicle Side Wiring Diagram
(negative post) of vehicle battery. GROUND WIRE EACH COIL BLACK W/WHITE STRIPE Top off the unit to the fill line on the reservoir with Meyer M-1 Hydraulic Fluid. Assemble adjustable stacking stop bolts to lift frame (13) using 5/8-11 x 2-3/4”... -
Page 8: Mount Plow System To Vehicle
4. Remove crankstand from a-frame. 6. Remove weather covers and connect both electrical plugs. 6. Remove weather covers and connect both electrical plugs. 5. Attach crankstand to lift frame. Meyer Products assumes no responsibility for installations not made in accordance with these instructions. -
Page 9: Dis-Mount Plow System From Vehicle
7. Disconnect both electrical plugs and install weather cover on both ends. 6. Remove hair pin and pull out receiver hitch pin. Meyer Products assumes no responsibility for installations not made in 8. Back vehicle away from plow assembly. accordance with these instructions. -
Page 10: Hydraulic Unit Drop Speed Adjustment, Wiring And Accessories
“C” Valve Green & Black with White Stripe Right Angle Cylinder Motor Solenoid White Motor Solenoid Purple Please visit http://www.meyerproducts.com/plows/lotpro.aspx for a complete listing of accessories Meyer Products LLC 18513 Euclid Ave. • Cleveland, Ohio 44112-1084 Phone 216-486-1313 www.meyerproducts.com• email info@meyerproducts.com... -
Page 11: Pre-Delivery Inspection
PRE-DELIVERY INSPECTION Vehicle Make: Vehicle Model: Vehicle Year: Vehicle VIN#: Vehicle FGAWR: Installing Company: Mounting Type: Plow Type: WingMan Hydraulic Serial Number: Moldboard Serial Number: All bolts torqued to specification Plow Operation Up Suspension interference Plow Operation Left 2” Receiver height in inches Plow Operation Right Trip springs adjusted Plow Operation Down...
