Meyer Diamond MD II Parts & Installation Instructions

Parts & Installation Instructions
21
18
17
18
5
Item 8.5 Qty.
09258 2 Moldboard R.H. & L.H. Wing
1 09254 1 •R.H. Wing
2 09255 1 •L.H. Wing
3 09259 1 •Cutting Edge (2 sections)
08692 1 •Hardware Bag
4 21961 8 •• Bolt C 1/2-13 x 2 Gr. 5
5 22066 2 •• Bolt C 1/2-13 x 2-3/4 Gr. 5
6 20307 1 0 •• Locknut 1/2-13
7 09126 2 •Runner & Spindle Assembly
8 07006 1 •• Runner
9 12057 1 •• Spindle
1 0 20363 1 0 •• Flatwasher 1-1/4"
1 1 22083 1 •• Linch Pin
1 2 20101 1 •• Bolt H-1/2-13 x 3"
1 3 20307 1 •• Locknut 1/2-13
12170 1 Snow Deflector KIT (OPTIONAL)
1 4 12189 2 •Deflector
1 5 12191 2 •Bar
1 6 12277 1 •Reinforcment Bar
1 7 12285 1 •Center Deflector & Decal
08691 1 •Hardware Bag
1 8 20006 1 8 •• Bolt H 1/4-20 x 1-1/4"
1 9 20312 1 8 •• Nut, Eslok 1/4-20
2 0 12275 2 •• Angle
2 1 12276 2 •• Deflector Extension
Parts indented are included in the carton, bag or assembly under which they are indented.
Meyer Products and Diamond Equipment reserves the right, under its continuing product improvement program, to change
construction or design details, specifications and prices without notice or without incurring any obligation.
Meyer Products
18513 Euclid Ave. • Cleveland, Ohio 44112-1084
Phone 486-1313 (Area Code 216)
email warranty@meyerproducts.com
© 2002 Printed in the U.S.A.
MDII™ "Vector" 8.5' Snow Plow
20
25
16
33
19
35
34
38 36
35
37
14
39
4
15
Description
1
9
8
12
26
24
22
6
30
28
33
2
6
3
ITEM 26 OPEN END OF HOOKS
MUST BE FACING DOWN ON ITEM 22
Parts List
Item 8.5
16525
2 2 13625
2 3 13727
2 4 07178
2 5 07069
2 6 07216
09916
2 7 8511002008040
08775
2 8 07031
2 9 12396
3 0 09124
3 1 20073
3 2 20306
3 3 20421
3 4 12198
3 5 12381
3 6 20357
3 7 20328
3 8 20354
3 9 20072
07996
#6 Angell Lane • Damariscotta, ME 04543-9720
www.diamondplow.com • email info@diamondplow.com
10
11
13
7
23
27
29
38
31
32
38
Qty. Description
1 A-Frame and Pivot Carton
1 • Pivot Assembly
1 • A-Frame
2 • Wing Spring
1 • Hinge Pin
4 • Trip Spring
1 • Plow Marker Kit
1 • Lift Chain
1 •Hardware Bag
6 •• Eye Bolt Cap
1 •• Pivot Pin
6 •• Eye Bolt w/Locknut
1 •• Bolt H 7/16-14 x 1-1/2"
1 •• Locknut 7/16-14
2 •• Cotter Pin 1/4" x 2-1/4"
1 •• V-Plow Center Edge
2 •• Center Plate
1 •• 5/8 Flatwasher
1 •• 7/16 Lockwasher
3 •• 7/16 Flatwasher
1 •• Bolt H 7/16-14 x 1-1/4"
1 •• Cable Tie
Diamond Equipment
Phone 563-2227(Area Code 207)
Form 1-784
May, 2002
