OWNER'S MANUAL
AND
USER'S GUIDE
Read the DrivePro LD Owner's Manual before operating or servicing a snow plow.
FOLLOW THESE INSTRUCTIONS EXPLICITLY.

Advertisement

Troubleshooting

loading
Need help?

Need help?

Do you have a question about the Drive Pro LD and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Meyer Drive Pro LD

Summary of Contents for Meyer Drive Pro LD

  • Page 1 OWNER’S MANUAL USER’S GUIDE Read the DrivePro LD Owner’s Manual before operating or servicing a snow plow. FOLLOW THESE INSTRUCTIONS EXPLICITLY.

  • Page 2: Table Of Contents

    Thank You Thank you for buying the Drive Pro LD. As a new owner of hard-working, mechanical equipment, we strongly urge you to spend quality time with this owner’s manual. It’s easy to use and full of time-saving tips that will enhance your ownership experience.

  • Page 3: Safety

    Obey all The Drive Pro LD should be used on compact and smaller vehicles. Use of this product on larger vehicles is prohibited and can result in damage to the safety messages that follow this vehicle or plow.
  • Page 4 Failure to comply will result in property damage. injury. Warranty does not apply to a Meyer product which has been negligently or improperly assembled or installed. Failure to comply will result in property damage. CAUTION: To avoid harm to vehicles electrical system always disconnect battery before beginning installation. DO NOT BURN holes or WELD vehicle CAUTION Indicates an potentially frame.

  • Page 5: Introduction

    Introduction Registration Meyer has published this manual to help you get maximum Register your snowplow at www.meyerproducts.com performance from your snow plow and familiarize you with the Once registered, you will be given a Registration ID. features designed for efficiency and safety; be sure you recognize Use the form below for your own records and understand them.
  • Page 6 STEP 1: (Fig. 1) (Fig. 2) PLOW LIFT FRAME ASSEMBLY STEP 1a Attach the two wheel assemblies with the shorter brackets to either side of the plow pivot bar (fig. 1 & 2) and the third wheel assembly to the Lift Frame Assembly under the lifting cylinder. Your Drive Pro Light Duty should now look like the picture below.
  • Page 7 STEP 2: (Fig. 14) WIRING INSTALLATION STEP 2a Carefully route the Vehicle Harness to the vehicle battery (fig. 12). You may need to route thru the grille or behind/under the bumper. Be sure to stay (Fig. 12) (Fig. 13) away from hot, sharp or moving parts of the vehicle and use the zip ties provided to secure.
  • Page 8 STEP 3: INSTALL PLOW ONTO VEHICLE (Fig. 22) (Fig. 21) (Fig. 23) Remove Pin Lift here and push toward vehicle. Lift here STEP 3a Gently roll the plow to the receiver hitch on the vehicle so that the male tube on the lift frame is lined up directly in front of the receiver hitch (fig.
  • Page 9 STEP 3b Remove both weather covers from the ends of the Plow Harness and Vehicle Har- Raise ness, add dielectric grease to (UP) the connecting prongs and connect. Lower (DOWN) Auto Angling Controller (Part #22846) STEP 3c Turn on Controller. On/Off Raise (UP)
  • Page 10 Auto Angling Controller Operation STEP 3d Raise plow and reposition the two front wheel brackets 180 degrees (fig. 25) and (Part #22826): Turn the controller on. When turned on the controller will illuminate. The Plow UP and the one rear wheel bracket 90 degrees (fig. 26) for plowing mode. Plow DOWN switch is a 3 position switch.
  • Page 11 ATTACH PLOW TO (Fig. 30) (Fig. 31) VEHICLE (Fig. 32) Remove Hitch Pin and gently roll the plow to the receiver hitch on the vehicle so that the male tube on the lift frame is lined up directly in front of the receiver hitch (fig. 30).
  • Page 12 REMOVE PLOW (Fig. 38) (Fig. 37) FROM VEHICLE Raise plow and set wheels to storage (Fig. 39) position (fig. 37-39). Lower plow all the way down. On hydraulic models, put the controller into “Float” position and push down on lift arm to put slack into the lift chain (fig.
  • Page 13 2-3 links of slack (fig.44). Also if a major hydraulic malfunction is experienced the plow can be raised by a floor jack or two people and the chain can be adjusted up with no slack. This will then suspend the plow above ground so the vehicle can be driven to your nearest Meyer Service center. (Fig. 44) Plowing (with Auto Angling) Always plow with the storm, every 5 to 8 cm of accumulation.

  • Page 14: Troubleshooting Guide

    Troubleshooting Guide for The Drive Pro LD Auto Angling Condition Possible Cause Correction Plow doesn’t lift 1. Low hydraulic fluid level 1. Add fluid to proper level 2. Discharged battery 2. Recharge battery Auto-Angling Model or lifts slowly - 3. Leaking or open “S1” cartridge 3.
  • Page 15 Troubleshooting Guide for The Drive Pro LD Power Angling Condition Possible Cause Correction Condition Possible Cause Correction Plow doesn’t lift 1. Low hydraulic fluid level 1. Add fluid to proper level Plow creeps down 1. Leaking “s1” cartridge 1. Clean or replace “S1” cartridge 2.

  • Page 16: Pre-Season & Post-Season Maintenance

    PRE-SEASON & POST-SEASON MAINTENANCE Meyer recommends this maintenance information for regular service. Sustained heavy operation may call for more frequent service. Snow plowing subjects a vehicle to exceptionally rugged use. As a result, it is very important to inspect and maintain the snow plow and vehicle up to maximum operating conditions.
  • Page 17 It is effective for Grease a maximum of one year. Always carry an extra quart of Meyer M-1 Hydraulic Fluid. Use of any inferior fluids will void Drive Pro LD warranty.

  • Page 18: Parts List

    PART NO. QTY. DESCRIPTION 25800 Drive Pro LD Auto Angling 08245 ••• Mounting Hardware Bag 16609 • Drive Pro LD PAF/Lift Frame 11101 •••• Hinge Pin DRIVE PRO LD 20152 •••• Bolt 5/8-11 x 5” Gr. 5 13145 •• Lift Frame & Hydraulic Assy 20355 ••••...
  • Page 19 PARTS LIST DRIVE PRO LD AUTO ANGLING – Hydraulic...
  • Page 20 PARTS LIST ITEM PART NO. QTY. DESCRIPTION 13851 Drive Pro LD Auto Angling Hydraulic Unit DRIVE PRO LD • Base Assy. • Pump Assy. AUTO ANGLING – • 1/4 x 3/4” Dowel Pin Hydraulic Unit • Intermediate Shaft • 1/4-20 x 1-1/4” Socket Head Cap Screw 15101 •...
  • Page 21 ITEM PART NO. QTY. DESCRIPTION 26800 Drive Pro LD Power Angling 08264 ••• Mounting Hardware Bag 16610 • Drive Pro LD PAF/Lift Frame DRIVE PRO LD 11101 •••• Hinge Pin 13155 •• Lift Frame & Hydraulic Assy 20152 •••• Bolt 5/8-11 x 5” Gr. 5 13095 •••...
  • Page 22 PARTS LIST DRIVE PRO LD Power Angling...
  • Page 23 PARTS LIST ITEM PART NO. QTY. DESCRIPTION 13848 Drive Pro LD Power Angling Hydraulic Unit DRIVE PRO LD • Base Assy. • Pump Assy. POWER ANGLING – • 1/4-20 x 1-1/4” Socket Head Cap Screw • 1/4 x 3/4” Dowel Pin Hydraulic Unit •...
  • Page 24 Steel Cutting Edge Drive Pro LD Poly Snow Deflector Manufactured with specially hardened steel Made of pliable poly, the Drive Pro LD deflector to meet the demands of a tough environment. keeps snow flume down and away from the Replacement cutting edges are sold as complete windshield and accentuates the snow rolling kits including attaching hardware and cutting edge.
  • Page 25 NOTES...
  • Page 26 Meyer will repair any product that proves to be defective in materials or workmanship. In the event repair is not possible or practical (as determined by Meyer in its sole discretion), Meyer will either replace the product with a new product of similar model and price, or refund the full purchase price, as determined by Meyer.
