PARTS & INSTALLATION INSTRUCTIONS
Item
1
2
3
4
5a
6a
7a
8a
9
5b
6b
7b
8b
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
*
32
33
34
Parts indented are included in the carton, bag or assembly under which they are indented. When ordering parts, furnish Part No., Name,
and Description. Also furnish Vehicle Model and Year. Type of Hydraulic Unit and Moldboard Size.
Meyer Products reserves the right, under its continuing product improvement program, to change construction or design details,
specifications and prices without notice or without incurring any obligation.
Meyer Products
18513 Euclid Ave. • Cleveland, Ohio 44112-1084
Phone 486-1313 (Area Code 216)
email•warranty@meyerproducts.com
© 2003 Printed in the U.S.A.
MEYER V - 66 QUIK LIFT
Part No.
Qty.
15770
1
Lift and P .A. Ass'y. (Complete) 12 volt
15840
1
• Lift Ass'y. (Unit only) 12 volt
15783
1
• Harness and Fuse Assembly
15370
1
• Starter Solenoid - 12 Volt
07071
1
• Ram L.H. with Hose & Fittings
05437
1
•• Ram 1-1/2" x 12"
22141
1
•• Hose Ass'y. 1/4 x 45" Lg.
21857
1
•• 1/4 x 90 Degree Elbow
15741
1
•• Coupler 1/4 - Male Half (22146)
22143
1
• Coupler Cap
07072
1
• Ram R.H. with Hose & Fittings
05437
1
•• Ram 1-1/2" x 12"
22144
1
•• Hose Ass'y. 1/4 x 45" Lg.
21857
1
•• 1/4 x 90 Degree Elbow
15741
1
•• Coupler 1/4 - Female Half (22145)
22142
1
• Coupler Plug
15811
1
• Pigtail Assembly
15671
1
• Power Cable - 63" - RED
15672
1
• Ground Cable - 42" - BLACK
05024
1
• Power Cable - 36"
15669
1
• Weather Plug - Solenoid Wires
36248
1
• Weather Plug - Power Cables
08473
1
• Relief Valve Kit - Reservoir
15765
1
• Hardware Bag
07273
1
•• Tap Connector
15102
1
•• Bolt 5/16-18 x 1-1/2" Gr.2
15673
1
•• Control Switch Bracket
15675
1
•• Clamp Plate
15676
1
•• Backup Plate
20312
2
•• Locknut 1/4-20
20863
2
•• Machine Screw 1/4-20 x 1" RND. HD.
21398
2
•• S. Tapping Screw 1/4-14 x 3/4"
21400
1
•• Washer INT/Ext Tooth 5/16
21832
1
•• Bushing - Split
21953
1
•• Decal - Danger (Mount on Dashboard)
22173
1
• Control Switch Assembly
08688
1
• Hardware Bag (P.A. Rams)
20150
2
•• Bolt H 5/8-11 x 4-1/2" Gr. 5
20151
2
•• Bolt H 5/8-11 x 4-3/4" Gr. 5
20309
4
•• Locknut 5/8-11
08642
1
Kit Bracket (Floor Mount) * Optional
15677
1
•• Bracket Floor
21398
4
•• Hex Head Self Tapping SCrew 1/4-14 x 3/4"
20325
4
•• Lockwasher 1/4"
PART LIST
Description
6 Angell Lane• Damariscotta, ME 04543-9720
www.diamondplow.com • email info@diamondplow.com
Form 1-702 R3
September, 2003
®
Diamond Equipment
Phone 563-2227(Area Code 207)
