Summary of Contents for Meyer EZ-MOUNT XPRESS AG-7.5
- Page 1 OPERATION and MAINTENANCE MANUAL Insist on genuine Meyer Parts & Accessories...
- Page 2 IMPORTANT NOTICE: In conjunction with FMVSS (Federal Motor Vehicle Standard) and OEM (Original Equipment Manufacturer) guide lines, Meyer Products LLC has designed this plow package with the following guidelines: CAUTION: Installation of a snowplow may affect your vehicle warranty.
-
Page 3: Table Of Contents
Stacking Snow SAFETY FIRST Trapped & Residential Areas Meyer Products recommends that this manual be read cover to cover so that Chemicals for Snow & Ice Control you are completely aware of all important safety recommendations. Record Meyer Products Salt Spreaders 21-23 your E-68 Serial number and Moldboard Serial number. -
Page 4: Get To Know Your Meyer Xpress Snow Plow
Made from 12 or 14 gauge steel, 6 vertical ribs. Painted with the 8. Mounting Cylinder Meyer Sno-Flo® Powder Coat, that is a baked on finish that looks Allows Plow Assembly to like glass, provides an extremely hard, low friction surface that be installed and removed outlasts ordinary paint by a large margin. -
Page 6: Xpress Specifications
SPECIFICATIONS (AG/DAG-7.5) (AG/DAG-8.0) (AG/DAG-8.5) (AG/DAG-9.0) WEIGHT (TOTAL) 850 lbs. 925 lbs. 945 lbs. 965 lbs. HEIGHT 32” 32” 32” 32’ LENGTH 90” 96” 102” 108” MOLDBOARD GAUGE VERTICAL RIBS TRIP SPRINGS CUTTING EDGES 3/8” X 6” 1/2” X 6” 1/2” X 6” 1/2”... -
Page 7: Snow Plow Controller Operation
SNOWPLOW HAND HELD While angling left or right or raising the snowplow if the button CONTROLLER OPERATION is pressed for more than four seconds the operation will be cancelled. This feature eliminates unnecessary amp draw from the vehicle charging system. To turn the controller on, press the on button located in the upper right hand corner on controller. - Page 8 flash until the Mount (MNT) button is pressed again turning the Mount/Dismount mode off. Note: If Monitor light is still illuminated after attempts to reset the controller, please contact your nearest authorized Meyer Activation of the Mount/Dismount Switch for longer than Distributor for repairs.
-
Page 9: Removing & Attaching Your Meyer E-Z Mount Xpress
Removing and Attaching Xpress Plow Removing Xpress™ Assembly : 1. Be sure Moldboard is on the ground. 2. Remove Xpress Lock Pin (Figure 1). 3. Turn on vehicle ignition switch, then Hand Held Controller. 4. Press Mount (MNT) button on Hand Held Controller. All controller buttons will illuminate and flash. 5. -
Page 10: General Maintenance & Adjustments
General Maintenance SNOWPLOW CAUTION: ALWAYS LOWER MOLDBOARD TO THE GROUND Meyer Products LLC recommends this maintenance information WHEN SNOW PLOW IS BEING SERVICED OR WHEN for regular service. Sustained heavy operation may call for more VEHICLE IS NOT IN USE. - Page 11 It is effective for a maximum of one year. Always carry an extra 8. DURA-SLICK™ POWDER COATING, both black and yellow, quart of Meyer M-1 Hydraulic Fluid. Use of any inferior fluids should be checked at the beginning and end of each season for will void the Meyer warranty.
- Page 12 SNOW PLOW STORAGE 1. When snow plow is disconnected, extend lift cylinder to end of stroke and coat chrome rod with light grease. This fills the cylinder with hydraulic fluid and protects the interior and exterior from rust and corrosion. 2.
-
Page 13: Trouble Shooting
TROUBLE SHOOTING These charts are intended to be used as an aid in diagnosing problems on the E-68 Meyer Hydraulic Power Units. They are not a substitute for factory training and experience. Be certain to read the General Information and Testing Tips sections before attempting any troubleshooting. -
Page 14: E-88 Diagnosis Chart
DIAGNOSTIC FLOW CHART FOR E-68 HYDRAULIC POWER UNITS MODEL CONDITION POSSIBLE CAUSE CORRECTION E-68 Plow does not lift or lifts 1. Low hydraulic fluid level. 1. Add fluid to proper level. slowly - motor operates. 2. Discharged battery. 2. Recharge battery. 3. - Page 15 DIAGNOSTIC FLOW CHART FOR E-68 HYDRAULIC POWER UNITS MODEL CONDITION POSSIBLE CAUSE CORRECTION E-68 Motor does not operate. 1. Discharged or defective battery. 1. Recharge or replace battery. 2. Loose or corroded electrical connections. 2. Clean and tighten electrical connections. 3.
-
Page 16: Efficient Snow Clearance Starts With Planning
Efficient Snow Clearance Starts with Planning PREPARING AREAS, USE OF GUIDE MARKERS Always plow in low gear and keep plowing. Heavy snow may Every area to be plowed should be inspected before snowfall also require clearing a path or area for working room to move for potential hazards. -
Page 17: Selecting Proper Size Snow Plowing Equipment
53,000 21,500 the Meyer Snowplow. Trucks 1 1/2 - 1 Ton Meyer Snowplow’s custom design for specific vehicles provides (2 WD) 7 - 7 -1/2 foot 38,000 19,000 the advantage of easy, fast attaching and detaching. This feature (4 WD) 7-8 foot 88.000... -
Page 18: Plow With The Storm
Plow with the Storm Angle Moldboard for Optimum Results. You will not be able to plow snow of any significant depth straight ahead for more than a short distance. Set the moldboard at the Plow with the Storm best angle for rolling snow sideways in the desired direction. It is of utmost importance to remember one basic rule —... -
Page 19: Establishing Snow Clearance Plans
Two Established Snow Clearance Plans These two snow plowing techniques have been time- and 3. Have vehicles and equipment inspected, fueled and ready. operation-tested. Use them as guidelines for most snow plowing strategies. Plan I is for smaller areas of 50,000 sq.ft. 4. -
Page 20: Snow Plowing Tips From The Pros
Snow Plowing Tips from the Pros SNOW PLOWING OPEN AREAS On a dirt or slag surface, drop moldboard to ground in straight Open areas such as parking lots require a more serious approach position, then raise one inch or adjust runners for desired to planning, where to begin, and where snow can be stacked at clearance. - Page 21 STRAIGHT LINE SNOW PLOWING WIDE DRIVEWAY This method is most efficient for drives, streets, roads and walkways. Moldboard type blade snow plows mounted on utility 1. Make one pass down center with blade in straight position. vehicles or service trucks are best for such an operation. 2.
-
Page 22: Stacking Snow
Snow Plow components CLEARING TRAPPED AREAS or the vehicle that will not be covered under the Meyer Areas where there is little or no space for stacking cleared snow Products Warranty Program. Such damage may include, are considered “trapped.”... -
Page 23: Chemicals For Snow & Ice Control
You may have to Mini Jr. (36006) increase the use of ice melting materials at night The Meyer Mini Jr (5.75cu.ft.) is an ideal solution for small and medium and as temperatures fall. sized jobs: walkways, intersections, access ramps and parking lots. - Page 24 - t o n d u m p b o d i e s b y s i m p l y replacing theexisting tailgate. Designed to spreadfree-flowing chemicals, salt The Meyer Mate XL spreader holds and/orsand throughout its entire 9 cubic feet of salt, sand or calcium...
- Page 25 Stainless Steel (63006),2.0 cu. yd. Carbon Steel (62992),2.0 cu. yd. Stainles Steel (63007) The Meyer 1.8 & 2.0 cubic yard capacityV-box spreader for pickup trucks mountsand stores as a single unit. This mechanically-operated spreader is powered by an electric start 10 H.P. gas engine, which drives a high torque orbital-type motor and a 20:1 ratio gearbox.
-
Page 26: Meyer Accessories
Meyer Accessories Snow Deflector M-1 Hydraulic Fluid Available in specific sizes to fit all Meyer Keep your Meyer Electro-Touch snow plow ® moldboards. Kits come with attaching parts. control system operating at peak performance; Deflects snow flume down and away from change hydraulic fluid yearly. - Page 27 It Deflects snow flume down and away from features special additives to ensure efficient your windshield. Available in specific sizes operation. to fit all Meyer moldboards. Kits come ready to install. Patented. Meyer M2 Hydra-Flush ®...
- Page 28 It’s reversible for extended wear. A perfect complement to the Touch Pad Controller, the leg strap keeps the Touch Pad close at hand. The adjustable buckle allows for a custom fit. Meyer Diamond Edge Reversible ® Cutting Edge (Button-trip)
- Page 29 (see page 4 for further information). Nite Saber I lights are standard equipment on new Meyer mounts. They have a slim profile and a strong light output.
-
Page 30: Genuine Meyer Parts
FAST MOVING PARTS LIST RUBBER EDGES W/HARDWARE 08189 AG-7.5 08190 AG-8.0 CUTTING EDGES - (STEEL) 08191 AG-8.5 8CE7.5 DAG-7.5 08192 AG-9.0 8CE8.0 DAG-8.0 8CE8.5 DAG-8.5 SNOWPLOW HARDWARE 8CE9.0 DAG-9.0 09124 EYE BOLT & NUTS 07017 TRIP SPRING CUTTING EDGE NUTS & BOLTS (STEEL) 08852 MARKER KIT AG / DAG 08184... - Page 31 CONTROLLER HOSE & HOSE FITTINGS 22693 CONTROLLER 22461 HOSE ASSY. 1/4 X 38” M-6 FACE SEAL HARNESS 22420 HOSE ASSY. 1/4 X 33” M-6 FACE SEAL 22694 PLOW SIDE 22691 TRIUCK SIDE COUPLER’S HOSE END (OPTIONAL) 22243 FEMALE COUPLER SAE-6 LIGHTS 22244 MALE COUPLER SAE-6...
- Page 32 Thank you for buying the best built, best backed plow in the industry. In order to expedite customer service and warranty registration www.meyerproducts.com please complete the below information and have it ready to register your product on line at www.meyerproducts.com Where Purchased Your Personal Plow Information Company __________________________________________...
