NOTICE: Meyer Products LLC reserves thje right, under its continuing product imporvement program, to change construction, design, details, specifications, and prices without notice or without incurring any obligation. Meyer Products LLC assumes no responsibility for installations not made in accordance with these instructions.
Page 4
Black Iron Parts List Item Part No. Part No. Qty. Description Item Part No. Part No. Qty. Description 28300 WM 6.8 2” Assy. 28301 28301 • Accessory Box 28310 WM 7.6 2” Assy. 23025 23025 •• Power Cable - 36” 05888 05888 •...
Moldboard Parts List Item 6’ 8” 7’ 6” Description 09478 09479 Drive ProTM Moldboard Assembly 09276 09796 • Cutting Edge 22067 • Bolt 1/2-13 x 3-1/4” Gr. 5 22067 • Bolt 1/2-13 x 3-1/4” Gr. 5 20307 20307 • Locknut 1/2-13 Parts indented are included in the carton, bag or assembly under which they are indented.
The following step is for 2015 & later GM vehicles with an alternator relay... 5) The WHITE wire will connect to 2015 & Later GM vehicles with alternator relay. See Meyer Products Service Bulletin SB252. The following two steps are optional and may be enforced by local law which requires your vehicle lights to be off while your plow The following two steps are optional and may be enforced by local law which requires your vehicle lights to be off while your plow lights are on and vice versa...
(i.e. driver side blinking instead of passenger side), reverse the harness connections. Note: All electrical connections should have both ends coated with a dielec- tric grease (Meyer Part # 15632) prior to final installation. This will ensure a good connection and help in preventing corrosion. Trip Spring Adjustment...
Page 8
Attach the Lift Chain to the Lift Arm through the two hooks on the lift Top off the unit to the fill line on the reservoir with Meyer M-1 Hydraulic arm. Adjust the lift chain at the lift arm so that there are 2-3 links of slack.
4. Remove crankstand from a-frame. ground. 6. Remove weather covers and connect both electrical plugs. 5. Attach crankstand to lift frame. 6. Remove weather covers and connect both electrical plugs. Meyer Products assumes no responsibility for installations not made in accordance with these instructions.
8. Back vehicle away from plow assembly. 6. Remove hair pin and pull out receiver hitch pin. 7. Disconnect both electrical plugs and install weather cover on both ends. Meyer Products assumes no responsibility for installations not made in accordance with these instructions.
