PILOT OPERATING HANDBOOK
ALPHA Trainer LSA
Document No.: POH-162-00-40-001*
REVISION A00
Date of Issue: December 3
, 2019
rd
*applicable to all ALPHA Trainer aircraft, from serial number 996 AT
912 LSA onwards, that are registered as an S-LSA or E-LSA (experi-
mental) airplane and have a MTOM of 550 kg.
Aircraft Serial Number: 1001 AT 912 LSA
Aircraft Registration Number: N221PF
PIPISTREL VERTICAL SOLUTIONS d.o.o.
Vipavska cesta 2
SI-5270 Ajdovščina
Slovenia
Tel: + 386 5 36 63 873
Fax: + 386 5 36 61 263
Email: info@pipistrel.si
All rights reserved. Reproduction or disclosure to third parties of this document or any
part thereof is not permitted, except with the prior and express written permission of
Pipistrel Group's R&D division, Pipistrel Vertical Solutions d.o.o., which is authorized to
publish technical documentation for Pipistrel Group's subsidiaries.
