Pilot's Operating Handbook
and Flight Training Supplement for
Alpha Electro
registered as LSA - 570 kg MTOM
Doc n. : POH-167-00-40-150
REV A00
(18
November, 2022)
th
SERIAL NUMBER
REGISTRATION NUMBER
For additional document applicability information, please refer to:
SB-160-00-80-999 Status of continuing airworthiness documentation
All rights reserved. Reproduction or disclosure to third parties of this document or any part thereof is not permitted,
except with the prior and express written permission of Pipistrel Group's R&D division, Pipistrel Vertical Solutions d.o.o.,
which is authorized to publish technical documentation for Pipistrel Group's subsidiaries.
