- Page 1 Indoor Unit Installation & Operation Manual Advanced Multi-split System Wall-mounted Indoor Unit MW(C)W509/512/518 R410A 200061350200 AMS-SVX03A-EN April 2012...
-
Page 2: Table Of Contents
Table of contents User notice Attentions Unit model Unit outline dimension Unit components and names Installation Electrical control wiring Indoor and outdoor unit communication wires specifi cation and attention Electrical parameters Electrical wiring diagram DIP setting Controller instruction LED light setting LED light setting instruction Defi... -
Page 3: User Notice
User notice • During operation, the total capacity of the indoor units operating at the same time shall not exceed the outdoor unit capacity. Otherwise, it will lead to inadequate indoor unit cooling (heating) capacity. • According to the capacity, install an air switch or fuse at each indoor unit and a main air switch for all indoor and outdoor units. -
Page 4: Attentions
• Do not repair the air conditioning unit by yourself. Improper repair may cause electric shock or fi re. If you need help, please contact Trane customer service center for repair. • Do not use fuse with improper capacity. Use iron wire replacing fuse may cause fault or fi... - Page 5 Attentions cause fi re or explosion. • Do not block the air outlet, otherwise it will reduce the unit effi ciency or lead to outage. Attention • Please verify the power supply meets requirements in the nameplate and check safety before installation.
-
Page 6: Unit Model
Unit model Model (Wall-mounted indoor unit) Model Additional option Service code Digit 1 M = Trane mini split unit Digit 2 W = Heat pump C = Cooling only Digit 3 W = Wall-mounted unit Digit 4 5 = Threaded connection... -
Page 7: Unit Outline Dimension
Unit outline dimension Model MW(C)W509 MW(C)W512 MW(C)W518 AMS-SVX03A-EN... -
Page 8: Unit Components And Names
Unit components and names Air inlet Wiring cover plate Strainer Panel Air guide slide Connecting pipe Air outlet Note: Appearances of air conditionings may differ by models. AMS-SVX03A-EN... -
Page 9: Installation
Pull the hanging plate to make sure it is fi xed after installation completed. Properly installed hanging plate can withstand 60kg and all fi xed screws are stressed uniformly. • Outlet pipe wall hole diameter: 50mm for MW(C)W509/512, and 65mm. for MW(C)W518. Outlet pipe wall hole Ø Drill piping hole •... - Page 10 Installation Drainage pipe installation • The drainage pipe should be inclined downward for water fl ow smoothly. Wrap the indoor drainage pipe with thermal insulation material. • The drainage pipe can not be twisted, bulged or waved etc. Do not insert the outlet port into water.
- Page 11 Installation Indoor unit installation • Wall-mounted unit pipe arrangement sees fi g. (a) and (b) below. Cut off piping blanking at the main unit base as needed (as shown in fi g. (c)) when arrange left or right pipe (wire). Cut off blanking 1 for leading power wires only.
-
Page 12: Electrical Control Wiring
Electrical control wiring Indoor and outdoor unit communication wires specifi cation and attention • Indoor and outdoor unit communication wires are provided by Trane. STP specifi cation is 0.5 1.25mm and the lay is less than 10cm. 10cm STP legend A: Outer sheath B: Shield layer C: Insulator D: Conductor •... -
Page 13: Electrical Parameters
Fan motor Rated Voltage Copper Frequency rated current Min. line Model voltage range core min. current diameter MW(C)W509 0.23 0.30 MW(C)W512 220~240 198~264 0.27 0.35 MW(C)W518 0.27 0.35 Note: • Choose power supply cable and wire in accordance with related local and national laws and regulations and specifi... -
Page 14: Electrical Wiring Diagram
Electrical wiring diagram Power supply Connect to other indoor or outdoor units Note: Communication wires Brown are assigned by users. It is recommended to use shield Blue Display board Communication twisted pair and pay attention wires to the polarity. Port A and B Yellow/green of two indoor units or indoor unit and outdoor unit can not... -
Page 15: Dip Setting
DIP setting Wall-mounted indoor unit PCB board DIP setting Indoor fan gear Indoor unit capacity DIP Reserved Reserved selection Indoor unit address DIP Reserved Reserved Test program Indoor unit capacity DIP According to the capacity, the indoor unit is divided into various models, such as 2.8kW, 3.6kW and 5.0kW etc. - Page 16 DIP setting Indoor unit address DIP Different indoor units must have different address DIP (Same indoor unit address DIP may cause confl icts). There are total 8 DIP switches for SW1 at the control board, S1, S2, S3 and S4 are address DIP switches as followings: Indoor unit address Note: 1.
-
Page 17: Controller Instruction
Controller instruction Remote controller front appearance and function buttons are as followings: On/Off Press this key to control On or Off of air conditioner (only the clock is displayed in Off state) Press the key ▲ or ▼ to increase or decrease current set Temperature setting temperature. -
Page 18: Led Light Setting
LED light setting LED light setting instruction There are 4 LED lights for the wall-mounted unit as shown below. They are heating , dry , cooling and run (power supply) . Numerical value displays in middle (display temperature and fault no. etc.) Defi... -
Page 19: Proper Use Method
Proper use method Set proper room temperature. Too low temperature is unhealthy. Clean the air strainer carefully. Please pull out the battery if the unit is unused for a long term. Avoid sunlight to lose cold air. • Adjust the setting temperature properly to save energy. Generally, indoor and outdoor temperature difference is 50C. -
Page 20: Maintenance
Maintenance Attention • Cleaning of air conditioning must be done with the unit stopped and its main power off, otherwise the risk of electric shock may be resulted in. • Never wet the air conditioning, otherwise the risk of electric shock may be resulted in. Make sure not fl... - Page 21 Maintenance Attention • Do not do cleaning with water hotter than 45 , otherwise the strainer may be discolored or distorted; • Do not dry a wet strainer over the fi re, otherwise it may catch fi re or become distorted. Installation Install the air strainer in arrow direction with the side marked [front] facing to you.
-
Page 22: Fault Analysis
Do not repair the air conditioning unit by yourself. Improper repair may cause electric shock or fi re. If you need help, please contact Trane customer service center, inviting professionals. Check followings may save your time and money before calling. - Page 23 April. 2012 Trane Supersedes www.trane.com For more information, contact your local Trane Trane has a policy of continuous product and product data improvement and reserves the right to office or e-mail us at comfort@trane.com change design and specifi cations without notice.
