u
Now any name can be entered for the
ThermoConnect TCon2 and be con-
firmed by clicking " ".
Step 4 of 4
ThermoConnect TCon2 is now connected
and ready for use. For more information,
see "https://www.webasto-comfort. com".
13.3 User management
More than one user may use ThermoCon-
nect TCon2. When adding new users (see
chapter 13.2 "Connect the mobile phone"
on page 8), an identification message is re-
quired from the new user. Existing users re-
ceive this message as a notification in their
ThermoConnect mobile app and must con-
firm or deny a new user. If the user gets a
new phone and tries to pair the mobile
phone without access to the previously
paired phone, the confirmation can be
done with the pushbutton: Press and hold
the pushbutton for 10 seconds to approve
a new user.
14 Statutory regulations
governing installation
Regula- Typ approval number
tion
ECE R10 E17 10 R - 050151
9040092C
The stipulations of these regulations are
binding in the area covered by EU Directive
70/156/EEC and/or 2007/46/EC (for new
vehicle models from 29/04/2009) and
should also be observed in countries where
there are no specific regulations. Failure to
follow the installation instructions and the
notes contained therein will lead to all liab-
ility being refused by Webasto.
WEEE directive This product
must not be disposed of with
normal household rubbish.
Dispose of this product according to the
applicable rules and regulations. Informa-
tion about proper disposal is provided by
the municipal authorities, the responsible
household waste recycling centre and/or
your local distribution partner.
15 CE-declaration of
conformity
Hereby, Webasto declares that the radio
equipment type ThermoConnect TCon2 is
in compliance with the Directive 2014/53/
EU. The full text of the EU declaration of
conformity is available under
https://dealers.webasto.com at "Webasto
Technical Service". Select product type
"Control Elements" and product "Thermo-
Connect".
16

Technical data

ThermoConnect TCon2 Values
Operating voltage [V] 9 to 32
Current consumption < 5 (no-load
[mA] current)
Operating/storage tem- -40 to +80
perature for receiver [ºC]
17

Dimensions

112
18
70
Fig. 16
All dimensions specified in mm.
EN
WHE000028A
9
