Freescale Semiconductor

Rev. 0.0, 08/25/2004

Quick Start Guide

DEMO908GZ60 Quick Start Guide

Introduction and Default Settings

This kit contains everything you need to get started minus the +9 VDC power supply. This guide will walk

you though how to connect the board to your PC, run the pre-programmed LED test, install the correct

version of CodeWarrior Development Studio, and load an ATD (Analog to Digital) test program. Source

code for DEMO908GZ60_LED (LED test) and DEMO908GZ60_ATD (ATD test) are provided on the

Axiom CD in the "Examples" folder.

Below are diagrams of the default settings for the DEMO908GZ60 demo board. Please refer to the

DEMO908GZ60 User's Guide on the Axiom CD for information on other configurations. All diagrams in

this guide are oriented with the MON08 header in the bottom right-hand corner. Black blocks indicate the

"on" or "installed" position of jumpers. Please check the settings before continuing.

Figure 1

DEMO908GZ60 Default Settings

Page 1 DEMO908GZ60_LED (LED test) and DEMO908GZ60_ATD (ATD test) are provided on the Axiom CD in the “Examples” folder. Below are diagrams of the default settings for the DEMO908GZ60 demo board. Please refer to the DEMO908GZ60 User’s Guide on the Axiom CD for information on other configurations. All diagrams in this guide are oriented with the MON08 header in the bottom right-hand corner.
Page 2 2. If you have not already done so, connect serial cable and apply power to the board. 3. In the working folder on the desktop, double click on the “DEMO908GZ60.mcp” project file. The CodeWarrior IDE will launch.
Page 3 Make sure the COM port matches the serial port in “Attempting to contact target and pass security…” window. • Make sure the supply voltage connected to the terminal power block is +9 VDC. DEMO908GZ60 Quick Start Guide, Rev. 0.0 Freescale Semiconductor...
Page 4 “Typicals” must be validated for each customer application by customer’s technical experts. Asia/Pacific: Freescale Semiconductor does not convey any license under its patent rights nor the rights of others. Freescale Semiconductor H.K. Ltd. Freescale Semiconductor products are not designed, intended, or authorized for use as components...
