Users Guide
DSPAUDIOEVM Users Guide
This document contains information on a new product. Specifications and
information herein are subject to change without notice.
© Freescale Semiconductor, Inc., 2004. All rights reserved.
DSPAUDIOEVMUG
Rev. 2.4, 08/2004

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DSPAUDIOEVM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Freescale Semiconductor DSPAUDIOEVM

Summary of Contents for Freescale Semiconductor DSPAUDIOEVM

  • Page 1 Freescale Semiconductor DSPAUDIOEVMUG Users Guide Rev. 2.4, 08/2004 DSPAUDIOEVM Users Guide This document contains information on a new product. Specifications and information herein are subject to change without notice. © Freescale Semiconductor, Inc., 2004. All rights reserved.

  • Page 3: Table Of Contents

    JP11 - Clock Selection ..............................9 Daughterboard Audio I / O and Clock Control Header ....................9 DSPAUDIOEVM Users Guide, Rev. 2.4 This document contains information on a new product. Specifications and information herein are subject ot change without notice. Freescale Semiconductor...
  • Page 4 JP11 – DSP Mute Control ...........................16 5.5.12 JP13 – I2C Boot ROM Enable ..........................16 DSPAUDIOEVM Users Guide, Rev. 2.4 This document contains information on a new product. Specifications and information herein are subject ot change without notice. TOC-2 Freescale Semiconductor...
  • Page 5 DSP56371 Daughterboard Schematics ........................33 DSP56374 Daughterboard Schematics ........................35 Appendix B EVM Bill of Materials DSPAUDIOEVM Users Guide, Rev. 2.4 This document contains information on a new product. Specifications and information herein are subject ot change without notice. Freescale Semiconductor TOC-3...
  • Page 6 Table Of Contents Notes DSPAUDIOEVM Users Guide, Rev. 2.4 Freescale Semiconductor...

  • Page 7: Chapter 1 Overview

    DSPAUDIOEVM Architecture The DSPAUDIOEVM system is a development tool for authoring and testing of Digital Audio DSP software. It can also be used as a demo platform for Motorola’s digital audio DSP technologies. The EVM system consists of a motherboard and a daughterboard (Ordered separately).

  • Page 8: Microcontrollers

    To use the headphone output select the desired analog output signals using the left and right channel select switches (SW2/SW3) and adjust the left and right volume sliders (RV3/RV4). DSPAUDIOEVM Users Guide, Rev. 2.4 This document contains information on a new product. Specifications and information herein are subject ot change without notice.

  • Page 9: Chapter 2 Motherboard

    Motorola DSP with a specific audio codec. DSPAUDIOEVM Users Guide, Rev. 2.4 This document contains information on a new product. Specifications and information herein are subject ot change without notice.

  • Page 10: Debugger And Microcontroller Configuration

    OnCE/JTAG debugger interface to the board. The USB/RS232 option is not currently supported and only one jumper should be inserted at a time. DSPAUDIOEVM Users Guide, Rev. 2.4 This document contains information on a new product. Specifications and information herein are subject ot change without notice.

  • Page 11: Jp10 - Config / Debug Mpu Communication

    DSP users guides. Note that when using an external OnCE/JTAG debugger tool, the JP9 JTAG jumper should be in the "OnCE" position. DSPAUDIOEVM Users Guide, Rev. 2.4 This document contains information on a new product. Specifications and information herein are subject ot change without notice.

  • Page 12: P3 - Analog I/O

    Section 2.2.4, Debugger and Microcontroller Configuration for the proper jumper settings to use this interface. DSPAUDIOEVM Users Guide, Rev. 2.4 This document contains information on a new product. Specifications and information herein are subject ot change without notice. Freescale Semiconductor...

  • Page 13: J3 - Rs232 Interface

    Right Surround AOUT3 WHITE Center AOUT3 RED Subwoofer AOUT4 WHITE Left Back AOUT4 RED Right Back DSPAUDIOEVM Users Guide, Rev. 2.4 This document contains information on a new product. Specifications and information herein are subject ot change without notice. Freescale Semiconductor...

  • Page 14: J13 - Headphone Outputs

    * These modes are only applicable to DSPs which have the embedded ROM based Software Architecture (SA). NOTE All other modes are reserved and should not be used. DSPAUDIOEVM Users Guide, Rev. 2.4 This document contains information on a new product. Specifications and information herein are subject ot change without notice. Freescale Semiconductor...

  • Page 15: Memory

    Position C forces the mode to be asynchronous, and no jumper forces synchronous mode. In synchronous mode FST is connected to FSR, and SCKT is connected to SCKR on the ESAI port of the DSP. DSPAUDIOEVM Users Guide, Rev. 2.4 This document contains information on a new product. Specifications and information herein are subject ot change without notice.

  • Page 16: Jp2 – Single/Double Speed Clocking Control

    Q position feeds the SDI1 signal from ADC1. There is no available jumper setting for use of the SDO4 signal. DSPAUDIOEVM Users Guide, Rev. 2.4 This document contains information on a new product. Specifications and information herein are subject ot change without notice.

  • Page 17: Dspx37Xdb1

    EXT – Clock DSP from motherboard 24.576MHz clock source Only one of the JP1 options should be populated at the same time. DSPAUDIOEVM Users Guide, Rev. 2.4 This document contains information on a new product. Specifications and information herein are subject ot change without notice.

  • Page 18: Daughterboard Audio I / O And Clock Control Header

    A jumper in position L feeds the SDI0 signal from the ADC2 microphone source. A jumper in the M position feeds the SDO5 signal to DAC4_6. DSPAUDIOEVM Users Guide, Rev. 2.4 This document contains information on a new product. Specifications and information herein are subject ot change without notice.

  • Page 19: Jp11 - Sdo4/Sdi1 Configuration

    This header allows for external connections to ESAI and ESAI_1 transmitter signals and GPIO. The odd row is ground while the even row of pins is signal. This provides ground isolation between each signal when used with ribbon cable connectors. DSPAUDIOEVM Users Guide, Rev. 2.4 This document contains information on a new product. Specifications and information herein are subject ot change without notice.

  • Page 20: Dspx374Db1

    XTAL jumpers must be removed. Only one clocking mode should be used at the same time DSPAUDIOEVM Users Guide, Rev. 2.4 This document contains information on a new product. Specifications and information herein are subject ot change without notice.

  • Page 21: Daughterboard Audio I/O And Clock Control Header

    (SDO3) or an input (SDI1). A jumper in position L feeds the SDI1 signal from the ADC2 microphone source. A jumper in position M feeds the SDO3 signal to DAC 4-6. DSPAUDIOEVM Users Guide, Rev. 2.4 This document contains information on a new product. Specifications and information herein are subject ot change without notice.

  • Page 22: Jp14 - S/Pdif Lock Control

    This header allows for external connections to ESAI and ESAI_1 transmitter signals and GPIO. The odd row is ground while the even row of pins is signal. This provides ground isolation between each signal when used with ribbon cable connectors. DSPAUDIOEVM Users Guide, Rev. 2.4 This document contains information on a new product. Specifications and information herein are subject ot change without notice.

  • Page 23: Appendix A Schematics

    Motherboard Schematics Appendix A Schematics Motherboard Schematics Figure A-1. Motherboard Block Diagram DSPAUDIOEVM Users Guide, Rev. 2.4 This document contains information on a new product. Specifications and information herein are subject ot change without notice. Freescale Semiconductor...
  • Page 24 Motherboard Schematics Figure A-2. Motherboard DACA 1-3 DSPAUDIOEVM Users Guide, Rev. 2.4 This document contains information on a new product. Specifications and information herein are subject ot change without notice. Freescale Semiconductor...
  • Page 25 Motherboard Schematics Figure A-3. Motherboard DACB 4-6 DSPAUDIOEVM Users Guide, Rev. 2.4 This document contains information on a new product. Specifications and information herein are subject ot change without notice. Freescale Semiconductor...
  • Page 26 Motherboard Schematics Figure A-4. Motherboard ADC 1-2 DSPAUDIOEVM Users Guide, Rev. 2.4 This document contains information on a new product. Specifications and information herein are subject ot change without notice. Freescale Semiconductor...
  • Page 27 Motherboard Schematics Figure A-5. Motherboard Configuration MPU DSPAUDIOEVM Users Guide, Rev. 2.4 This document contains information on a new product. Specifications and information herein are subject ot change without notice. Freescale Semiconductor...
  • Page 28 Motherboard Schematics Figure A-6. Motherboard Headphone Amplifier and Mixer DSPAUDIOEVM Users Guide, Rev. 2.4 This document contains information on a new product. Specifications and information herein are subject ot change without notice. Freescale Semiconductor...
  • Page 29 Motherboard Schematics Figure A-7. Motherboard SPDIF DSPAUDIOEVM Users Guide, Rev. 2.4 This document contains information on a new product. Specifications and information herein are subject ot change without notice. Freescale Semiconductor...
  • Page 30 Motherboard Schematics Figure A-8. Motherboard PPI and JTAG Command Converter DSPAUDIOEVM Users Guide, Rev. 2.4 This document contains information on a new product. Specifications and information herein are subject ot change without notice. Freescale Semiconductor...
  • Page 31 Motherboard Schematics Figure A-9. Motherboard JTAG/PPI Debugger MPU DSPAUDIOEVM Users Guide, Rev. 2.4 This document contains information on a new product. Specifications and information herein are subject ot change without notice. Freescale Semiconductor...
  • Page 32 Motherboard Schematics Figure A-10. Motherboard DSP Daughterboard Connectors DSPAUDIOEVM Users Guide, Rev. 2.4 This document contains information on a new product. Specifications and information herein are subject ot change without notice. Freescale Semiconductor...
  • Page 33 Motherboard Schematics Figure A-11. Motherboard Power and MCLK Lost Detect and Systems Reset DSPAUDIOEVM Users Guide, Rev. 2.4 This document contains information on a new product. Specifications and information herein are subject ot change without notice. Freescale Semiconductor...
  • Page 34 Motherboard Schematics Figure A-12. Motherboard Notes and Tables DSPAUDIOEVM Users Guide, Rev. 2.4 This document contains information on a new product. Specifications and information herein are subject ot change without notice. Freescale Semiconductor...

  • Page 35: Dsp5636X Daughterboard Schematics

    DSP5636x Daughterboard Schematics DSP5636x Daughterboard Schematics Figure A-13. DSP5636x Daughterboard DSP Connections for DSP56362/366/367 DSPAUDIOEVM Users Guide, Rev. 2.4 This document contains information on a new product. Specifications and information herein are subject ot change without notice. Freescale Semiconductor...
  • Page 36 DSP5636x Daughterboard Schematics Figure A-14. DSP5636x Daughterboard DSP Connections for DSP56364 DSPAUDIOEVM Users Guide, Rev. 2.4 This document contains information on a new product. Specifications and information herein are subject ot change without notice. Freescale Semiconductor...
  • Page 37 DSP5636x Daughterboard Schematics Figure A-15. DSP5636x Daughterboard External Memory DSPAUDIOEVM Users Guide, Rev. 2.4 This document contains information on a new product. Specifications and information herein are subject ot change without notice. Freescale Semiconductor...
  • Page 38 DSP5636x Daughterboard Schematics Figure A-16. DSP5636x Daughterboard Connectors DSPAUDIOEVM Users Guide, Rev. 2.4 This document contains information on a new product. Specifications and information herein are subject ot change without notice. Freescale Semiconductor...

  • Page 39: Dsp56371 Daughterboard Schematics

    DSP56371 Daughterboard Schematics DSP56371 Daughterboard Schematics Figure A-17. DSP56371 Daughterboard DSP Connections DSPAUDIOEVM Users Guide, Rev. 2.4 This document contains information on a new product. Specifications and information herein are subject ot change without notice. Freescale Semiconductor...
  • Page 40 DSP56371 Daughterboard Schematics Figure A-18. DSP56371 Daughterboard Connectors DSPAUDIOEVM Users Guide, Rev. 2.4 This document contains information on a new product. Specifications and information herein are subject ot change without notice. Freescale Semiconductor...

  • Page 41: Dsp56374 Daughterboard Schematics

    DSP56374 Daughterboard Schematics DSP56374 Daughterboard Schematics Figure A-19. DSP56374 Daughterboard 80-pin DSP Connections DSPAUDIOEVM Users Guide, Rev. 2.4 This document contains information on a new product. Specifications and information herein are subject ot change without notice. Freescale Semiconductor...
  • Page 42 DSP56374 Daughterboard Schematics Figure A-20. DSP56374 Daughterboard 52-pin DSP Connections DSPAUDIOEVM Users Guide, Rev. 2.4 This document contains information on a new product. Specifications and information herein are subject ot change without notice. Freescale Semiconductor...
  • Page 43 DSP56374 Daughterboard Schematics Figure A-21. DSP56374 Daughterboard Connectors DSPAUDIOEVM Users Guide, Rev. 2.4 This document contains information on a new product. Specifications and information herein are subject ot change without notice. Freescale Semiconductor...

  • Page 44: Appendix Bevm Bill Of Materials

    0.1UF10% X7R 0805 50V Ceramic Chip Capacitor Venkel 18PF C080COG500-180JNE 18 PF 5% COG 0805 50V Ceramic Chip Capacitor Venkel DSPAUDIOEVM Users Guide, Rev. 2.4 This document contains information on a new product. Specifications and information herein are subject ot change without notice. Freescale Semiconductor...
  • Page 45 0.1UF10% X7R 0805 50V Ceramic Chip Capacitor Venkel 4.7UF T491A475M016AS 4.7UF Tantalum Chip Capacitor 16V 3216 Kemet DSPAUDIOEVM Users Guide, Rev. 2.4 This document contains information on a new product. Specifications and information herein are subject ot change without notice. Freescale Semiconductor...
  • Page 46 150 PF 5% COG 0805 100V Ceramic Chip Capacitor Venkel C148 0.1UF C0805X7R500-104KNE 0.1UF10% X7R 0805 50V Ceramic Chip Capacitor Venkel DSPAUDIOEVM Users Guide, Rev. 2.4 This document contains information on a new product. Specifications and information herein are subject ot change without notice. Freescale Semiconductor...
  • Page 47 96-pin 3-row DIN41612 Female Type C Straight Connector .110" Teka Tail Length JE040060BN 2 X 2 RCA Jack All Black Nickel Plated Vimex DSPAUDIOEVM Users Guide, Rev. 2.4 This document contains information on a new product. Specifications and information herein are subject ot change without notice. Freescale Semiconductor...
  • Page 48 FMMTA06 NPN Transistor SOT23 Zetex FMMTA06 NPN Transistor SOT23 Zetex FMMTA06 NPN Transistor SOT23 Zetex DSPAUDIOEVM Users Guide, Rev. 2.4 This document contains information on a new product. Specifications and information herein are subject ot change without notice. Freescale Semiconductor...
  • Page 49 200 1% 0805 .1 W Thick Film Chip Resistor Venkel CR0805-10W-2000FT 200 1% 0805 .1 W Thick Film Chip Resistor Venkel DSPAUDIOEVM Users Guide, Rev. 2.4 This document contains information on a new product. Specifications and information herein are subject ot change without notice. Freescale Semiconductor...
  • Page 50 100K 1% 0805 .1 W Thick Film Chip Resistor Venkel CR0805-10W-1002FT 10K 1% 0805 .1 W Thick Film Chip Resistor Venkel DSPAUDIOEVM Users Guide, Rev. 2.4 This document contains information on a new product. Specifications and information herein are subject ot change without notice. Freescale Semiconductor...
  • Page 51 100K 1% 0805 .1 W Thick Film Chip Resistor Venkel R148 CR0805-10W-1002FT 10K 1% 0805 .1 W Thick Film Chip Resistor Venkel DSPAUDIOEVM Users Guide, Rev. 2.4 This document contains information on a new product. Specifications and information herein are subject ot change without notice. Freescale Semiconductor...
  • Page 52 24.9 1% 0805 .1 W Thick Film Chip Resistor Venkel R199 CR0805-10W-1002FT 10K 1% 0805 .1 W Thick Film Chip Resistor Venkel DSPAUDIOEVM Users Guide, Rev. 2.4 This document contains information on a new product. Specifications and information herein are subject ot change without notice. Freescale Semiconductor...
  • Page 53 R250 4.99K RR1220P-4991-D-M 4.99K 0.5% 0805 .1 W Thin Film Chip Resistor Susumu Co Ltd DSPAUDIOEVM Users Guide, Rev. 2.4 This document contains information on a new product. Specifications and information herein are subject ot change without notice. Freescale Semiconductor...
  • Page 54 3.57K 1% 0805 .1 W Thick Film Chip Resistor Venkel R301 3.57K CR0805-10W-3571FT 3.57K 1% 0805 .1 W Thick Film Chip Resistor Venkel DSPAUDIOEVM Users Guide, Rev. 2.4 This document contains information on a new product. Specifications and information herein are subject ot change without notice. Freescale Semiconductor...
  • Page 55 1:1 Wide Band RF Transformers Surface Mount Coilcraft TTWB1010 1:1 Wide Band RF Transformers Surface Mount Coilcraft DSPAUDIOEVM Users Guide, Rev. 2.4 This document contains information on a new product. Specifications and information herein are subject ot change without notice. Freescale Semiconductor...
  • Page 56 High Performance Low Noise Dual Operational Amplifier DMP8, Philips SOIC-8 AK5380VT 96KHz 24-Bit ADC with Single-ended Input 16 pin TSSOP DSPAUDIOEVM Users Guide, Rev. 2.4 This document contains information on a new product. Specifications and information herein are subject ot change without notice. Freescale Semiconductor...
  • Page 57 HCM49 Series Surface Mount Crystals 11.0592MHZ Citizen America 12.000MHZ HCM49-12.000MABJT HCM49 Series Surface Mount Crystals 12.000MHZ Citizen America DSPAUDIOEVM Users Guide, Rev. 2.4 This document contains information on a new product. Specifications and information herein are subject ot change without notice. Freescale Semiconductor...
  • Page 58 56362 http://e-www.motorola.com/brdata/PDFDB/docs/DSP56362.pdf http://e-www.motorola.com/brdata/PDFDB/docs/DSP56362UM.pdf 56364 http://e-www.motorola.com/brdata/PDFDB/docs/DSP56364.pdf http://e-www.motorola.com/brdata/PDFDB/docs/DSP56364UM.pdf 56366 http://e-www.motorola.com/brdata/PDFDB/docs/DSP56366.pdf http://e-www.motorola.com/brdata/PDFDB/docs/DSP56366UM.pdf 56367 http://e-www.motorola.com/brdata/PDFDB/docs/DSP56367UM.pdf AKM parts www.akm.com DSPAUDIOEVM Users Guide, Rev. 2.4 This document contains information on a new product. Specifications and information herein are subject ot change without notice. Freescale Semiconductor...
  • Page 59 DSP56374 Daughterboard Schematics DSPAUDIOEVM Users Guide, Rev. 2.4 This document contains information on a new product. Specifications and information herein are subject ot change without notice. Freescale Semiconductor...
  • Page 60 LDCForFreescaleSemiconductor@hibbertgroup.com or other applications intended to support or sustain life, or for any other application in which the failure of the Freescale Semiconductor product could create a situation where personal injury or death may occur. Should Buyer purchase or use Freescale Semiconductor products for any such unintended...
