Carf-Models EXTRA 330SC Building Instruction page 16

Wings Pack
Quantity Description
8 Sheetmetal screws, 2.9 x 16mm
8 Sheetmetal screws, 2.9 x 13mm
2 Allen bolts, M3 x 16mm
2 Stop Nuts, M3
4 Nut; M3
2 Aluminium Clevise; M3 (with aluminium pin E-clip)
2 All thread, M3 x 50mm
2 Ball-links; M3
Elevators & Stabs Pack
Quantity Description
2 Aluminium Clevise; M3 (with aluminium pin E-clip
4 Nut, M3
2 All thread, M3 x 60mm
2 Ball-links, M3
8 Sheetmetal screws, 2.9 x 16mm
2 Stop Nut, M3
2 Allen bolt, M3 x 16mm
2 Allen bolt, M3 x 12mm
Rudder Pack
Quantity Description
4 Sheetmetal screws, 2.9 x 16mm
4 Allen bolt, M3 x 16mm
4 Stop Nut, M3
4 Nut, M3
4 Ball-link, M3
4 Threaded ends for cables, M3
EXTRA 330SC 2.3m
)
