ElMod ThinkTank Tank Module PRO II Instructions For Assembly And Handling

• ThinkTank tank module PRO II PCB
• ready to use power supply cable set
• motor connectors
• proportional receiver cable set
• two cables for additional light

1 Power supply

2 Fuse for turret elements
3 Connector for left chain motor
4 Connector for right chain motor
5 Setup mode push button
6 DIP-switches for selecting the tank profile
7 Connector for HengLong
Configurator
8 Connector for HengLong
9 Connector for turret elements
10 Connector for Tamiya ® recoil unit
11 Connector for proportional receiver
12 Servo motors connectors.
13 Main gun muzzle flash LED (also muzzle flash for 1
14 Brake light LED
15 Auxiliary light
16 Muzzle flash LED for 2
nd
L Status LED
Solder the loose ends of the power supply cable to a battery connector that fits to your battery type. Use the included shrinking tube to
insulate the soldered wires.
Use the included plugs to connect the motors to the board. Keep the wires as short as possible.
To check the correct wiring of the motors perform the following procedure:
• Jack the tank up, so that the chains can move freely.
• Attach a full charged battery to the power supply connector and switch the electronics on.
• Wait 3 - 4 seconds and press the pushbutton.
• The chains start to move. They change the running direction every 4 seconds. Release the button when both chains move forwards and
the light chain runs faster than the left one.
• Go ahead with the installation when the motors run in described manner.
Connect the white 8-pin turret plug to the corresponding connector.
• If using the genuine HengLong
• If using the genuine AsiaTam
manual of the units.
• If using the genuine Tamiya
faces the edge of the board.
• Servo motors are connected as shown on the picture.
• Additional light sources may be connected to the plugs 13 to 16. They provide about 50mA each and are
designed to drive one to four LEDs.
Please read this document carefully!
® muzzle flash, AsiaTam ® recoil unit and PC
muzzle flash
®
MG (also muzzle flash for 2
HINT: The function of all connectors is printed on the back side of the PCB!
Warning! The use of the switch and fuse is mandatory! Fire hazard when disregarded!

Turret elements

LED muzzle flash, attach it's cables (a 5-wire and a 2-wire cable) to the board.
®
turret mechanics and high voltage muzzle flash, proceed as described in the
®
® recoil unit, attach it to the corresponding connector on the board. The white cable
ThinkTank Tank Module PRO II
Instructions for Assembly and Handling

Product contents

Overview

st barrel for AA tanks)
barrel for twin barreled AA tanks)
nd

Assembly

Power supply

Chain motors
