EXPEDITION II AUSTRALIAN
WOOD INSERT
AUTOMATIC COMBUSTION
CONTROL (ACC)
MODEL NUMBER:
EXPEDITIONII-AU
1
Installation Manual
Installation & Appliance Set-Up
NOTICE: DO NOT DISCARD THIS MANUAL
Quadrafire • Expedition II AU Install Manual_Rev B • 2020 - ___ • 09/20
R
If the information in these instructions is
not followed exactly, a fire could result
causing property damage, personal injury,
or death.
•
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
•
Do not over fire - If appliance or chimney connector
glows, you are over firing. Over firing will void
your warranty.
•
Comply with all minimum clearances to combustibles
as specified.
Failure to comply may cause house fire.
Hot glass and appliance will cause burns.
•
Do not touch glass until it is cooled
•
Use leather gloves when reloading fuel
•
NEVER allow children to touch glass
•
Keep children away
•
CAREFULLY SUPERVISE children in same room
as appliance.
•
Alert children and adults to hazards of high
temperatures
•
High temperatures may ignite clothing or other
flammable materials.
•
Keep clothing, furniture, draperies and other
flammable materials away.
Fire Risk.
For use with solid wood fuel only.
Other fuels may over fire and generate
poisonous gases (i.e. carbon monoxide).
!
WARNING
!
WARNING
HOT SURFACES!
Glass and other surfaces are hot during
operation AND cool down.
!
WARNING
7095-818
Advertisement
Table of Contents
Related Manuals for Hearth and Home Technologies Quadra-Fire EXPEDITIONII-AU
Summary of Contents for Hearth and Home Technologies Quadra-Fire EXPEDITIONII-AU
- Page 1 Installation Manual Installation & Appliance Set-Up INSTALLER: Leave this manual with party responsible for use and operation. OWNER: Retain this manual for future reference. NOTICE: DO NOT DISCARD THIS MANUAL WARNING If the information in these instructions is not followed exactly, a fire could result EXPEDITION II AUSTRALIAN causing property damage, personal injury, WOOD INSERT...
-
Page 2: Table Of Contents
Safety Alert Key: • DANGER! Indicates a hazardous situation which, if not avoided will result in death or serious injury. • WARNING! Indicates a hazardous situation which, if not avoided could result in death or serious injury. • CAUTION! Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury. •... -
Page 3: Important Safety Information
Important Safety Information A. Insert Certification C. Glass Specifications This appliance is equipped with 5mm ceramic glass. Model: EXPEDITIONII-AU Replace glass only with 5mm ceramic glass. Please contact Laboratory: ASFT your dealer for replacement glass. Report No: ASFT20046 Improper installation, adjustment, alteration, service or Type: Hardwood only at 25% dry basis maintenance can cause injury or property damage. -
Page 4: Getting Started
Getting Started A. Design and Installation Considerations NOTICE: Hearth & Home Technologies assumes no responsibility for the improper performance of Consideration must be given to: the appliance system caused by: Safety • Inadequate draft due to environmental conditions Convenience • Down drafts Traffic flow •... -
Page 5: Negative Pressure
C. Negative Pressure D. Tools And Supplies Needed Before beginning the installation be sure the following tools WARNING and building supplies are available: Reciprocating saw Asphyxiation Risk. Pliers • Negative pressure can cause spillage Hammer combustion fumes, soot Phillips screwdriver carbon monoxide. -
Page 6: Install Checklist
F. Install Checklist ATTENTION INSTALLER: Follow this Standard Work Checklist This standard work checklist is to be used by the installer in conjuction with, not instead of, the instructions contained in this installation manual. _________________________________________________________________________________ Customer: ______________________________________________________________________________ Date Installed: ______________________________________________________________________________ Lot / Address: ________________________________________________________________________ Location of Appliance:... -
Page 7: Dimensions And Clearances
Dimensions and Clearances A. Appliance Dimensions 31-1/2 in (800mm) 31-1/2 in (800mm) 31-1/2 in (800mm) 31-1/2 in (800mm) 23-5/8 in (600mm) 23-5/8 in (600mm) 23-5/8 in (600mm) 23-5/8 in (600mm) 18 in 18 in 17-1/4 in 17-1/4 in (457mm) (457mm) (438mm) (438mm) 2-3/8 in... - Page 8 13-1/4 in 13-1/4 in (337mm) (337mm) 14 in 14 in (356mm) (356mm) 23-1/8 in 23-1/8 in 15° 15° 23-1/8 in 23-1/8 in 15° 15° (589mm) (589mm) (589mm) (589mm) 23-3/4 in 23-3/4 in 23-3/4 in 23-3/4 in (604mm) (604mm) (604mm) (604mm) Figure 3.7 - Side View with Flat Surround Figure 3.10 - Side View with Cast Surround 13-3/8 in...
-
Page 9: Clearances To Combustibles
Triple Skin Flue B. Clearances to Combustibles Triple Skin THESE MEASUREMENTS ARE FOR WHEN USING THE OPTIONAL ZERO CLEARANCE BOX - PLEASE REFER TO Flue ADDTIONAL MANUAL. Triple Skin Flue 100mm Gap Mantel Shelf 575mm 100mm Gap Mantel Shelf 575mm Mantel Key 525mm Mantel Key 525mm 300mm... - Page 10 TOP TRIM (3/4” max depth) 1647mm 547mm 1110mm Figure 3.18 Minimum Opening Dimensions Millimeters HEARTH EXTENSION (MINIMUM EMBER PROTECTION) Height 1220mm Front Width Back Width Figure 3.16 Depth (Steel Surround) NOTE: If trim measurement is over 76mm in depth use Depth (Cast Surround) mantle or side clearances to combustibles.
- Page 11 WARNING Fire Risk. • Comply with all minimum clearances to combustibles as specified. • Failure to comply may cause house fire. 2- 15mm layers of compressed cement sheets or similar material with a thermal conductivity of 0.003m2/kw Figure 3.20 Quadrafire • Expedition II AU Install Manual_Rev B • 2020 - ___ • 09/20 7095-818...
-
Page 12: Chimney Systems
Chimney Systems A. Locating Your Appliance & Chimney • Consider the appliance location in order to avoid floor and ceiling attic joists and rafters. Location of the appliance and chimney will affect • Locate termination cap away from trees, adjacent performance. -
Page 13: Minimum Height Of Flue System Exit
B. Minimum Height of Flue System Exit 3000mm more than 3000mm or less 600mm 6000mm minimum 3000mm increase from 1000mm minimum until clear within 3000mm of flue top increase as necessary until nothing within 3000mm of fluetop any nearby structure Figure 4.2 NOTICE: NOTICE: Locating the appliance in a basement or in a... -
Page 14: Venting Systems
D. Venting Systems Chimney Connector: It is also known as flue pipe or stove pipe. It must be 152mm minimum diameter stainless steel connector pipe. (Solid or Flex and must run the entire chimney) Chimney: The chimney can be new or existing, masonry or prefabricated and must meet the following minimum requirements as specified below. -
Page 15: Masonry Chimney
G. Masonry Chimney • Must have at least 16mm fire clay lining joined with refractory cement. NOTE: Installations into a clay flue without a stainless steel liner may reduce draw which affects performance, will cause the glass to darken and produce excessive creosote and create start-up issues. •... -
Page 16: Install Into A Masonry Fireplace
H. Install into a Masonry Fireplace LINER CONNECTOR The insert must be installed as per the requirements of your local inspection authority. It is recommended to use a full liner as it is the safest installation and provides the most optimum performance. Your retailer should be able to help you decide which system would be the best for CRIMPED FLUE... -
Page 17: Zero-Clearance Fireplace
L. Zero-Clearance Fireplace N. Chimney Height / Rise and Run To be sure that your Quadra-Fire insert burns properly, the A permit may be required for installations, final approval is chimney draft (static pressure) should be approximately contingent of the authority having local jurisdiction. Consult -2.54mm water column (W.C.) during a high burn and insurance carrier, local building, fire officials or authorities -1.016mm W.C. -
Page 18: Appliance Set-Up
Appliance Set-Up A. Outside Air Kit A source of air (oxygen) is necessary in order for combustion to take place. Whatever combustion air is consumed by the fire must be replaced. Air is replaced via air leakage around windows and under doors. In homes that have tightly sealed doors and windows, an outside air source is needed. -
Page 19: Stove Pipe Or Liner To Flue Collar
B. Stove Pipe or Liner to Flue Collar D. Power Cord 1. There are 4 already drilled holes in the flue collar 90 The power cord is shipped assembled to the appliance. degrees apart. Attach the flue collar to the stove pipe/ You may route the power cord either to the left or right liner. -
Page 20: Flat Surround
4. Lift surround on to front of appliance (Figure 5.9). NOTE: These are generic drawings and may not represent your specific model. Top: over lip on top of F. Flat Surround appliance Overall Dimensions Part Number Standard Size 43” x 31” SP2-4331 Large Size 51”... -
Page 21: Flat Surround With Trim Kit
G. Flat Surround with Trim Kit 5. Install two steel springs at the top on each side and between the flat surround and the assembled trim kit as Overall Part shown in Figure 5.14. Trim Kit Dimensions Number Standard 43” x 31” SP2-4331 TRIMKIT-4331-NL Size Large... -
Page 22: Standard Surround & Cast Trim Kit
H. Standard Surround & Cast Trim Kit 6. Place the cast footers under the metal sides aligning the top and bottom holes in the cast footers and metal sides. Overall Dimensions Part Number 7. The 9 mounting clips are shipped in one long strip. Hand Standard break apart or use pliers. -
Page 23: Reference Materials
Reference Materials A. Service and Maintenance Log Date of Service Performed By Description of Service Quadrafire • Expedition II AU Install Manual_Rev B • 2020 - ___ • 09/20 7095-818... - Page 24 Date of Service Performed By Description of Service Quadrafire • Expedition II AU Install Manual_Rev B • 2020 - ___ • 09/20 7095-818...
-
Page 25: Service Parts List
Quadrafire • Expedition II AU Install Manual_Rev B • 2020 - ___ • 09/20 7095-818... - Page 26 CONTACT INFORMATION Hearth & Home Technologies 352 Mountain House Road Halifax, PA 17032 Division of HNI INDUSTRIES Please contact your Quadra-Fire dealer with any questions or concerns. For the number of your nearest Quadra-Fire dealer log onto www.quadrafi re.com CAUTION DO NOT DISCARD THIS MANUAL •...
