Summary of Contents for PCE Health and Fitness AM 85
- Page 1 User Manual PCE-AM 85 Air Flow Meter User manuals in various languages (français, italiano, español, português, nederlands, türk, polski, русский, 中文) can be found by using our product search on: www.pce-instruments.com Last change: 8 January 2021 v1.0 © PCE Instruments...
-
Page 2: Table Of Contents
Contents Safety notes ................... 1 Specifications ..................2 Delivery scope ..................2 System description ................3 Measuring functions ................3 Operation ....................4 Preparation ........................4 Functions ......................... 4 Measurement ........................5 Warranty ....................7 Disposal ....................7 © PCE Instruments... -
Page 3: Safety Notes
Safety notes Please read this manual carefully and completely before you use the device for the first time. The device may only be used by qualified personnel and repaired by PCE Instruments personnel. Damage or injuries caused by non-observance of the manual are excluded from our liability and not covered by our warranty. -
Page 4: Specifications
0 ... 50 °C / max. 80 % RH Dimensions 120 x 45 x 20 mm Weight approx. 160 g Delivery scope 1 x air flow meter PCE-AM 85, 1 x CR2032 battery, 1 x protective bag 1 x user manual © PCE Instruments... -
Page 5: System Description
System description ① ⑥ Vane Hand strap ② ⑦ LC display Short description of key function ③ ⑧ Hold key (freeze display) Pressure sensor barometer ④ ⑨ Power key (On) Battery compartment ⑤ REC key (recording min, max) Measuring functions Measuring function Display text Unit of measurement... -
Page 6: Operation
Operation Preparation Open the battery compartment on the back of the device by turning it slightly to the left and insert the CR 2032 3 V battery, observing correct polarity. Close the battery compartment. Functions 6.2.1 Switch on / off •... -
Page 7: Measurement
Measurement 6.3.1 Wind / air speed • Switch on the meter and select the wind / air speed measurement function as described above. • Select the desired units of measurement as described above. • Hold the meter in such a way that the vane is placed in wind direction. 6.3.2 Air pressure •... - Page 8 6.3.3 Altitude above sea level • Switch on the meter and select the function for the altitude above sea level measurement as described above. • Select the desired unit of measurement as described above. • Do not cover or enclose the opening of the pressure sensor on the back of the unit. This will lead to incorrect measurement results.
-
Page 9: Warranty
Warranty You can read our warranty terms in our General Business Terms which you can find here: https://www.pce-instruments.com/english/terms. Disposal For the disposal of batteries in the EU, the 2006/66/EC directive of the European Parliament applies. Due to the contained pollutants, batteries must not be disposed of as household waste. They must be given to collection points designed for that purpose. - Page 10 PCE Instruments contact information Germany France Spain PCE Deutschland GmbH PCE Instruments France EURL PCE Ibérica S.L. Im Langel 4 23, rue de Strasbourg Calle Mayor, 53 D-59872 Meschede 67250 Soultz-Sous-Forets 02500 Tobarra (Albacete) Deutschland France España Tel.: +49 (0) 2903 976 99 0 Téléphone: +33 (0) 972 3537 17 Tel.
