- Page 1 OPERATING INSTRUCTIONS Translation of the Original HIPACE Heating sleeve...
- Page 2 These operating instructions describe all models and variants of your product. Note that your product may not be equipped with all features described in this document. Pfeiffer Vacuum constantly adapts its products to the latest state of the art without prior notice. Please take into account that online operating instructions can deviate from the printed operating instructions supplied with your product.
-
Page 3: Table Of Contents
General safety information Safety instructions Safety precautions Limits of use of the product Proper use Foreseeable misuse Personnel qualification Product description Function Identifying the product Scope of delivery Installation Operation Service solutions by Pfeiffer Vacuum Technical data Declaration of conformity 3/20... -
Page 4: About This Manual
Keep the manual for future consultation. 1.1 Validity This operating instructions is a customer document of Pfeiffer Vacuum. The operating instructions de- scribe the functions of the named product and provide the most important information for the safe use of the device. The description is written in accordance with the valid directives. The information in this op- erating instructions refers to the product's current development status. -
Page 5: Stickers On The Product
About this manual Note 1.3.3 Stickers on the product This section describes all the stickers on the product along with their meaning. Rating plate (example) The rating plate is located on the relay box D-35641 Asslar Mod.-Nr.: PM 071 272 -T Input: 230 V 50/60 Hz Output:... -
Page 6: Safety
Safety 2 Safety 2.1 General safety information The following 4 risk levels and 1 information level are taken into account in this document. DANGER Immediately pending danger Indicates an immediately pending danger that will result in death or serious injury if not observed. ►... -
Page 7: Limits Of Use Of The Product
Tbl. 2: Permissible ambient and operating conditions 2.5 Proper use ► Use the heating sleeve exclusively for the baking out of Pfeiffer Vacuum turbopumps with a stain- less steel high vacuum flange. ► Adhere to the installation, commissioning, operating, and maintenance instructions. - Page 8 Safety 3. Only allow trained technical personnel to work with the product. 4. Before starting work, make sure that the commissioned personnel have read and understood these operating instructions and all applicable documents, in particular the safety, maintenance and repair information. 8/20...
-
Page 9: Product Description
Relay box 2 Heating sleeve 3.2 Identifying the product ► To ensure clear identification of the product when communicating with Pfeiffer Vacuum, always keep all of the information on the rating plate to hand. 3.3 Scope of delivery The scope of delivery includes the following parts: ●... -
Page 10: Installation
Installation 4 Installation Operational conditions for a housing heater Heating sleeves may only be used on turbopumps with a stainless steel high vacuum flange. Use of a housing heater is only permissible in conjunction with water cooling. ● Observe the maximum permissible flange temperature at the high vacuum connection to the vacuum system supplied by the customer. - Page 11 Installation 5 (2x) Fig. 5: Example: Assembling a heating sleeve on the HiPace 1200 1 Pump housing Heating relay box 2 Interior hexagon socket screw "Hot surface" warning sticker 3 Heating sleeve Assembling a heating sleeve 1. Carefully bend out the heating sleeve at the outer clamping strap. 2.
-
Page 12: Operation
Important settings and function-related variables programmed ex factory as parameters in the vacuum pump electronic drive unit. Each parameter has a three-digit number and a description. Parameter-driv- en operation and control is supported via Pfeiffer Vacuum displays and control units, or externally via RS-485 using Pfeiffer Vacuum protocol. -
Page 13: Service Solutions By Pfeiffer Vacuum
We are always focused on perfecting our core competence – servicing of vacuum components. Once you have purchased a product from Pfeiffer Vacuum, our service is far from over. This is often exactly where service begins. Obviously, in proven Pfeiffer Vacuum quality. - Page 14 Service solutions by Pfeiffer Vacuum 5. Prepare the product for transport in accordance with the provisions in the contamination declaration. a) Neutralize the product with nitrogen or dry air. b) Seal all openings with blind flanges, so that they are airtight.
-
Page 15: Technical Data
Technical data 7 Technical data Classification Heating sleeve for Hi- Heating sleeve for Heating sleeve for Pace® 80, 230 V AC HiPace® 80, 208 V HiPace® 80, 115 V Order number PM 061 360 -T PM 061 361 -T PM 061 362 -T Pump HiPace 80 with TC 110 HiPace 80 with TC... - Page 16 Technical data Classification Heating sleeve, Heating sleeve, Heating sleeve, screened, for HiPace screened, for HiPace screened, for HiPace 300, 230 V AC 300, 208 V AC 300, 115 V AC Power consumption 120 W 120 W 120 W of heating sleeve, max.
- Page 17 Technical data Classification Heating sleeve for HiPace Heating sleeve screened, for 350/450, 230 V AC HiPace 350/450, 115 V AC Order number PM 071 700 -T PM 071 705 -T Pump HiPace 350/450 with TC HiPace 350/450 with TC 400 110/120 Mains cable Type FR, DE...
- Page 18 Technical data Classification Heating sleeve, Heating sleeve, Heating sleeve, screened, for Hi- screened, for Hi- screened, for Hi- Pace® 2300/230 V AC Pace® 2300/208 V AC Pace® 2300, 115 V AC Power consumption of 450 W 450 W 450 W heating sleeve, max.
-
Page 19: Declaration Of Conformity
Harmonized standards and applied national standards and specifications: DIN EN 61000-3-2: 2014 DIN EN 61000-3-3: 2013 DIN EN 61010-1: 2010 DIN EN 61326-1: 2013 DIN EN 62061: 2005 Signature: Pfeiffer Vacuum GmbH Berliner Straße 43 35614 Asslar Germany (Daniel Sälzer) Aßlar, 2020-01-15 Managing Director...
