II.
Pre-assembly
1.
Assemble of
Set the universal joints (one is fixed with 2 x M3*10 inner hexagon screw
and another is fixed with 2 x M3 screw). The diagonal supporting arm is fixed
on universal joint (1 x M3*10 inner hexagon screw + 1 x M3 rubber-washer
screw). When the free joint can be assured, the gap should be as small as
possible.
the Universal arms
http://www.geeetech.com
20 / 31
