3.1

VARIOUS MODELS AND TERMS

3.2

SPECIFICATIONS

3.2.1

DEVICE SPECIFICATIONS

Model Name
Operating Flow Range
Maximum Flow Range
Minimum Flow Rate
Required to Connect
Waterway Diameter
Flow Accuracy
Non-recoverable Pressure
Loss @ Maximum Flow
Maximum Operating
Pressure
Hydrostatic Test Pressure
Operating Temperature -
Electronics
Length
Width
Weight
Materials
IP Rating
Power Supply
Backup Battery
©Copyright Task Force Tips LLC 2019-2021
OPERATING FLOW RANGE
50-300 GPM
(200-1200 LPM)
50 GPM (200 LPM)
Required to Connect
DO NOT EXCEED
350 GPM (1300 LPM)
MAXIMUM
OPERATING PRESSURE
300 PSI (20 BAR)
INLET THREADS
DIRECTION OF FLOW
SHO-FLOW 1
25-125 GPM
(100-500 L/min)
150 GPM
(600 L/min)
25 GPM
(100 L/min)
1.5" (38 mm)
10 PSI @ 125 GPM
(0.7 BAR @ 500 L/min)
6.3" (160 mm)
3.9" (99 mm)
2.8 lbs (1.3 kg)
Aluminum 6000 series hard anodized MIL8625 class 3 type 2, stainless steel 300 series,
®
50-300 GPM
(200-1200 LPM)
UNIQUE DEVICE NAME/SERIAL NUMBER
Figure 3.1
50-300 GPM
(200-1200 L/min)
350 GPM
(1300 L/min)
50 GPM
(200 L/min)
1.5" (38 mm)
+/-2.5% Full Scale
15 PSI @ 300 GPM
(1 BAR @ 1200 L/min)
300 PSI (20 bar)
900 PSI (62 bar)
-20-140°F
(-30-60°C)
rubber, and CPVC
IP65
Self-powered, Water Flow Energy Harvesting
CR2032 enabled in app
Table 3.2.1
5
QUICKSTART:
tft.com/SHO-FLOW
tft.com/EXXXXXX
DEVICE NAME
MADE IN USA
TFT.COM
PATENT PENDING
PATENT: 9,295,863
OUTLET THREADS
SHO-FLOW 2
100-500 GPM
(400-2000 L/min)
600 GPM
(2300 L/min)
100 GPM
(400 L/min)
2.5" (65 mm)
10 PSI @ 500 GPM
(0.7 BAR @ 2000 L/min)
7.4" (188 mm)
4.9" (125 mm)
4.2 lbs (1.9 kg)
500-1250 GPM
(2000-5000 L/min)
1350 GPM
(5200 L/min)
500 GPM
(2000 L/min)
2.5" (65 mm)
10 PSI @ 1250 GPM
(0.7 BAR @ 5000 L/min)
POM, nitrile
LIE-100 January 29, 2021 Rev06
