T14SG / FX-22 SOFTWARE UPDATE MANUAL
[Updating procedure]
1. SD card format
1. You will first want to format your SD card to the 14SG/
FX-22. If you are using an existing SD card, any data
previously saved to it will be deleted during the
"format". We suggest you either save this data on your
computer or purchase a new card.
T14SG:
① Push to open.
③ Battery cover will open downward.
②Slide in the direction of the
arrow on the battery cover.
FX-22:
① A side cover is opened.
2. After inserting the new SD card
into the transmitter, turn on the
power switch. You will see the
word "FORMAT" if you have not
previously used this card in the
transmitter.
3. Please select "YES" and touch
"RTN".
4. The following screen is displayed
during formatting.
5. When the format is completed,
the following screen is displayed.
6. Turn off the power switch and
remove the SD card from its slot.
SD card slot
④ SD card is inserted in a slot
by direction of a figure.
*It is releasable if a card is pushed once again.
SD card slot
*Don't mistake the
both sides/ the
② It inserts until it locks SD card into SD card slot.
*It is releasable if a card is pushed once again.

2. Preparing the software update card.

1. Please unzip the zipped file. The
following files will be created.
2. Insert the 'formatted" SD card into a card reader in your
PC.
3. Please run "T14sgUpdate.exe".
direction of
SD card.
4. Select the drive that your card reader is assigned to in
your PC.
5. After the Update files are copied to the SD card, the
following screens are displayed.
Click the "End" button.
- 1 -
・T14sgUpdate.exe
・T14sgUpdate.dat
・T14SG_UPDATE.dat
・T14SG_TS.bin
・T14SG_AP.bin
・T14SG_UPLD.bin
