T14SG SOFTWARE UPDATE MANUAL
[Updating procedure]
1. SD card format
1. You will first want to format your SD card to the 14SG. If you are using an existing
SD card, any data previously saved to it will be deleted during the "format". We
suggest you either save this data on your computer or purchase a new card.
① Push to open.
②Slide in the direction of the
arrow on the battery cover.
2. After inserting the new SD card into the transmitter, turn
on the power switch. You will see the word "FORMAT" if
you have not previously used this card in the transmitter.
3. Please select "YES" and touch "RTN" .
4. The following screen is displayed during
formatting.
5. When the format is completed, the following screen is
displayed.
6. Turn off the power switch and remove the SD card from
its slot.
2. Preparing the software update card.
1. Please unzip the zipped file. The following files will be created.
・T14sgUpdate.exe
・T14sgUpdate.dat
・T14SG_UPDATE.dat ... Identified file of T14SG
・T14SG_TS.bin
・T14SG_AP.bin
・T14SG_UPLD.bin
③ Battery cover will open downward.
... File copy utility
... Information file for T14sgUpdate.exe
... Update file of T14SG (piece 3)
... Update file of T14SG (piece 2)
... Update file of T14SG (piece 1)
-1-
SD card slot
④ Insert the SD card in the
slot as shown above.

Advertisement

loading
Need help?

Need help?

Do you have a question about the T14SG and is the answer not in the manual?

Questions and answers

Summary of Contents for FUTABA T14SG

  • Page 1 ... File copy utility ・T14sgUpdate.dat ... Information file for T14sgUpdate.exe ・T14SG_UPDATE.dat … Identified file of T14SG ・T14SG_TS.bin ... Update file of T14SG (piece 3) ・T14SG_AP.bin ... Update file of T14SG (piece 2) ・T14SG_UPLD.bin ... Update file of T14SG (piece 1)
  • Page 2 2. Insert the 'formatted" SD card into a card reader in your PC. 3. Please run "T14sgUpdate.exe". 4. Select the drive that your card reader is Update assigned to in your PC. 5. After the Update files are copied to the SD card, the following screens are displayed. Click the "End"...
  • Page 3 3. Update software of T14SG 1. Please insert the SD card which includes the update file. 2. Push the HOME/EXIT button. 3. While still holding the HOME/EXIT button, power on the transmitter. HOME/EXIT U.MENU/MON. button button 4. After a few seconds, the following screen is displayed.
  • Page 4 Before installing the speech data, you will need to update your T14SG software to Version 2.0 or later. If the software version of T14SG is before Ver.2.0, the speech data can not be installed. There are three language versions, English, German, and Japanese, in speech data. It is possible to install only one language.
  • Page 5 2. Install the already formatted SD card into your PC's card reader. 3. Please run "T14sgInstallSound***.exe". 4. Select the drive that your card reader is Update assigned to in your PC. Click "OK". 5. After the Update files are copied to the SD card, the following screens are displayed. Click the "End"...
  • Page 6 2. Install speech data of T14SG 1. Please insert the SD card which includes the installing speech data. 2. Push the HOME/EXIT button. 3. Still holding the HOME/EXIT button, power on the transmitter. HOME/EXIT U.MENU/MON. button button INSTALLSOUND 4. After a few seconds, the following screen is displayed.
  • Page 7 This software update modifies features found on the 14SG. If you have questions about these updated directions, please consult your instruction manual or futaba-rc.com for further details. Refer to the original manual where applicable but replace the steps indicated below with these instructions.
  • Page 8: Linkage Menu

    ④ If you want to show two sensors on your 2. Telemetry Speech function Telemetry screen, select 2 in "Display". ■ There is not only a software update, but also a Then move down to the Sensor to select Speech update that must be done. which other item is shown.
  • Page 9 ● The phone volume is added to SOUND *The format of the speech output is menu in SYSTEM MENU. "warning" [sensor type][data] [unit] Ex. Rx battery 「warning」 「battery」 「four point zero」 「volt」 *If the telemetry data is changed frequently, the speech data will not be the same as the displayed data.
  • Page 10 While this manual has been carefully written, there may be inadvertent errors or omissions. Please contact our service center if you feel that any corrections or clarifications should be made. FUTABA CORPORATION Phone: +81 475 32 6982, Facsimile: +81 475 32 6983 1080 Yabutsuka, Chosei-mura, Chosei-gun, Chiba 299-4395, Japan ©FUTABA CORPORATION...
