Summary of Contents for FUTABA T6PV

  • Page 1 FULL MANUAL 1M23Z10802...
  • Page 2 OUTSIDE NORTH AMERICA Please contact the Futaba importer in your region of the world to assist you with any questions, problems or service needs. Please recognize that all information in this manual, and all support availability, is based upon the systems sold in North America only. Products purchased elsewhere Compliance Information Statement (for U.S.A.)
  • Page 3: Table Of Contents

    ● Features  ……………………………… 9 Battery  ……………………………… 20 ● Set Contents  ……………………… 10 ● Steering Wheel Arrangement …… 21 ● Specifications  ……………………… 10 ● Exchange procedure to wheel adaptor 32 deg and large diameter wheel  ● Transmitter T6PV Nomenclature  ● Installing the accessory APA steering ● Power & Display Switch  ………… 12 wheel offset adapter  ……………… 23 ● Display When Power Switch Is Turned ● Angle Spacer  ……………………… 25 On  …………………………………… 12 ●...
  • Page 4 Table Of Contents ● Value Of Each Function And ● Kyosho MINI-Z EVO2 82044 (RA-51), Changing The Set Value  ………… 33 82046(RA-53) Link  ………………… 64 ● Linking Method For F-4G System  34 ● Kyosho MINI-Z FS-RM005 module Link ……………………………………… 67 ● Function Map   … …………………… 37 ● Servo view   ………………………… 69 SYSTEM MENU   … ……………………… 39 ● Throttle mode (Trigger)   ………… 70 ● Display  ……………………………… 39 ● Channel reverse  …………………… 72 ● Information   ……………………… 40 ●...
  • Page 5 Table Of Contents ● Brake mixing   ……………………… 120 ACCESSORY MENU  …………………… 159 ● Gyro mixing   ……………………… 124 ● Timer   ……………………………… 159 ● 4WS mixing   … ……………………… 127 ● Using the Up timer   ……………… 162 ● Dual ESC   …………………………… 130 ● Using the fuel down timer   ……… 163 ● CPS mixing (1, 2, 3 )   ……………… 132 ● Using the lap timer   ……………… 164 ●...
  • Page 6: Safety Precautions

    Please adjust the receiver settings on the transmitter according to the servo you are using and its operating mode (UR/SR/digi- tal/analog). (For each channel) If the settings are not correct, it may damage the servo, battery, etc.. Please use Futaba genuine products as Futaba won't cover the damage caused by using other brand servos or peripherals such as extension cable, etc..
  • Page 7: Operation Precautions

     Never plug the charger into an outlet of other than the indicated voltage.  Never insert or remove the charger while your hands are wet. You may get an electric shock.  Do not use the T6PV transmitterʼs battery as the receiverʼs battery. Since the transmitter’s battery has an overload protection circuit, the output power will be shut down when the high current load is applied. This may result in runaway or fatal crash.
  • Page 8: Storage And Disposal Precautions

    A used battery is a valuable resource. Insulate the battery terminals and dispose of the battery by taking it to a battery recycling center. Other Precautions Caution  Do not expose plastic parts to fuel, motor spray, waste oil or exhaust. The fuel, motor spray, waste oil and exhaust will penetrate and damage the plastic. Always  use  only  genuine  Futaba  transmitters,  receivers,  servos,  ESCs  (electronic  speed  controller),  Batteries  and other optional accessories. struction manual and catalog. Return to table of contents...
  • Page 9: Features

    Features -Full color screen LCD -Drag racing T6PV has a 3.2 inch, full-color, backlit LCD screen. This function can be used in a drag racing situation, where the driver can use the trans-brake to assist in the -F-4G system & telemetry staging process.
  • Page 10: Set Contents

    Short manual Hex wrench - If any of the set contents are missing, or you have any questions, please contact your dealer. The R404SBS-E receiver is for electric. Do not use for the gas powered models. Always  use  only  genuine  Futaba  transmitters,  receivers,  servos,  ESCs  (electronic  speed  controls),  batteries and other optional accessories. struction manual and catalog. In addition, the Fail-safe Unit cannot be used because the system is different. Use the fail-safe function of the ...
  • Page 11: Transmitter T6Pv Nomenclature

     Transmitter T6PV Transmitter overview *Please be careful not to push the switch too strongly. Communication port Power switch Color LCD screen Display switch Direct button    Antenna DIR    microSD End button    END    Jog key Digital Dial  (DL1) /  Push switch 3 (SW3) + button        microSD port Steering wheel R-PIN that secures the  - button             ...
  • Page 12: Power & Display Switch

    Power & Display Switch The power switch and display switch are push switches. When the power switch (PWR) is held down, operation starts by transmitting radio waves. When the display switch (DSP) is held down, the transmitter side data can be checked and set. Power & Display Switch When the power is turned off, is shown.
  • Page 13: Power Off Forgotten Alarm & Auto Power Off

    Power Off Forgotten Alarm & Auto Power Off When leave the transmitter without any operation of steering wheel, throttle trig- ger, push switch, edit button, or other operation 10 minutes, the audible alarm will given within 5 minutes from the warning the alarm is reset. On the other hand, If the operation is not given in 5 minutes, the power will be automatically shut down.
  • Page 14: Digital Trim Operation

    Digital Trim Operation Operating by the trim: Push the trim lever to the left or right (up or down). The cur- rent position is displayed on the LCD screen. • DT1 (Steering trim display) • DT2 (Throttle trim display) • DT3 (Channel. 3 display) •...
  • Page 15: Trim/Dial Lock

    Trim/Dial Lock T6PV setup and operation by digital trim DT1, DT2, DT3, DT4, DT5 and DT6 and dials DL1 can be prohibited. Setting When the END button is pressed for about 1 second on the initial screen, a confirma- tion beep sounds and the trim/dial lock sign appears on the screen.
  • Page 16: Wheel & Trigger Tension Adjustment

    Wheel & Trigger Tension Adjustment Adjustment Using hex wrench, adjust the wheel spring tension by turning the screw in- side the adjusting hole. - The spring is set to the weakest ten- sion at the factory. - When the adjusting screw is turned clockwise, the spring tension increases. Wheel tension Trigger tension ad- adjusting screw...
  • Page 17: Sw: Push Switch Dl: Dial

    SW: Push switch     DL: Dial  The position of various switches. The assignment of each function can be changed for T6PV. SW3/DL1 Optional Grip Rubber  Change the thickness of the grip by replacing it with the optional grip rubber for the T10PX. Grip Rubber Optional carbon handle An optional carbon handle (for T10PX) can be installed.
  • Page 18: Battery Replacement Method

    Battery Replacement Method  Load the four batteries in accordance with the polarity markings on the battery holder. Battery Replacement Method Remove the battery cover from the Slide battery cover while pressing here. transmitter by sliding it in the direction of the arrow in the figure. Remove the used batteries.
  • Page 19: When Using The Optional Battery

    When Using The Optional Battery When using an optional rechargeable battery, replace the battery as described below. -Always use the optional FT2F1100B(V2), FT2F1700B(V2), FT2F2100B, HT5F1800 or LT- 2F2000B rechargeable battery. -The type of battery used must be selected through the system setting. -When the transmitter will not be used for a long time, remove the battery. NiMH LiFe Battery Replace- ment Method Remove the transmitter battery cover.
  • Page 20: Optional Lipo Battery Lt2F2000B Replacement Method

    When Charging For The Optional LiPo Battery To charge the battery, connect a type C USB cable to the Futaba optional USB AC adapter or a commercially available USB AC adapter (USB-A type 5 V-2 A) from the LiPo dedicated charging port. Use a commercially ...
  • Page 21: Steering Wheel Arrangement

    Steering Wheel Arrangement Changing the wheel position Angle can be adjusted justing the steering wheel unit installa- using the accessory APA(Adjustable tion. Positioning Adaptor) wheel position [7.5 ° 48 steps ] 5° Angle spacer The wheel mounting angle can be changed by us- ing the optional angle spacer 5°. Return to table of contents...
  • Page 22: Exchange Procedure To Wheel Adaptor 32 Deg And Large Diameter Wheel

    Exchange procedure to wheel adaptor 32 deg and large diameter wheel The operating angle of the wheel can be adjusted The operating angle of the wheel can be changed from 34 deg to 32 deg by install- ing the 32 deg wheel adjuster. If you install the 32 deg wheel adapter, be sure to adjust the scale of the steering channel accordingly by using the "Calibration Function (System menu)".
  • Page 23: Installing The Accessory Apa Steering Wheel Offset Adapter

    Installing the accessory APA steering wheel offset adapter - Obtain hex wrench./ Remove the battery. Remove the 2 steering unit mounting screws (M3x12 screw). (Using a hex wrench.) M3×12 Remove the 2 mounting screws com- pletely from the transmitter body. M3×12 Gently remove the steering unit, without pulling excessively on the wiring.
  • Page 24 Pass the wiring from the wheel unit M2×10 through the hole in the APA parts and steering housing as shown in the figure. M2×10 APA uses the inside holes. The mounting M2×10 angle in the direction Normal of rotation can be screw adjusted.
  • Page 25: Angle Spacer

    Angle Spacer  The wheel mounting angle can be changed by using the optional angle spacer 5°. - Obtain hex wrench./ Remove the battery. APA uses the outside holes. The mounting angle in the direction of rotation can be adjusted. Normal Angle spacer screw position Adjust the angle with the position mark.
  • Page 26: Trigger Brake Lever Replacement

    This is not an issue but please keep this symptom in mind, especially when setting-up. microSD port Rotating the antenna 90 ° reveals a microSD T6PV model data and telemetry log data can be port. saved by using a commercial microSD card. When T6PV software updates are released, the microSD card can also be used to make the update.
  • Page 27: Receiver Terminology

    • Use the servo that matches the servo type of each receiver response. tion, it may cause trouble with servos and other equipment. Futaba will not be responsible for damage, etc. caused by combi- nation with the products of other companies.
  • Page 28: Receiver And Servo Connections

    Installation Receiver And Servo Connections Connect the receiver and servos as shown below. Connect and install the receiver and servos in accordance with Installation Safety Precautions on the next page. speed controller to the motor and battery depends on the motor controller used. Purchase the electronic speed controller and servos separately.
  • Page 29: Installation Safety Precautions

    Installation Safety Precautions Warning Receiver (receiver antenna)  Do not cut or bundle the receiver antenna wire.(R404SBS)  Do not bundle the receiver antenna wire together with the ESC lead wire.(R404SBS)  Keep the receiver antenna at least 1 cm away from motor, battery, and other wiring carrying heavy current.  Do not use a metal receiver antenna holder on a plate made of metal, carbon, or other conductive material.  Since the antenna of built-in antenna receivers is installed under this, do not place wiring or other objects on it. Install the receiver as far away as possible from the battery, ESC, motor, silicon Battery cord and other noise sources. Keep it away from the antenna wire, in particular.   Antenna Since the antenna of built-in antenna receivers is installed under this, do not place wiring or other objects on it.
  • Page 30 Screw Damper Eyelet Mechanical plate (or) Nut (as required) When installing the servo, always install the accessory grommet and grommet are not installed correctly. Warning Servo Throw  Operate each servo over its full stroke and be sure the linkage does not bind or come loose. The continuous application of unreasonable force to a servo may cause damage and excessive battery drain. Adjust the throttle servo so that un- reasonable force is...
  • Page 31: Basic Operations

    Basic Operations Menu Selection This section explains how to operate the basic screens. The jog keys and DIR/END button are used to operate the screens. *You can return to the home screen from each screen by pressing and holding the END button. Display Menu Screen Press Press and hold...
  • Page 32: Jog Key/Dir/End Button

    T6PV's main unit's digital trims DT1 to DT6 and dial DL1. screen or any setting screen will return to the previous screen.
  • Page 33: Value Of Each Function And Changing The Set Value

    Value Of Each Function And Changing The Set Value On the setting screen for each function, to increase or decrease the data value, se- lect the item with the jog key and press the [+] or [-] button to set. Pressing the [+] and [-] button simultaneously will return to the initial value. *The example below shows the endpoint screen.
  • Page 34: Linking Method For F-4G System

    Futaba Service Center. When a screen is displayed at the "DSP" side, "Display" is displayed. *Since the R404SBS(E) receiver supplied with the T6PV set uses the F-4G system, T6PV receiver setup must be set to F-4G.
  • Page 35 *In the F-4G system, the Battery Fail-safe voltage is set at the time of linking. Relink when changing Battery Fail-safe voltage. on the receiver power. Select [Link] on the transmitter T6PV screen, you will hear a chime sound and T6PV will enter the link mode for 20 seconds. Return to table of contents ...
  • Page 36 *When using multiple F-4G/T-FHSS receivers, link each receiver with be linked. each T6PV model memory. However, one receiver can be linked with multiple model memories. *The telemetry function communication status can be checked at the T6PV home screen.
  • Page 37: Function Map

    Function Function Map  *The screens in this manual may  differ depending on the version. HOME MENU System menu 1 Model menu Linkage menu 1 Racing menu 1 Mixing menu 1 Telemetry menu Accessory menu 1 System menu 2 Linkage menu 2 Racing menu 2 Mixing menu 2 Accessory menu 2 System menu Receiver Display...
  • Page 38 Throttle mode Channel Receiver Servo view (Trigger) reverse Sub trim End point Fail-safe Acceleration Linkage menu Trim / Dial Switch Channel Idle up D/R, ATL select select setting Traction Racing menu Curve (EXP) Speed A.B.S. Start Engine cut Response Drag Racing control Mixing menu Steering...
  • Page 39: System Menu

    SYSTEM MENU Display This function is Backlight brightness, dimming time setting menu. Home screen Menu screen System menu screen Display Jog Key Display setup (Backlight decrease brightness adjustment) Select the value with jog key of the [Backlight max, bright- ness] or [Backlight min, brightness]. Use the [+] or [-] button to adjust the backlight decrease the brightness amount.
  • Page 40: Information

    It also displays the software version. Home screen Menu screen System menu screen Information T6PV software version Jog Key Setting the user name Name cursor movement  (Moving the cursor to the character you want to change.) With the cursor on [User name], press the jog key. In the when you decide a character, model name, Use the jog key to select [ ←...
  • Page 41 SYSTEM MENU Language setting Language select Use the jog key to select from the list and press it. (Language select) Select the [Language] with the jog key and press, a list of languages will be displayed on the screen. If you press jog key the language you want to use from the list, the language display will be changed and you will be taken to the home screen.
  • Page 42: Buzzer

    SYSTEM MENU Buzzer This function can set the sound of " Operation " and " Warning " . -The sound of when switch, dial, button, and trim are operated can be adjusted. -The sound of the audible alarm sound can be adjusted. Home screen Menu screen System menu screen...
  • Page 43: Battery

    Therefore, always set the battery type to match the power supply being used. When using a Futaba rechargeable type battery, always select “ LiFe 2 cells ” “ LiPo 2 cells ” or “ NiMH 5 cells ” . The incorrect setting will substantially shorten the time from low battery alarm to system stopping and is very dangerous.
  • Page 44: Total Time

    SYSTEM MENU Total time Displays the total time for how long the T6PV has been turned on. Whether the timer or the total time (accumulation timer) is displayed on the initial screen can be set. The total time can be reset at this menu.
  • Page 45: Led Setting

    SYSTEM MENU LED setting Adjust the brightness and lighting method of the pilot LED light. The pilot LED lighting method can be selected from " Always On " , " " or " Backlight " . Home screen Menu screen System menu screen LED setting Jog Key LED setting...
  • Page 46: Calibration

    END button to return to the Home screen. If the operation cannot usually be ended even when correction is re- peated, please contact the Futaba Service Center. hold the END button to return to the Home screen.
  • Page 47 END button to return to the Home screen. If the operation cannot usually be ended even when correc- tion is repeated, please contact the Futaba Service Center. hold the END button to return to the Home screen.
  • Page 48: Receiver Update

    Receiver battery (The receiver power supply can be con- nected to the each of CH1-4.) Antenna Turn on the DSP or PWR switch of T6PV and display the receiver update screen. Home screen Menu screen System menu screen 1 System menu screen 2 Receiver update Jog Key...
  • Page 49 A progress bar will be displayed indicating the prog- ress. The LED of the receiver turns green, and it blinks green for a moment every time it accepts data from the T6PV. - Do not turn off the power of T6PV while updating.
  • Page 50: Model Menu

    Forty model data (model data for 40 R/C cars) can be saved in the T6PV transmitter and used when the relevant model data selected. However, models copied in the mi- croSD card cannot be used by directly calling from the card. Please copy it to the T6PV main unit when using it.
  • Page 51: Model Copy

    MODEL MENU Model copy The contents of model memory can copy to another model memory. You can also save content to a microSD card for backup or to copy to another T6PV. Home screen Menu screen Model menu screen Model copy Jog Key Model copying...
  • Page 52 END button to return to the Home screen. The microSD card storage destination When a microSD card is installed in the T6PV, a folder called "Futaba" is created, and folders called "LOG" and "MODEL" are created in it. The "MODEL" folder contains the model data.
  • Page 53: Model Name

    MODEL MENU Model name This function allows you to assign a name up to 15 characters, to each model memory. Home screen Menu screen Model menu screen Model name Jog Key Setting the model name and user name (Moving the cursor to the character you want to change.) Name cursor movement  Use the [ ]/[ ] press jog key In the model name, Select the [ ] [ ] with the jog key and to move the cursor.
  • Page 54: Model Delete (Model Saved On Microsd Card)

    MODEL MENU Model delete (Model saved on microSD card) This function deletes model data saved on the microSD card. Model deletion is displayed on the menu only when the microSD card is set in the T6PV card slot. Home screen Menu screen Model menu screen Model delete Jog Key...
  • Page 55: Data Reset

    MODEL MENU Data reset  This function resets the contents of the currently called model memory. The reset method can be selected from among the four types described below. These resets do not initialize the calibration function and system function. -Model data This mode is Initializes only the function setting data. The direct menu function is not initialized.
  • Page 56: Model Type

    MODEL MENU Model type It can be changed to the initial setting suitable for 1/5 big car and drift car. Also, the user menu changes the layout for each model type. For example, for 1/5 big cars, steer- ing mixing and brake mixing are set to ON in advance, and drift is set to gyro mixing, so it is easy to set each type of machine.
  • Page 57: Linkage Menu

    When a screen is displayed at the "DSP" side, "Display" is displayed. *Since the R404SBS(E) receiver supplied with the T6PV set uses the F-4G system, T6PV receiver setup must be set to F-4G. Receiver system Change & How To Link receiver memorizes the transmitter ID number so that signals from other transmitters will not be received.
  • Page 58 Bring the transmitter and receiver within 50 cm of each other (antennas do not touch) and turn on the receiver power. Select [Link] on the transmitter T6PV screen, you will hear a chime sound and T6PV will enter the link mode for 20 seconds.
  • Page 59 "Link with receiver" appears on the screen, release the receiver push switch. This ends reading of mutual ID and displays the memorized receiver ID number on the T6PV screen. Power cycle the receiver. If the "Receiver not found" error screen is displayed, linking failed. Check the set contents and repeat the linking operation.
  • Page 60: T-Fhss Link

    LINKAGE MENU Telemetry function ON/OFF (Function ON/OFF) Setting Use the jog key to select telemetry and use the [+] - Use the [+] or [-] button or [-] button to set it to (ON) or (OFF). to set (ON)/(OFF). "OFF": Telemetry function OFF "ON": Telemetry function ON Telemetry function ON...
  • Page 61 Bring the transmitter and receiver within 50 cm of each other (antennas do not touch) and turn on the receiver power. Select [Link] on the transmitter T6PV screen, you will hear a chime sound and T6PV will enter the link mode for 20 seconds.
  • Page 62: S-Fhss Link

    Precaution: If there are many Futaba 2.4GHz systems turned on close to your receiver might not link to your transmitter. In to one of the other transmitters. It is dangerous if you do not notice this situation. To avoid problems, it is strong- ly recommended that you double-check that the transmitter controls the receiver by making the wheel or trigger inputs and checking the servo response.
  • Page 63: Kyosho Mini-Z Evo 82042 (Ra-42) Link

    Turn on the Mini-Z receiver RA-42. Use the jog key to select [Link] on the T6PV screen and press it, you will hear a chime sound, and T6PV will enter the link mode for 20-seconds. Push the receiver side push switch for about 2-seconds or more.
  • Page 64: Kyosho Mini-Z Evo2 82044 (Ra-51), 82046(Ra-53) Link

    LINKAGE MENU Kyosho MINI-Z EVO2 82044 (RA-51), 82046(RA-53) Link * KYOSHO MINI-Z receiver unit RA-51 [No.82044], RA-53 [No.82046] (sold separately) is required. Receiver system Change Set the transmitter “PWR” side power switch to ON. From the Home screen, use the jog key to call up the menu. Next, select [Receiver] at the Linkage menu and access the setup screen shown below.
  • Page 65: How To Link

    Press and release the link switch on the MINI- Z receiver for more than 2 seconds, and when the cancel the link mode of the T6PV and return it to normal mode. When the MINI-Z receiver LED lights up, the link is complete.
  • Page 66 LINKAGE MENU Supported the following Kyosho products: ● Compatible receivers MINI-Z EVO receiver unit T7PX/T7XC/T4PM 82042  MINI-Z EVO2 receiver unit for Futaba compatible transmitters 82044  MINI-Z EVO2 receiver unit V2 for Futaba compatible transmitters 82046 Compatible chassis MR-03EVO MINI-Z racer MR-03 EVO chassis set(W-MM/12000KV)  32790  MINI-Z racer MR-03 EVO chassis set(N-MM2/5600KV)  32791  MR-04 EVO2 MINI-Z racer MR-04 EVO2 chassis set (W-MM/8500KV) 32890  MINI-Z racer MR-04 EVO2 chassis set (W-MM/5600KV) 32891  MINI-Z racer MR-04 EVO2 chassis set (N-MM2/4100KV) 32892 MINI-Z EVO is a non-telemetry protocol compatible with the MR-03 EVO chassis. Compatible chassis MINI-Z racer MR-03EVO chassis set(W-MM/12000KV)  32790 MINI-Z racer MR-03EVO chassis set(N-MM2/5600KV)  32791  Compatible receivers FUTABA/FHSS receiver unit (for T7PX/T7XC) No82042  MINI-Z EVO2 receiver unit for Futaba compatible transmitters 82044  MINI-Z EVO2 receiver unit V2 for Futaba compatible transmitters 82046 MINI-Z EVO2 is a protocol compatible with the MR-04 EVO2 chassis. MINI-Z racer MR-04 EVO2 chassis set (W-MM/8500KV) 32890 MINI-Z racer MR-04 EVO2 chassis set (W-MM/5600KV) 32891 MINI-Z racer MR-04 EVO2 chassis set (N-MM2/4100KV) 32892 MINI-Z EVO2 telemetry OFF is a non-telemetry protocol. MINI-Z EVO2 receiver unit for Futaba compatible transmitters 82044 MINI-Z EVO2 receiver unit V2 for Futaba compatible transmitters 82046 MINI-Z EVO2 telemetry ON has two types of telemetry protocols. Response Slow  … REAL TIME ICS MiniZ and Telemetry Enabled Response Fast ...
  • Page 67: Kyosho Mini-Z Fs-Rm005 Module Link

    * KYOSHO MINI-Z module FS-RM005 is required. Receiver system Change Connect FS-RM005 module to T6PV. Set the transmitter “PWR” side power switch to ON. From the Home screen, use the jog key to call up the menu. Next, select [Receiver] at the Linkage menu and access the setup screen shown below.
  • Page 68 MINI-Z receiver. Check that the LED on the MINI-Z receiver blinks quickly and releases the link switch. Select the [Link] on the “Receiver” screen. The T6PV will enter link mode, Rand a message will be dis- has changed to slow blinking, then Select the [Close].
  • Page 69: Servo View

    LINKAGE MENU Servo view The servo operation of each channel can be checked. Process of the steering angle ad- Home screen Menu screen Linkage menu screen Servo view Jog Key The number of channels varies depending on the selected system. Confirm operation Operating each channel, such as a steering wheel or throttle trigger, the graph moves, and and hold the END button to return to the Home screen.
  • Page 70: Throttle Mode (Trigger)

    The neutral brake, which applies the brakes at the neu- tral position of the throttle trigger, can be set. However, when using the MC971CR, MC970CR, MC960CR, MC950CR, MC851C, MC602C, MC402CR, or other Futaba mode before setting the neutral brake function switch to ON.
  • Page 71 OFF. neutral brake. Reference The ESC neutral brake function and the T6PV neutral brake function can be used that only one neutral brake function be used. Trim/Dial Setting  When the neutral brake function is , the neutral brake rate adjustment is auto- "...
  • Page 72: Channel Reverse

    LINKAGE MENU Channel reverse This function reverses the direction of operation of the servos related to transmitter steering, throttle, channel 3-6 channels operation. However, when the position set by trim or sub trim shifts from the center, the center becomes the opposite side. Home screen Menu screen Linkage menu screen...
  • Page 73: Sub Trim

    LINKAGE MENU Sub trim Use this function to adjust the neutral position of the steering, throttle, channel 3, chan- nel 4, and auxiliary channels servos. Home screen Menu screen Linkage menu screen Sub trim Jog Key 90° *Sub trim adjusts the entire range of the *Adjust the center position of servo in the set direction.
  • Page 74: End Point

    LINKAGE MENU End point  Used to adjust the left and right end points of the steering wheel, adjust the throttle high side/brake side manipulated variable, change the channel 3, channel 4, auxiliary chan- nel servo upside/downside manipulated variable. - Correct the maximum steering angle for left and right steering angles when there is a Maximum steering angle The End point function determines the maximum steering angle of each channel.
  • Page 75 LINKAGE MENU Linkage menu Home screen Menu screen Linkage menu screen End point Jog Key Steering end point adjustment Adjustment buttons Adjust with the [+] or [-] button. (Preparation) - Return to the initial value by press - Before setup of the steering end point adjustment, set the steer- the [+] and [-] button simultaneously ing D/R dial (initial setup: DT5) to the maximum steering angle Steering End point: 0~140...
  • Page 76 LINKAGE MENU Throttle end point adjustment (Preparation) Adjustment buttons - Use the [+] or [-] button to - Before setting the throttle end point adjustment, set the throttle make adjustments. ATL dial (initial setup: DT6) to the maximum throttle angle po- - Return to the initial value by press the [+] and [-] button si- sition 100%.
  • Page 77: Fail-Safe/Battery Fail-Safe

    LINKAGE MENU Fail-safe/Battery fail-safe This function sets the servo operation position when transmitter signals cannot be re- ceived by the receiver for some reason, or the battery voltage has dropped. -Fail-safe mode This function moves each servo to a preset position when the receiver cannot receive the signals from the transmitter for some reason.
  • Page 78 LINKAGE MENU Fail-safe mode selection (Preparation) - Use the jog key to select the fail-safe channel you want to set. (Mode selection) safe-Hold. (Each channel can be individually set.) Fail-safe mode the END button, or press and hold the END button to return to the Home screen. When setting fail- safe, set the servo position by the following method.
  • Page 79: Acceleration

    LINKAGE MENU Acceleration The servo will jump to the input position at its maximum possible speed. Unlike expo- nential, which adjusts the whole throttle movement into a curve, throttle acceleration " jumps " away from neutral and then leaves the remaining response linear. Operation - Operation near the throt- 100%...
  • Page 80 LINKAGE MENU Throttle acceleration adjustment Adjustment buttons (Preparation) Adjust with the [+] or [-] button. - Return to the initial value by - Use the jog key to move the cursor to the forward value: press the [+] and [-] button si- multaneously (Forward acceleration amount adjustment) Use the [+] or [-] button to adjust the ac- Forward acceleration amount celeration amount.
  • Page 81: Trim/Dial Select

    LINKAGE MENU Trim/Dial select This function allows the selection of the function performed by the digital dial DL1 and digital trimmers (DT1 to DT6), step amount adjustment, and operating direction reversal. - The table on next page lists the functions that can be assigned to each dial and digital trim.
  • Page 82 LINKAGE MENU (Changing the operation direction) Setting direction - Use the [+] or [-] button to se- Move the jog key left or right to display lect the [Nor.]/[Rev.]. the second page of the screen. If you (Nor.) Normal/(Rev.) Reverse want to change the direction, use the jog key to move the cursor and use the [+] or [-] button to set normal or reverse.
  • Page 83 LINKAGE MENU Set table functions (DT1, DT2, DT3, DT4, DT5, DT6, DL1) Name Function Steering trim Steering trim Throttle trim Throttle trim Channel 3-6 control Channel 3-6 control Dual rate Dual rate function Sub trim Ch.1 to 6 Sub trim Ch.1~6 Acceleration (forward) Throttle acceleration (Forward side) Acceleration (brake 1) Throttle acceleration (Brake 1 side) Acceleration (brake 2) Throttle acceleration (Brake 2 side)
  • Page 84: Switch Select

    LINKAGE MENU Switch select This function allows the selection of the function to be performed by the switches (SW1-3, steering wheel, throttle trigger) and setting of the direction, etc. of operation. - Next lists the functions that can be assigned to each push switch. - The push switch SW3 is integrated with the DL1.
  • Page 85 LINKAGE MENU (Changing the operation direction) Move the jog key left or right to display the second page of the screen. If you want to change the direction, use the jog key to move the cursor and use the [+] or [-] button to set normal or reverse. Use the jog key left or right to go to page 2 Setting direction - Use the [+] or [-] button to se-...
  • Page 86 LINKAGE MENU Set table functions Push switch  : SW1-SW3 Abbreviation used on  Function name, etc the setup screen Operation of channel 3 to 6 (Number of channels Channel 3 to 6 control varies by system.) Program mixing (1-5) Program mixing (1-5) function ON/OFF A.B.S. (Brake 1) A.B.S function brake 1 (2 channel) ON/OFF A.B.S function brake 2,3 (Auxiliary channel) ON/ A.B.S.
  • Page 87: Idle-Up

    However, considering safety, and to prevent the motor from rotating instantly when the power is turned on, Futaba electronic motor speed controller (ESC) will not taba ESC, verify that the ESC is in the neutral position and the set is in the operation mode before setting the idle up function switch to ON.
  • Page 88 LINKAGE MENU Idle-up function adjustment (Preparation) Example of setting SW1 as an idle up switch - In the [Switch select] function(Linkage menu), set the ON/OFF switch for the idle-up function. If it is not set, “A switch is not assigned” will be dis- played, so select [Switch select] with the jog key and press it to move to the switch setting screen and set the switch.
  • Page 89: D/R, Atl

    LINKAGE MENU D/R, ATL D/R (Steering dual rate) The steering left and right servo travels are adjusted simultaneously. This setting is linked to transmitter grip trim DT5. When DT5 is assigned another function, the dual rate can be adjusted with this screen. ATL (Brake 1 rate) value when the braking force is weak.
  • Page 90 LINKAGE MENU Brake rate (ATL) adjustment Use the jog key to move the cursor to the Adjust button Adjust with the [+] or [-] button. [Brake1 rate (ATL)] value and use the [+] - Return to the initial value by press or [-] button to set the rate. the [+] and [-] button simultaneously When finished, return to the Linkage Brake rate(ATL)
  • Page 91: Channel Setting

    LINKAGE MENU Channel setting This function assigns steering or throttle to any channel. You can operate steering and throttle on other channels, and operate other channels in the same way as steering and throttle. Home screen Menu screen Linkage menu screen 1 Linkage menu screen 2 Channel setting Jog Key...
  • Page 92: Racing Menu

    RACING MENU Curve (EXP) Steering curve This function is used to change the sensitivity of the steering servo around the neutral Home screen Menu screen Racing menu screen Curve(EXP) screen Jog Key Quick Mild (Positive side) (Negative side) EXP curve screen Curve type which operates the steering from the neutral point to the end point on a curved Wheel operation Wheel operation...
  • Page 93 RACING MENU Trim/Dial Setting  The steering EXP, VTR adjustment can be controlled with digital trim DT1 to DT6 or digital dial DL1 etc. with the trim/dial select function. (Linkage menu) EXP adjustment (Preparation) -Press jog key the curve type and select [EXP]. Adjustment buttons Select the value with jog key of the [EXP - Adjust with the [+] or [-] button.
  • Page 94 RACING MENU Throttle curve (Forward side) This function makes the throttle high side direction servo operation quicker or milder. The selection from among three kinds of curves (EXP/VTR) is also possible. Advice When the course conditions are good and the surface has good grip, set each curve to the plus [+] side (quick side).
  • Page 95 RACING MENU Trim/Dial Setting  The steering EXP, VTR adjustment can be controlled with digital trim DT1 to DT6 or digital dial DL1 etc. with the trim/dial select function. (Linkage menu) EXP adjustment (Preparation) -Press jog key the curve type and select [EXP]. Adjustment buttons Select the value with jog key of the [EXP - Adjust with the [+] or [-] button.
  • Page 96: Brake Curve

    RACING MENU Brake curve  This function makes the servo operation on the brake side faster or gentler. It does not (EXP/VTR) is also possible. If the Ratio is set to 100:0 with the trigger function (Link- each curve is the same as the throttle (forward) side curve, please read previous page “Throttle curve”.
  • Page 97: Steering Speed

    RACING MENU Speed Steering speed Quick steering operation will cause momentary understeering, loss of speed, or spin- ning. This function is useful in such cases. Understeering Spin Smooth cornering Without "Steering speed function" With "Steering speed function" Operation  - This function limits the maximum speed of the steering servo. (Delay function) - The steering speed when the steering wheel is operated (Turn direction) and returned (Return direction) can be inde-...
  • Page 98 RACING MENU Adjustment buttons  Steering Speed adjustment - Adjust with the [+] or [-] button. - Return to the initial value by press ("Turn" direction delay adjustment) the [+] and [-] button simultane- Select the value with jog key of the [Turn]. Use the [+] or [-] ously button to adjust the turn speed amount.
  • Page 99: Throttle Speed

    RACING MENU Throttle speed Sudden throttle trigger operation on a slippery road only causes the wheels to spin, and the vehicle cannot accelerate smoothly. Setting the throttle speed function reduces waste- ful battery consumption while at the same time permitting smooth, enjoyable operation. Without "Throttle speed function"...
  • Page 100 RACING MENU Adjustment method for Speed mode (Preparation) Adjustment buttons -Use the jog key to select [Throttle Speed] and press it. - Adjust with the [+] or [-] button. - Return to the initial value by press (Turn direction delay adjustment) the [+] and [-] button simultaneously Select [Turn] side of the value button.
  • Page 101: Traction Control

    RACING MENU Traction control Trigger operation with cornering on a slippery road surface is hard to get traction, and smooth cornering cannot be done. By intermittently operating the operation of the throttle, you can smoothly navigate and travel on driving lines. Also, with a drift car, by intermittently operating the motor in the high point direction, a pseudo revving en- gine sound can be reproduced.
  • Page 102 RACING MENU - Delay Set the delay from when the throttle is operated until when the traction control opera- tion starts. When set to 0%, the traction control function works without delay. At 50%, the traction control function works approximately 0.5-seconds later, and the traction control function works about 1.0-seconds later at 100%.
  • Page 103: Cycle Speed

    RACING MENU ("Delay" amount setup) Adjustment buttons Select the value with jog key of the [De- - Adjust with the [+] or [-] button. - Return to the initial value by press lay]. Use the [+] or [-] button to adjust the the [+] and [-] button simultaneously delay amount.
  • Page 104 RACING MENU ("Trigger point" setup) Adjustment buttons - Adjust with the [+] or [-] button. Select the value with jog key of the [Trigger point]. Use the [+] - Return to the initial value by press or [-] button to adjust the operation point. the [+] and [-] button simultane- ously - Sets the throttle trigger position at which the traction control function is...
  • Page 105: 105

    RACING MENU A.B.S. When the brakes are applied while cornering with a 4-Wheel Drive or other types of vehicles, understeer may occur. The tendency to understeer can be eliminated and corners can be smoothly cleared by using this function. Operation  - When the brakes are applied, the throttle servo will pulse in- Without "A.B.S."...
  • Page 106 RACING MENU - Delay Sets the delay from brake operation to ABS operation. When set to 0%, the ABS func- tion is activated without any delay. At 50%, the ABS function is activated after a delay of approximately 0.7-seconds and at 100%, the ABS function is activated after a delay of approximately 1.4-seconds.
  • Page 107 RACING MENU ("Delay" amount setup) Adjustment buttons - Adjust with the [+] or [-] button. Select the value with jog key of the [De- - Return to the initial value by press lay]. Use the [+] or [-] button to adjust the [+] and [-] button simultane- ously the delay amount.
  • Page 108: Trigger Point

    RACING MENU Adjustment buttons ("Trigger point" setup) - Adjust with the [+] or [-] button. - Return to the initial value by press Select the value with jog key of the [Trigger point]. Use the [+] the [+] and [-] button simultaneously or [-] button to adjust the operation point.
  • Page 109 RACING MENU Switch setting Use switch the A.B.S. function ON/OFF. See the switch select function. (Linkage menu) Trim/Dial Setting  The brake return amount, delay amount, and cycle speed can be controlled with digital trim DT1 to DT6 or digital dial DL1, etc. with the trim/dial select function. (Linkage menu) Example of A.B.S. function setting ...
  • Page 110: Start

    RACING MENU Start  If the track is slippery and you begin to accelerate by pushing the trigger to full throt- tle, the car wheels will spin, and the car will not accelerate smoothly. When the Start function is activated, merely operating the throttle trigger slowly causes the throttle servo to automatically switch from the set throttle position to a preset point so that the tires do not lose their grip and the car accelerates smoothly.
  • Page 111 RACING MENU ("Trigger point" setup) Adjustment buttons - Adjust with the [+] or [-] button. Select the value with jog key of the [Trig- - Return to the initial value by press the [+] and [-] button simultaneously ger point]. Use the [+] or [-] button to ad- just the operation point.
  • Page 112: Engine Cut

    RACING MENU Engine cut When the switch is pressed, the throttle servo will move to the preset position without regard to the throttle trigger position. This function is convenient when used to cut the engine of boats, etc. (The switch select function in Linkage menu) Home screen Menu screen Racing menu screen...
  • Page 113 RACING MENU (Preset position setup) Select the value with jog key of the [Pre- set]. Use the [+] or [-] button to set the *Shows the ON/OFF state preset position of the throttle servo. Adjust button Adjust with the [+] or [-] button. - Return to the initial value by press the [+] and [-] button simultane- ously...
  • Page 114: Response

    RACING MENU Response It is a function to make the response mild. Use when the servo response is too sensitive. Home screen Menu screen Racing menu screen Response Jog Key Response function adjustment (Function ON/OFF) Use the jog key to move the cursor to “Response adjuster”...
  • Page 115: Drag Racing

    RACING MENU Drag racing Trans-Brake The Trans-Brake allows the engine to develop full power without that power being transmitted into the drive-train. This function can be used in a drag racing situation, where the driver can use the trans-brake to assist in the staging process. Home screen Menu screen Racing menu screen 1...
  • Page 116: Mixing Menu

    MIXING MENU Steering mixing This mixing function uses two servos to individually control the left and right steering. Left and right steering can be set independently, so smooth cornering is possible. By us- ing the " Steering mixing rate " function, the motions of the servos on the left and right sides of the steering can be adjusted at the same time.
  • Page 117 You can check the mixing used on the channel setting screen (Linkage menu). - T6PV can also be used for steering 2 by setting the throttle to other auxiliary channels setting function and mak- ing the Ch.2 assignable channel (Linkage menu).
  • Page 118 MIXING MENU (Steering mixing rate adjustment) Adjustment buttons Select the value with jog key of the - Adjust with the [+] or [-] button. "Steering mixing rate" [Left] or [Right]. - Return to the initial value by press the [+] and [-] button simultane- Adjust each of the left/right steering an- ously gles using the [+] or [-] button.
  • Page 119 MIXING MENU (Steering brake) (Preparations) When using this function, set the switch with the "Switch select" function (Linkage menu). Select the value with jog key of the "Brake rate". adjust the steering 1/2 operation position by [+] or [-] button. Adjustment buttons - Adjust with the [+] or [-] button.
  • Page 120: Brake Mixing

    MIXING MENU Brake mixing This function is used when the front and rear brakes must be adjusted independently such as a 1/5 scale GP car. This mixing uses the 2nd channel for the rear brakes and the auxiliary channel for the front brakes, or controls the front brakes with the auxiliary channel servos, or controls the 2nd channel by the independent throttle and controls the rear and front brakes with the auxiliary channel.
  • Page 121 MIXING MENU Home screen Menu screen Mixing menu Brake mixing Jog Key Brake mixing ON Brake mixing Brake mixing Brake mixing Brake 2 "ON" Brake 3 "ON" Brake 2&3 "ON" The mixing function is assigned to auxiliary channels used by another mixing can- Steering mixing adjustment Setting (Function ON/OFF) - Use the [+] or [-] button to set...
  • Page 122 You can check the mixing used on the channel setting screen (Linkage menu). - T6PV can also be used for brake 2 or 3 by setting the steering to other auxiliary channels with the channel setting function and making the Ch.1 assignable channel (Linkage menu).
  • Page 123 MIXING MENU (Steering mixing) Use this function when you want to soft- en the brakes when the steering is oper- Adjustment buttons - Adjust with the [+] or [-] button. ated. - Return to the initial value by press the [+] and [-] button simultane- Select the value with jog key of the ously "Brake 1 or 2,3"...
  • Page 124: Gyro Mixing

    This function is a remote gain function which adjusts the sensitivity of the Futaba car rate gyro at the T6PV side, and is mixing that uses the auxiliary channels to improve the gyro sensitivity. When using the T6PV by switching the AVCS and normal modes, use SW with the switch select function (Linkage menu).
  • Page 125 MIXING MENU Gyro mixing adjustment (Preparation) - Refer to the gyro instruction manual and connect the gyro to the receiver. When using re- mote gain, connect gyro sensitivity adjustment to the auxiliary channels of the receiver. - When using gyro mixing by switching between the NORM (normal) and AVCS modes, use the switch select function (Linkage menu) to set the switch to be used.
  • Page 126 MIXING MENU Setting (Gyro mixing type selection) - Press jog key Gain type. 1 gain/2 gain/4 gain Use the jog key to move the cursor to Gyro type. Use the [+] or [-] button to se- lect [1 gain], [2 gain] or [4 gain]. "1 gain"...
  • Page 127: 4Ws Mixing

    MIXING MENU 4WS mixing This function can be used with crawlers and other 4WS type vehicles. It is mixing that uses the 1st channel to control front side steering and the auxiliary channel to control rear side steering. A method of specifying directly for each type of opposite phase (only on the in-phase side), reverse phase, in-phase side and rear side by selecting SW in the "...
  • Page 128 You can check the mixing used on the channel setting screen (Linkage menu). - T6PV can also be used for rear steering by setting the throttle to other auxiliary channels setting function and making the Ch.2 assignable channel (Linkage menu).
  • Page 129 MIXING MENU Adjustment buttons (Rear side travel adjustment) - Adjust with the [+] or [-] button. Select the value with jog key of the [Rear - Return to the initial value by press the [+] and [-] button simultaneously mix rate]. Use the [+] or [-] button to ad- just the rear side travel amount.
  • Page 130: Dual Esc

    MIXING MENU Dual ESC This function is mixing two ESCs used with crawlers and other 4WD type vehicles and uses the 2nd channel to control the rear motor controller and the auxiliary channel to control the front motor controller. Front drive only, rear drive only, and both front and rear drive (4WD) switching can be performed by trim dial or by setting a switch for each mode.
  • Page 131 As this function drives two separate motor controllers simultaneously, a mutual load is applied. Use this function carefully so that the motor controllers are not damaged. Futaba will not be responsible for motor controller, motor, and other vehicle trouble due to the use of this function.
  • Page 132: Cps Mixing (1, 2, 3 )

    MIXING MENU CPS mixing (1, 2, 3 )  This function controls the Futaba CPS-1 channel power switch. Usually, when us- ing the CPS-1 unit to light the vehicle dress-up and other illumination (LED) the CPS-1 unit with LED connected is connected to a vacant switch channel and the the "...
  • Page 133 MIXING MENU (Channel setup) The channel list screen used for the CPS channel is displayed. Press jog key the auxiliary channel that connected the CPS-1 unit channel. and make an unused channel. You can check the mixing used on the channel setting screen (Linkage menu). Setting - Select with Jog key.
  • Page 134: Tank Mixing

    MIXING MENU Tank mixing This function is intended for vehicles such as tanks and can be used for the pivotal turn, or the ultra-pivotal brake turn, by steering and throttle operation. Home screen Menu screen Mixing menu Tank mixing Jog Key Connection channel The channels connecting the left and right motor controllers are as Throttle channel Steering channel  Tank mixing adjustment...
  • Page 135 MIXING MENU (Limit ON/OFF) Setting - Use the [+] or [-] button to set It is a function to limit the maximum op- (ON)/(OFF). eration amount of the steering and throt- tle channel so that it does not exceed the limit by the influence of the mixing amount.
  • Page 136: Program Mixing (1, 2, 3, 4, 5 )

    MIXING MENU Program mixing (1, 2, 3, 4, 5 )  These functions allow you to apply mixing between the steering, throttle, and auxiliary channel. It is possible to assign telemetry data to the mixing master. Additional Functions  -When the steering or throttle channel is the master channel (the channel that ap- plies mixing), trim data can be added.
  • Page 137 MIXING MENU Program composite adjustment (Preparation) - Use the switch select function (Linkage menu) to select the switch. (as desired) - From the Program mixing screen Select the [Program mixing 1-5] to use to move to the setting screen. Setting - Select 1-5 with the jog key. - Press jog key.
  • Page 138 MIXING MENU (Left, Forward or A side mixing amount adjustment) Adjustment buttons - Adjust with the [+] or [-] button. Operate the jog key left or right to display - Return to the initial value by press page 1. Select the value with jog key of the [+] and [-] button simultane- ously the "Rate A".
  • Page 139 MIXING MENU EXP adjustment (Preparation) Adjustment buttons - Adjust with the [+] or [-] button. -Use the jog key to move the cursor to “Type” - Return to the initial value by press the [+] and [-] button simultaneously and use the [+] or [-] button to select “EXP”. Select the value with jog key of the [EXP Curve rate rate].
  • Page 140: Winch Mixing

    MIXING MENU Winch mixing This mixing function allows any Trim/Dial to control a winch. The Trim/Dial will only move the device forward or reverse when the button is activated or pressed acting in a momentary manner. Movement will stop when the switch is released. Winch mixing uses a winch and applies bidirectional mixing from the throttle to winch and from the winch to throttle so that the rock crawler and winch can operate simultaneously with one input.
  • Page 141 MIXING MENU (Channel setup) The channel list screen used for the winch is displayed. Press jog key the auxiliary channel that connect- ed the winch. used channel. You can check the mixing used on the channel setting screen (Linkage menu). The number of channels varies If there is no assignable depending on the selected channel, Select the [Close].
  • Page 142: Telemetry Menu

    TELEMETRY MENU Telemetry system With the telemetry system, the running status can be displayed at the transmitter and also recorded as a data log by installing various sensor units to the chassis (The S-FHSS systems do not have a telemetry function.) -The sensor data can be checked at the transmitter by connecting the telemetry sensor sold separately to the S.BUS2 (S) port of the R404SBS receiver.
  • Page 143: Telemetry

    TELEMETRY MENU Telemetry  This screen displays and sets the various information from the receiver. The telemetry can be used in the F-4G and T-FHSS system. An alarm can be generated depending on the information. Each information screen sets the alarm. For example, a drop in the voltage of the receiver battery housed in the model car can be reported by an alarm.
  • Page 144: Telemetry: Receiver Battery Voltage

    TELEMETRY MENU Telemetry: Receiver Battery Voltage This function displays and sets the receiver power supply battery. The sensor sold sepa- rately does not have to be installed. The transmitter’s initial status voltage is also dis- played. For a description of the alarm set when the voltage drops, see the description of the procedure on this page.
  • Page 145: Telemetry: The Drive Battery Voltage

    TELEMETRY MENU Telemetry: The Drive Battery Voltage This function displays and sets the voltage of an external power supply (drive battery, etc.) separately installed in the chassis. Receiver S.BUS 2 connector is used to connect SBS-01V sensor and battery. * A drive battery sensor must be installed in the model car. Install and connect the sensor following the sensor in- struction manual.
  • Page 146: Telemetry: Rpm

    TELEMETRY MENU Telemetry: RPM Speed information from an SBS-01RM (telemetry rotation sensor) sold separately is displayed and set at this screen. The speed of the engine, motor, etc. of the chassis while running can be viewed at the transmitter. When the speed becomes higher (lower) than the set speed, it can be announced by an alarm.
  • Page 147: Telemetry: Temperature

    TELEMETRY MENU Telemetry: Temperature This screen displays and sets the temperature information from an SBS-01T (telemetry temperature sensor) sold separately. The temperature of the engine, motor, amp, etc. of the chassis while running can be viewed at the transmitter. When the temperature becomes higher or lower than the set value, it can be announced by an alarm.
  • Page 148: Telemetry: The Drive Battery Electric Current

    TELEMETRY MENU Telemetry: The Drive Battery Electric Current When the SBS-01C (electric current sensor) sold separately is mounted on the vehicle, the electric current, voltage, and consumption capacity of the power battery, etc., can be displayed. * A drive battery electric current sensor must be installed in the model car. Install and connect the sensor following the sensor instruction manual.
  • Page 149 END button, or press and hold the END button to return to the Home screen. The reset operation on the transmitter resets the integrated capacity display on the T6PV. It does not re- set the integrated capacity on the SBS-01C. The consumption capacity measurement range of SBS-01C is 32767 mAh maximum.
  • Page 150: Telemetry: Mc/Acuvance

    TELEMETRY MENU Telemetry: MC/Acuvance It is possible to display the following information for MC971CR/Acuvance compatible ESCs: *The motors that support the motor temperature measurement function are the “LUXON AGILE” series manufactured by Accuvance Co., Ltd. Motor temperature measurement is not guaranteed if any other motor is connected. Current temperature Telemetry The minimum and maximum when...
  • Page 151 TELEMETRY MENU Current drive battery voltage The minimum and maximum when powering ON are shown. *Select and press this with the jog key to reset and restart measurement from that point. from that point. Alarm ON/OFF setting ( Arrow in- dicates that an alarm is generated when the number exceeds the set value.) Sets the limiter voltage...
  • Page 152: Sensor List

    TELEMETRY MENU Sensor list This menu registers the telemetry sensors used with the transmitter. When only one of a certain type of sensor is used, this setting is unnecessary, and the sensor can be used by directly connecting it to the S.BUS2 port of the transmitter. When using two or more of the same kind of sensors, they must be registered here.
  • Page 153 TELEMETRY MENU How to change start slot and set empty slot (Start slot selection) Start slot selection Select the [Slot] with the jog key and press, the list of sen- - Select with jog key and press sors that can be registered in the start slot, will be displayed. Sensors that cannot be changed are not displayed. (Sensor selection) Sensor selection From the sensor list, press jog key the sensor you want to...
  • Page 154: Sensor

    TELEMETRY MENU Sensor With this menu, you can display the telemetry meter on the home screen. Also, you can register a telemetry sensor in the transmitter. When using each sensor of the initial setting one by one, setting here is unnecessary. You can use it by connecting the purchased sensor to the S.BUS 2 port of the receiver.
  • Page 155: Sensor Reload

    The ID of each sensor is registered in the transmitter. To load the sensor, connect all sensors to be used to the T6PV communication port, as shown below. Also, to clear all sensor registration, execute this [Reload] function without connecting the sensor.
  • Page 156: Sensor Register

    Connecting S.BUS/S.BUS2 servo connector to the T6PV. microSD Sensor (The battery is not necessary) * I f t h e b a t t e r y s e t t i n g i s (4 d r y batteries), power supply is not possible.
  • Page 157: Change Slot

    TELEMETRY MENU Change Slot This procedure changes the slot number of the one registered sensor. Connect the sen- This function is set when using multiple telemetry sensors of the same type. Sensor slot change (Change) tion screen will be displayed. To execute, Select the [Yes] to hear an electronic sound and and the current sensor information is displayed.
  • Page 158: Logging Interval

    TELEMETRY MENU Logging interval This function sets the interval for recording log data. Logging interval change Select [Logging Interval] with the jog key and with the cursor on the setting value, press the [+] or [-] button to set the time. Adjustment buttons - Adjust with the [+] or [-] button. - Return to the initial value by press the [+] and [-] button simultaneously Range...
  • Page 159: Accessory Menu

    ACCESSORY  MENU Timer  It allows you to select between one of four timers. Up timer, fuel down timer, lap timer, and lap navigate timer. Up timer function - The Up timer can be used to count the time between the start and stop, etc. - The timer repeatedly starts and stops each time the switch is operated and accumulates the time between each start and stop.
  • Page 160 ACCESSORY  MENU Lap timer function Lap timer function - The lap timer can memorize each lap time of each switch operation. (200 laps) - The race time can be set. Switch operation after the set time my alarm has elapsed automatically stops the timer. Pre- alarm can also be set.
  • Page 161 ACCESSORY  MENU How to set the timer Home screen Menu screen Linkage menu 1 Linkage menu 2 Switch select Jog Key ■ Example of starting a timer with SW3 Ex. SW3 start/stop the  timer To reset the timer with a  SW3 setting  switch, follow the same  complete! procedure and assign  Select Switch Go to page 5 “Timer Reset” to the  desired switch. Timer type selection (Timer type selection) Use the jog key to move the cursor to “Mode” and press it. A Setting type - Select with the jog list of timer types will be displayed, so use the jog key to se-...
  • Page 162: Using The Up Timer

    ACCESSORY  MENU Using the Up timer (Preparation) Select the "Up timer" from the timer type list and press jog key. Alarm time  (Alarm time setting) OFF, 1~99-minutes Initial value: 5-minutes Select the value with jog key of the - Adjust with the [+] or [-] button. "Alarm time".
  • Page 163: Using The Fuel Down Timer

    ACCESSORY  MENU Using the fuel down timer (Preparation) Select the "Fuel down timer" from the timer type list and press jog key. Alarm time  (Alarm time setting) OFF, 1~99-minutes Select the value with jog key of the Initial value: 5-minutes - Adjust with the [+] or [-] button. "Alarm time".
  • Page 164: Using The Lap Timer

    ACCESSORY  MENU Using the lap timer (Preparation) Select the "Up timer" from the timer type list and press jog key. Alarm time  (Alarm time setting) OFF, 1~99-minutes Initial value: 5-minutes Select the value with jog key of the - Adjust with the [+] or [-] button. "Alarm time".
  • Page 165: Using The Lap Navigate Timer

    ACCESSORY  MENU Using the lap navigate timer (Preparation) Select the "Lap navigate timer" from the timer type list and press jog key. Alarm time  OFF, 1~99-minutes Initial value: 5-minutes (Alarm time setting) - Adjust with the [+] or [-] button. Select the value with jog key of the - Return to the initial value by press the [+] or [-] button simultaneously "Alarm time".
  • Page 166: Lap List

    ACCESSORY  MENU (Timer reset operation) With the timer stopped, press the switch Timer reset (timer reset) set by the Switch select - Select with jog key and press function, or Use the jog key to select [Reset] and press it. The timer is reset with a beeping sound.
  • Page 167: S.bus Servo

    -A power supply is not required only if the T6PV battery type is other than dry 4-cell and the HV servo is used. Since an overvoltage will be applied to servos other than this, con- nect the corresponding battery to the servo.
  • Page 168 (Preparation) - Connect S.BUS or S.BUS2 servo with reference to the above connection diagram. - If the T6PV battery type is a dry 4-cell battery, the servo battery will also be connected to the hub. - Be sure to use the wired method when changing the setting of UR/SR mode. Mode cannot be changed with the wireless setting.
  • Page 169 -"Reading succeeded" is displayed on the screen, and the ser- - If "Failed" is displayed on the screen, communication with the servo is not being performed normally. - Check the T6PV and servo connection or receiver and servo connection to servo and repeat [Read]. (Check receiver power supply etc.)
  • Page 170 If "Failed" is displayed, com- munication with the servo is not performed usually. Check the connection between the T6PV and the servo, and then The type of servo and execute the [Write] operation again.
  • Page 171 ACCESSORY  MENU UR mode setting (Wired only) The T6PV F-4G system provides the fastest response when used in combination with the Futaba UR Servo. Follow the steps below to switch the settings. UR mode can only be used with F-4G systems. Procedure for changing T6PV settings It is necessary to relink and restart the receiver power supply after changing the settings.
  • Page 172: Receiver Mode Precautions

    Bring the transmitter and receiver within 50 cm of each other (antennas do not touch) and turn on the receiver power. Touch [Link] on the transmitter T6PV screen, you will hear a chime sound and T6PV will enter the link mode for 20 seconds.
  • Page 173: Ur Servo Setting Change Procedure

    UR type 4 Connect the UR servo as shown. Communication port microSD microSD A power supply is not required only if UR servo the T6PV battery type is other than ● When changing the UR / SR mode  dry 4-cell and the settings, be sure to use the wired  HV servo is used. Servo battery method. Cannot change the servo ...
  • Page 174 ACCESSORY  MENU HOME screen Menu Accessory menu S.Bus servo Jog Key Read the connected UR servo data into the T6PV. The data of the  connected servo is  displayed.  Select [Close] Select  [Communication  Select [Read] Read the warning and  port] Select the [Continue]  Change to UR mode, select UR type, and write data to the connected UR servo.
  • Page 175: S.bus Function Setup

    ACCESSORY  MENU S.BUS function setup Select [value] with the jog key, and set the value with the [+] or [-] button when it is displayed in blue. In the case of multiple se- lection (if the item does not have a frame), select the item with the jog key and a pop-up screen will appear, so select it with the jog key and press it.
  • Page 176 ACCESSORY  MENU Stretcher The servo hold characteristic can be set. The torque which attempts to return the servo to the target position when the current servo position has deviated from the target position can be adjusted. This is used when stopping hunting, etc., but the holding characteristic changes as shown below. [Relationship between stretcher and servo operation] Small - Servo holding force becomes weaker.
  • Page 177: Mc (Esc) Link

    ACCESSORY  MENU MC (ESC) Link This function allows you to change the data of Futaba MC971CR and Acuvance Xarvis on the T6PV unit. This function is used by connecting ESC directly to the transmitter. Use the various optional servo extension cords according to the distance between the transmitter and ESC.
  • Page 178 ACCESSORY  MENU ● Connect the battery to the ESC. The MC (ESC) Link screen can be displayed in the following way. Home Menu Accessory MC(ESC)-Link Jog Key It is compatible with Acuvance Xarvis/ XarvisXX. For details on the functions, please contact Acuvance Corporation. Return to table of contents...
  • Page 179         If  “Reading  failed”  is  displayed,  communication  with  the  ESC  is  not  working  properly.  Check  the  connection  between  the  T6PV  and  the  ESC,  the  battery  connection  to  the  ESC,  and  the  power  switch  of  the  ESC,  then ...
  • Page 180 ●The  screen  will  display  “Writing  succeeded”  and  the  setting  data  will  be  written  to  the  ESC.  If  the  screen  displays  “Writing  failed” ,  communication  with  the  ESC  is  not  working  properly. Check the connection between the  T6PV  and  the  ESC,  the  battery  connection  to the ESC, and the power switch of the ESC,  then perform the [Write] operation again. Data list Use the Jog Key to select the setting item [Data List] and press it to display the loaded ...
  • Page 181 ACCESSORY  MENU Setting each data Use  the  Jog  Key  to  select  each  value  in  the  [Data  list],  and  when the value is displayed in blue, press the + or - button to  set it. *Drive frequency(kHz)   ・1 〜 16kHz(1kHz Step) & 16 〜 32kHz(2kHz Step) & 35・38・42・55・64kHz Adjust Acceleration. Lower Number (Acceleration : increase / Smoothness : Decrease) Higher Number (Acceleration : Decrease / Smoothness : Increase) *...
  • Page 182 ACCESSORY  MENU * Full brake power (%) ・0 〜 100% (2% step) Select the maximum brake power when applying full brakes during a run. Lower Number : Soft Breaking, Higher Number : Strong Breaking. * Max forward speed (%) ・50 〜 100% (2% step) Function that limit the maximum speed at full throttle. *...
  • Page 183 ACCESSORY  MENU * Full turbo timing (deg.) ・0 〜 60deg. (1deg. step) It is the additional timing added to the Boost timing. * Turbo start rotation speed (rpm) ・10,000 〜 50,000rpm (500rpm step) It is the motor RPM value at which the turbo function starts. “RPM “ or “Full Throttle & RPM” *...
  • Page 184 ACCESSORY  MENU *Operation mode  1. N/F/B Normal/Forward/Brake     2. N/F/B/R Normal/Forward/Brake/Reverse  3. N/F/R Normal/Forward/Reverse  4. R/F/B Reverse/Forward/Brake  5. R/F/B/R Reverse/Forward/Brake/Reverse  6. R/F/R Reverse/Forward/Reverse There are six operation modes. *Cutoff voltage (V) ・NONE,  2.6 〜 3.6V/cell (0.1V/cell step) When the battery voltage drops to the set value, the vehicle will slow down to notify the driver that the battery voltage is low, and prevent the receiver from going into a no-control state. If you are using a battery that is sensitive to over-discharge, you can prevent battery damage by setting the voltage higher than the battery damage voltage (varies depending on the battery).
  • Page 185 ACCESSORY  MENU * Torque level ・-5 〜 0 〜 +5 A setting of 0 is the normal state. The higher the value, the more torque- like acceleration and gentler deceleration will be achieved, and the lower the value, the more gentle the acceleration and suddener the deceleration will be. *...
  • Page 186 ACCESSORY  MENU MC/Acuvance (Telemetry sensor registration) MC/Acuvance  can  display  the  following  data  via  telemetry,  and  the  RPM  can  also  be  displayed on the MC Link parameter setting screen. ● Rotational speed  ● Internal ESC temperature  ● Motor temperature *  ● Battery voltage The  motors  that  support  the  motor  temperature  measurement  function  are  the  “LUXON  AGILE”  series  manufactured by Accuvance Co., Ltd. If any other motor is connected, motor temperature measurement is not  guaranteed. ● To  display  telemetry,  set  the  ESC  to  [MC  Link  Mode].  It  cannot  be  displayed  in  [ESC  Mode].
  • Page 187 ACCESSORY  MENU Using the sensor registration function  (to automatically register in an empty slot on the transmitter) Connect only the SBM-1 to the communication port of the transmitter. Display  the  Telemetry  menu  →  Sensor  menu  screen.    On  the  Sensor  menu  screen,  select [Sensor Registration].  The ESC slot number will be automatically set and [MC/ Acuvance] will be displayed on the Telemetry screen. Telemetry Screen Once  the  ESC  is  registered  as  a  telemetry  sensor,  you  can  set  limits  and  alarms  in  the  same  way  as  other  temperature  sensors, RPM sensors, etc.
  • Page 188: Gyro Link

    ACCESSORY  MENU Gyro link The Gyro Link is a function that allows you to set the parameters of the car gyro wire- lessly from the transmitter. *A gyro compatible with the wireless setting :  GYD550 (As of Jan. 2025) - The S.BUS servo data can be set wirelessly from the transmitter via the gyro. *A receiver compatible with the wireless setting function is required.
  • Page 189 ACCESSORY  MENU (Gyro read) When you open the Gyro Link screen from the Accessory menu, the connection method selection screen is displayed. Press jog key the button according to the connection method between the gyro and the receiver. The Gyro type and currently set contents are read. CH1 connection S.BUS connection S.BUS/S.BUS2 port...
  • Page 190: Data Settings

    ACCESSORY  MENU Display data list The gyro setting data is divided into the Basic setting and Gyro data (1 to 5) screens and displayed by the method shown on the right. - When the S.BUS connection is not used, the gyro data switching function cannot be used, so only [Gyro data 1] is displayed.
  • Page 191 ACCESSORY  MENU Gyro data   1/2   2/2 The gyro data setting screen has two pages, use the jog key left and right to turn the pages. Also, data can be set independently in each gyro operation mode (NORMAL / AVCS). AVCS and normal mode change button The AVCS / NORMAL modes setting. The gyro has 2 operating modes: NORMAL mode and AVCS mode.
  • Page 192: Gyro Data Switching Function

    ACCESSORY  MENU Gyro data switching function Gyro data can be switched with the push switch or trim lever/dial of the transmitter. (Up to 5 gyro data) - Connect the gyro to the S.BUS2 terminal of the receiver. - The gyro mixing function must be enabled. When switching with the push switch Gyro mixing screen Channel select screen...
  • Page 193: Roll Out Chart

    ACCESSORY  MENU Roll out chart This function is designed for pan cars. The roll out chart can be calculated from input values for the number of teeth of the spur gear and pinion gear, and the tire diameter, and displayed as a table. Menu screen Accessory menu screen Roll out chart...
  • Page 194: Gear Ratio Chart

    ACCESSORY  MENU Gear ratio chart The Gear Ratio Chart can be calculated from input values for the number of teeth of the spur gear and pinion gear and second gear ratio and displayed as a table. Menu screen Accessory menu screen Gear ratio chart Home screen Setup item ...
  • Page 195: End/Dir Button Setting

    ACCESSORY  MENU END/DIR  button setting The END/DIR button can be used to call up the desired screen from the home screen. END/DIR button Home Menu Accessory menu 1 Accessory menu 2 setting screen Jog Key END/DIR button call settings You  can  select  the  display  of  a  specific  function  screen.  S e l e c t  ...
  • Page 196: Home Screen Setting

    ACCESSORY  MENU Home screen setting You can choose to display the home screen. ● Normal ● Servo view ● Timer ● Instrument panel Home screen Menu screen Accessory menu 1 Accessory menu 2 Home screen setting Jog Key How to set the home screen display Use the jog key to move the cursor to [Mode]. Press the [+] or [-] button to change it. ●...
  • Page 197 ACCESSORY  MENU Instrument panel selection Select [Instrumental Panel] in the home screen display settings. Use the jog key to move the cursor to [Mode] and use the [+] or [-] button to select [Instrumental Panel]. Home screen setting The  display  can  be  turned  ON/OFF  for  each meter.
  • Page 198: User Menu Setting

    ACCESSORY  MENU User menu setting You can create your own functions for frequently used functions. The custom menu editing screen can be displayed in the following way. Home screen Menu screen Accessory menu 1 Accessory menu 2 User menu setting Jog key Example of setting the first line Select the line you w a n t t o c h a n g e w i t h t h e j o g k e y and press it.
  • Page 199: Real Time Ics Miniz

    ACCESSORY  MENU REAL TIME ICS MiniZ REAL TIME ICS MiniZ setting *This function is limited to when the system is MINI-Z EVO2 and [Bi-Dir] is ON. When the telemetry function of the Kyosho MINI-Z EVO2 is turned on, it is possible to change the parameters of the MR-04 chassis. Set the transmitter “PWR” side power switch to ON. From the Home screen, operates the jog key. Next, select [REAL TIME ICS MiniZ] at the Accessory menu page 2 and access the setup screen shown below by press the jog key.
  • Page 200 ACCESSORY  MENU Use the jog key to place the cursor on [Steering] and press it to set steering parameters from the transmitter. ST Power:L  (Setting of holding characteristics near neutral)1 〜 5 ST Power:H(Setting of retention characteristics for ranges other than power low)1 〜 5 ST Speed   (Maximum steering speed setting)  Slow、2〜 4、Fast Punch         (Initial response settings)   1 〜 20 Neutral          (Neutral zone settings)    0 〜 10 Damping   (Brake characteristic setting)Over、Middle、Smooth Use the jog key to select the setting value for each item and set it with the [+] or [-] button. Setting with the [+] or [-] button is immediately reflected on the car. Use the jog key to place the cursor on [Throttle] and press it to set throttle parameters from the transmitter. Throttle 1 page When you touch the No Backwheel and Brushless items, a confirmation screen will appear.
  • Page 201: Warning Displays

    If the battery goes dead while in operation, you will lose control.  Power off forgotten alarm At T6PV initialization, if steering wheel, throttle trigger, push switch, HOME button, or other operation is not performed within 10 minutes, an audible alarm will sound and the message " " will appear. If steering wheel, throttle trigger, push switch, HOME button or other operation is performed, the alarm is reset.
  • Page 202: Warranty & Repair Service (In U.s.a.)

    WARRANTY & REPAIR service (IN U.S.A.)  Technical updates and additional programming examples can be found at: www.futabausa.com (Information needed for repair) tact the Futaba Service Center at the e-mail address, fax or telephone number listed below: Phone:1-256-461-9399, FAX:1-256-461-1059 E-Mail: contactus@futaba.com If you are unable to resolve the issue, pack the system in its original container with a note en- •...
  • Page 203 Return to table of contents...

Table of Contents

Save PDF
