STEP 2
Estimated Time: 5 minutes
2a
Insert double ended connecting rods into the large stabilizer (C12) and tighten cam.
2b
Insert wooden dowels into the large stabilizer (C12).
2c
Slide the left small stabilizer (C13) onto the other end of the double ended connecting rod and tighten the cam.
2d
Repeat for the right small stabilizer (C14).
Tightening Cams
Unlocked
Locked
Turn 210°
Large Stabilizer
C12
Double End
Connecting Rod
2a
2b
Right Small
2d
Stabilizer
C14
Left Small
Stabilizer
2c
C13
Wood Dowel
