IMAQ A8020 Camera Cable
™
Installation Guide
Note
Refer to the JAI Web site and documentation for information about the functionality
of these cameras.
Getting Started
Camera Advisor™, IMAQ™, National Instruments™, NI™, ni.com™, and NI-IMAQ™ are trademarks of
National Instruments Corporation. Product and company names mentioned herein are trademarks or trade names of
their respective companies. For patents covering National Instruments products, refer to the appropriate location:
Help»Patents in your software, the patents.txt file on your CD, or ni.com/patents.
ni.com
© 2003 National Instruments Corp. All rights reserved.
This guide describes how to use the National Instruments IMAQ A8020
analog camera cable to connect the PXI/PCI-1409 image acquisition
(IMAQ) device to a camera.
The IMAQ A8020 cable provides direct connection between the
IMAQ 1409 device and the camera without using a breakout box. Use
the IMAQ A8020 cable with the following JAI cameras:
•
JAI CV-M1
•
JAI CV-M10
•
JAI CV-M50
The following items are necessary for connecting the IMAQ A8020 cable:
❑
IMAQ A8020 cable
❑
IMAQ A8020 Camera Cable Installation Guide
❑
IMAQ 1409 device and documentation
❑
Camera and documentation
April 2003
323485A-01
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for National Instruments IMAQ A8020
Summary of Contents for National Instruments IMAQ A8020
- Page 1 Camera Advisor™, IMAQ™, National Instruments™, NI™, ni.com™, and NI-IMAQ™ are trademarks of April 2003 National Instruments Corporation. Product and company names mentioned herein are trademarks or trade names of 323485A-01 their respective companies. For patents covering National Instruments products, refer to the appropriate location: Help»Patents in your software, the patents.txt file on your CD, or ni.com/patents.
- Page 2 Connecting the IMAQ A8020 Cable Complete the following steps to connect the IMAQ A8020 cable to the IMAQ 1409 device and camera. Refer to Figure 1 for an illustration of the connectors on the IMAQ A8020 cable. Connect the 68-pin male VHDCI connector to the connector on the IMAQ 1409 device and tighten the thumbscrews.
- Page 3 12-pin and 6-pin Hirose connectors provide connection to the camera. Figures 2 and 3 show the pinouts for these connectors. Figure 2. 68-Pin VHDCI Connector (Cable) Figure 3. Hirose Connectors (Cable) © National Instruments Corporation IMAQ A8020 Camera Cable...
- Page 4 The IMAQ 1409 can then be programmed to generate precise timing pulses for controlling the camera. Visit the National Instruments Camera Advisor Web site at ni.com/camera application notes and sample code for many of the cameras the IMAQ A8020 supports. *323485A-01* 323485A-01 Apr03...
