National Instruments IMAQ SCB-100 Installation Manual

INSTALLATION GUIDE
IMAQ SCB-100 C
IMAQ D100100 C
Warning Use the D100100 cable with IMAQ digital devices only. Also, do not use data
acquisition (DAQ) cables with IMAQ digital devices. Using the D100100 cable
with other devices or DAQ cables with IMAQ digital devices may result in damages
to your device or your computer. National Instruments is
damages or injuries resulting from improper use or connection.
Introduction
What You Need to Get Started
IMAQ ™ is a trademark of National Instruments Corporation. Product and company names mentioned herein are trademarks or trade names of their
respective companies.
321950B-01 © Copyright 1998, 1999 National Instruments Corp. All rights reserved.
ONNECTOR
ABLE
This guide describes how to connect and use the IMAQ SCB-100 100-pin
shielded connector block with 100-pin digital image acquisition (IMAQ)
products and the IMAQ D100100 cable.
The IMAQ SCB-100 100-pin shielded connector block is a shielded board
with 100 screw terminals that connects to the IMAQ PCI-1424 or other
products using a 0.050 series shielded D-type I/O connector.
The terminal block has 100 screw terminals for easy connection to signal
wires. When you use the IMAQ SCB-100 100-pin shielded connector block
with the IMAQ PCI-1424, set the switches as shown in the Switch Settings
section to obtain a generic 100-screw terminal connector block. The IMAQ
SCB-100 also has a strain-relief bar for securing signal wires or cables.
To install your IMAQ D100100 cable, you will need the following:
IMAQ SCB-100 100-pin shielded connector block
IMAQ D100100 cable
IMAQ SCB-100 Connector Block and IMAQ D100100 Cable
Installation Guide
B
LOCK AND
liable for any
NOT
January 1999
