INSTALLATION INSTRUCTIONS

NI TB-2676

Introduction

Caution

Ensure that power has not been applied to signals prior to connection. Only

trained and qualified service personnel should install and connect signals.

This guide describes how to install and connect signals to the

National Instruments TB-2676 terminal block. Use the ribbon cable

headers of the NI TB-2676 to access all channels of the NI PXI-2576

multiplexer for all configurations.

Refer to the NI Switches Getting Started Guide to determine when to install

the NI TB-2676.

To set up and use the NI TB-2676 terminal block, make sure you have the

following items:

❑

NI TB-2676 terminal block

❑

NI PXI-2576 switch module

❑

1/8 in. flathead screwdriver

❑

#1 Phillips screwdriver

❑

Eight 0.100 in. pitch 2 × 10 ribbon cable assemblies, or wire wrap

cable and tools

To connect signals to the terminal block, refer to Figure 1 and complete the

following steps:

Remove the terminal block top cover screw.

Gently lift the top cover off the terminal block.
