Silicon Laboratories Si5 UC-EVB Series Manual page 14

SiLabs Type # Freqs
Device
Si565 VCXO Single
Si566 VCXO Dual
Si567 VCXO Quad
Si569 VCXO Single/
Dual (or
2
I C)
Si550 VCXO Single
Si552 VCXO Dual
Si554 VCXO Quad
Si595 VCXO Single
Si596 VCXO Dual
Si597 VCXO Quad
Si515 VCXO Single
(CMOS)
Si515 VCXO Single
(Diff)
Si516 VCXO Dual
(CMOS)
Si516 VCXO Dual (Diff) 6
silabs.com | Building a more connected world.
Table 6.2. Pin Controlled VCXOs
# pins Pkg sizes Pin 1
(mm x mm) Control
6 5x7, 3.2x5 Vc
6 5x7, 3.2x5 Vc
8 5x7, 3.2x5 Vc
8 5x7, 3.2x5 Vc
6 5x7 Vc
6 5x7 Vc
8 5x7 Vc
6 5x7, 3.2x5 Vc
6 5x7, 3.2x5 Vc
8 5x7 Vc
6 5x7, 3.2x5, Vc
2.5x3.2
6 5x7, 3.2x5, Vc
2.5x3.2
6 5x7, 3.2x5, Vc
2.5x3.2
5x7, 3.2x5, Vc
2.5x3.2
Supported Devices - Stand-Alone Mode
Pin 2 Pin 7 Pin 8
Control Control Control
OE - -
FS - -
OE FS1 FS0
OE/FS SDA SCL
OE - -
FS - -
OE FS1 FS0
OE - -
FS - -
OE FS1 FS0
OE - -
OE - -
FS - -
FS - -
UG298: Si5xxUC-EVB
Pin 4 Out- Pin 5 Out-
put put
CLK+ CLK-
CLK+ CLK-
CLK+ CLK-
CLK+ CLK-
CLK+ CLK-
CLK+ CLK-
CLK+ CLK-
CLK+ CLK-
CLK+ CLK-
CLK+ CLK-
CLK NC
CLK+ CLK-
CLK NC
CLK+ CLK-
Rev. 0.3 | 14
