Cylinders - Danfoss Maneurop NTZ Series Selection & Application Manuallines

OUTLINE DRAWINGS

4 cylinders

519
115
158
232
202
15
NTZ215
NTZ271
ø 352
Oil equalisation
3/8" (VE version only)
Threaded oil
sight glass
Mounting hole for PTC
crankcase heater
15
205
246
Rotolock connections size
Suction Discharge
1"3/4 1"1/4
Suction rotolock
1"3/4
Discharge rotolock
1"1/4
233
125
99
Silent block
246
15
Pipe sizing
Suction Discharge
1"1/8" 3/4"
Schrader
1/4"
96
HM12-50
Rotolock valve
Suction
V02
95
30
19
Discharge
V04
9
