LOCKING CAR AND TRACK SYSTEM
Installation and Use Guidelines – Intended for specialized personnel or expert users
Locking car
C13807 shown
WARNING! Strictly follow all instructions to avoid potential
hazards that may kill or hurt you and others. See www.harken.com/
manuals for general warnings and instructions.
Please read these instructions carefully before installing, servicing, or operating the equipment.
This manual may be modified without notice. See: www.harken.com/manuals for updated versions.
Switch Battcar 32 mm
Lock track C14526 shown
PLEASE SAVE THESE INSTRUCTIONS
Headboard plate - C9250 Shown
IMPORTANT! Use only Harken
approved headboard plate.
5271 03-19
Advertisement
Related Manuals for Harken C14526
Summary of Contents for Harken C14526
- Page 1 See www.harken.com/ manuals for general warnings and instructions. Please read these instructions carefully before installing, servicing, or operating the equipment. This manual may be modified without notice. See: www.harken.com/manuals for updated versions. PLEASE SAVE THESE INSTRUCTIONS...
-
Page 2: How It Works
How it works General description - Locking mechanism - Locking headboard system consists of locking car, lock track and headboard plate. The car has multiple pawls that lock into pockets in the lock track. Return springs keep the pawls retracted into the car for hoisting and lowering. Once the sail is hoisted to the correct height, pulling the trip line moves the control link, leveraging the pawls' control arms simultaneously engaging the pawls into the lock track pockets. - Page 3 Alternatively use marks on the halyard. Magnet Note: The sensor magnet is supplied by Harken. The proximity sensor is not supplied. Locking Headboard Assembly...
- Page 4 Installation guidelines Installation - Trip line 1. Trip line runs in sleeve in the sail luff. Choose Dyneema uncovered 12 strand core for the trip line so that is ® slides easily in the sleeve. 2. In the lower portion, just above the reef tack fittings, provide 1 to 1 1/2 m (3' to 5') gaps in the sleeve for access to the trip line.
- Page 5 Using the system Headboard plate pivot pin lock - The pivot pin locks to the car using two retractable spring plungers. Use a small strap, zip tie or line to get under and lift the arm. Rotate the arm to lock it out. The pivot pin can then be removed.
-
Page 6: Parts List
Parts List C13807 Locking Car - Replaceable components Part # 1 Plunger H-78344 2 Pivot pin H-78333 3 Trigger body fastener - M5X10 A4 SS FLAT SHCS HFS946 4 Retractable spring plunger HCP2148 5 Trigger body H-78338 6 Pawl pivot pin H-78334 7 Pawl return spring HCP2174... - Page 7 Parts List C14084 8T Locking Car - Replaceable components Part # 1 Plunger H-78344 2 Pivot pin H-78964 3 Trigger body fastener - M5X10 A4 SS FLAT SHCS HFS946 4 Retractable spring plunger HCP2148 5 Trigger body H-78965 6 Pawl pivot pin H-78334 7 Pawl return spring HCP2174...
-
Page 8: Maintenance
Maintenance IMPORTANT! - All parts must be inspected, cleaned and serviced regularly. Servicing locking mechanism Use 3 mm hex key to remove four screws holding trigger body assembly in place. Lift trigger body assembly. Trigger body assembly Push pivot pin out of main body and remove pawl from the underside. - Page 9 Maintenance After cleaning parts, put a small amount of grease in the spring sockets. Lightly grease entire pawl pivot pin. Grease holds springs in place. Lightly grease pivot pins. Clean and inspect all trigger body assembly. Lightly grease Be sure to inspect knots on end of trip line. pawl arms.
- Page 10 See image below. Raised boss Servicing bushings in headboard plate. IMPORTANT! Use only Harken approved headboard plate. Bushings in headboard plate must be inspected and in good working condition. Replace if there is any visible wear.
-
Page 11: Troubleshooting
Troubleshooting Troubleshooting Locking car will not release - Make sure: 1. Trip line is eased. Make sure it is not caught on anything. 2. Halyard is tensioned to counter the weight of the sail. If the tip line does not have tension and pawls will not release, remove four screws securing trigger body to the car. - Page 12 Main Office and Harken Brandstore: Västmannagatan 81B SE-113 26 Stockholm Sweden Telephone: (46) 0303 61875 • Fax: (46) 0303 61876 Mailing address: Harken Sweden AB, Box 64, SE -440 30 Marstrand Web: harken.se • Email: harken@harken.se Harken UK, Ltd. Bearing House, Ampress Lane, Lymington, Hampshire S041 8LW, England Telephone: (44) 01590-689122 •...
