8685/8686 Portable Dock Box
Assembly Instructions
PARTS
8685 Portable Dock Box (38" x 23" x 18")
QTY
Description
4
1/4" x 28" Round Battens
4
1/4" x 38" Round Battens
8
Black Webbing Corner Sleeves
PARTS
8686 Portable Dock Box (66" x 23" x 18")
4
1/4" x 28" Round Battens
4
1/4" x 66" Round Battens
8
Black Webbing Corner Sleeves
2
18" Black Webbing Center Battens
5025 11-13
