Ademco Contact ID Format

If 'E' is entered for address 42, the following data is automatically programmed for the Secondary

phone number event codes.

Address

Description

139 - 141

Secondary # General Alarm Code

142 - 144

Secondary # Zone/Point Alarm Code

145 - 147

Secondary # General Supervisory Code

148 - 150

Secondary # Zone/Point Supervisory Code

151 - 153

Secondary # General Fault Code

154 - 156

Secondary # AC Fault Code

157 - 159

Secondary # Zone/Point Fault Code

160 - 162

Secondary # Low Battery Fault Code

163 - 165

Secondary # Telco Primary Line Fault Code

166 - 168

Secondary # Telco Secondary Line Fault Code

169 - 171

Secondary # NAC Fault Code

172 - 174

Secondary # Comm. Trouble Primary # Code

175 - 177

Secondary # Comm. Trouble Secondary # Code

178 - 180

Secondary # 485 Comm. Trouble Code

181 - 183

Secondary # System Off Normal Code

184 - 186

Secondary # ADT-UDACT Off Normal Code

187 - 189

Secondary # System 24 Hour Test

190 - 192

Secondary # System 24 Hour Test w/active event 608

193 - 195

Secondary # Manual Test Message

Notes:

1) Note: Zero entries prevent the transmission of the report to the Central Station.

2) Refer to Contact ID program locations 64 - 68.

3) The identification of the zone/device number is automatically transmitted by the ADT-UDACT and is

added to the main event code. See Table 5-3 for more information.

4) For control panels Unimode 2020/1010, ADT-MNNA, and Unimode 300/400 the factory default event

code is 110 and reprogrammable. The Unimode 300 and Unimode 400 are unique in point reporting

mode in that only the control module report codes are programmable. The factory setting of report

code 111 is fixed for addressable smoke detectors and cannot be changed.

5) The Group # is automatically incremented for Unimode 2020/1010 and ADT-MNNA applications.
