Safety – Operation – Maintenance
Keep this document in a safe place
Read and understand this manual before operating your vacuum
Warthog WGP
Industrial Vacuum 120V / 220V with Pneumatic Tool Sync
Models with Prefix: WGP-115G-0, WGP-205G-0, WGP-215G-0
• Designed for general cleanup, housekeeping, vacuum sanding
• Dry Recovery Only
Scan this QR code for
online instructions and
documentation, or visit
www.ClaytonHowTo.com
WARNING
SAFETY LEGEND
Read and understand operator's manual before
using this equipment.
Hearing protection is recommended when
operating this equipment.
WARNING
• A HEPA Filter must be installed in this vacuum at all times
• If this vacuum is used to collect hazardous material, appropriate personal protective equipment may be required
• Any alteration to this equipment by a third party will nullify its warranty
WARNING
WARNING
WARNING
Eye protection is required when operating
this equipment.
WARNING
Respiratory protection is recommended when
operating this equipment.
October 2019
Advertisement
Table of Contents
Related Manuals for Clayton Warthog WGP Series
Summary of Contents for Clayton Warthog WGP Series
- Page 1 Safety – Operation – Maintenance Keep this document in a safe place Read and understand this manual before operating your vacuum Warthog WGP Industrial Vacuum 120V / 220V with Pneumatic Tool Sync Models with Prefix: WGP-115G-0, WGP-205G-0, WGP-215G-0 • Designed for general cleanup, housekeeping, vacuum sanding •...
-
Page 2: Important Safety Instructions
Figure 1: Earthed/Grounded Outlet and Plug configuration as the plug. No adaptor should be used with this appliance. • • • Repair or Warranty Contact Clayton Associates, Inc. 1650 Oak Street Lakewood, New Jersey 08701 P.+1-732-363-2100 F.+1-732-364-6084 • www.DustlessMadeSimple.com Sales@JClayton.com... -
Page 3: Table Of Contents
Do not use this equipment for cleaning or extracting live sparks or burning embers Do not use this equipment for use in combustible dust or gas atmospheres • • • Repair or Warranty Contact Clayton Associates, Inc. 1650 Oak Street Lakewood, New Jersey 08701 P.+1-732-363-2100 F.+1-732-364-6084 • www.DustlessMadeSimple.com Sales@JClayton.com... -
Page 4: What's Included
WHAT’S INCLUDED Clayton Warthog Power Heads ship with the following items: • Warthog WGP Power Head • HEPA 12 Month Timer Card Clayton Vacuum Tanks ship separately and include Bags, Filters, and other components. These instructions asume you have both a Power Head and one of... -
Page 5: Compressed Air Fittings
• Ensure the bottom of the collar is past the opening on the underside of the inlet tube 2. Unbox a new HEPA Filter • Remove the Clayton HEPA Timer Card from the box and set aside • Remove the HEPA Cable Lock from the box and set aside •... -
Page 6: Pneumatic Tool Sync
• Adjust the Shutoff Delay Valve until the pressure bleeds down as slow or as fast as required using the tool sync pressure gauge as a guide • • • Repair or Warranty Contact Clayton Associates, Inc. 1650 Oak Street Lakewood, New Jersey 08701 P.+1-732-363-2100 F.+1-732-364-6084 • www.DustlessMadeSimple.com Sales@JClayton.com... -
Page 7: Before Each Use
This vacuum is equipped with Manual Mode (ON Mode) which activates the vacuum when the switch is set to ON • Toggle the Power Switch to the ON Position • • • Repair or Warranty Contact Clayton Associates, Inc. 1650 Oak Street Lakewood, New Jersey 08701 P.+1-732-363-2100 F.+1-732-364-6084 • www.DustlessMadeSimple.com Sales@JClayton.com... -
Page 8: Bag Filter Change
• Rotate the Power Head so that the switch on the Power Head is in line with the inlet port on the vacuum tank • Latch the Power Head to the tank • • • Repair or Warranty Contact Clayton Associates, Inc. 1650 Oak Street Lakewood, New Jersey 08701 P.+1-732-363-2100 F.+1-732-364-6084 • www.DustlessMadeSimple.com Sales@JClayton.com... -
Page 9: Pre-Filter Change
• Carefully sit the Power Head on the floor - avoid damaging the HEPA filter 3. Unbox a new HEPA Filter • Remove the Clayton HEPA Timer Card from the box and set aside • Remove the HEPA Cable Lock from the box and set aside •... -
Page 10: Illustrated Parts Breakdown
600-WF-1364F WASHER FIBER 13/64 ID X 3/8OD WIRING HARNESS REPRESENTATIVE ACTUAL HARNESS MAY DIFFER IN APPEARANCE • • • Repair or Warranty Contact Clayton Associates, Inc. 1650 Oak Street Lakewood, New Jersey 08701 P.+1-732-363-2100 F.+1-732-364-6084 • www.DustlessMadeSimple.com Sales@JClayton.com Page 10... - Page 11 WASHER .203ID X .500OD .047H ROUND STAINLESS STEEL WE481831-RZSZ SHIM .750 ID X 1.125 OD X .048 ROUND STAINLESS • • • Repair or Warranty Contact Clayton Associates, Inc. 1650 Oak Street Lakewood, New Jersey 08701 P.+1-732-363-2100 F.+1-732-364-6084 • www.DustlessMadeSimple.com Sales@JClayton.com...
- Page 12 ENCLOSURE FOAM 1 SOUND CONTROL 911-803-7 ENCLOSURE FOAM 2 SOUND CONTROL 911-803-8 ENCLOSURE FOAM 3 SOUND CONTROL • • • Repair or Warranty Contact Clayton Associates, Inc. 1650 Oak Street Lakewood, New Jersey 08701 P.+1-732-363-2100 F.+1-732-364-6084 • www.DustlessMadeSimple.com Sales@JClayton.com Page 12...
- Page 13 FTG ELBOW 1/2PC TO 1/4FNPT 927-08MA-04 1/2 PC X 1/4 MPT STRAIGHT FTG 927-08Y UNION Y, 1/2PC • • • Repair or Warranty Contact Clayton Associates, Inc. 1650 Oak Street Lakewood, New Jersey 08701 P.+1-732-363-2100 F.+1-732-364-6084 • www.DustlessMadeSimple.com Sales@JClayton.com Page 13...
-
Page 14: Limited Lifetime Warranty Terms And Conditions
Repair within the Continental US During the first 90 days of the warranty period, Clayton will provide parts and labor to the customer’s site at no charge or pay freight costs associated with returning the products for repair to a Clayton selected service location and repair the product at no charge. -
Page 15: Declaration Of Conformity
EC DECLARATION OF CONFORMITY Clayton Associates, Inc. of 1650 Oak Street, Lakewood New Jersey 08701 U.S.A. declare on our own responsibility that the following equipment: Industrial HEPA Filtered, Electrically Powered Vacuum Cleaners and Accessories for Dry Recovery • Vacuum Models (where XXXX is the Tank Model):... - Page 16 EC DECLARATION OF CONFORMITY Clayton Associates, Inc. of 1650 Oak Street, Lakewood New Jersey 08701 U.S.A. declare on our own responsibility that the following equipment: Industrial HEPA Filtered, Electrically Powered Vacuum Cleaners • Vacuum Models (where XXXX is the Tank Model):...
- Page 17 • • • Repair or Warranty Contact Clayton Associates, Inc. 1650 Oak Street Lakewood, New Jersey 08701 P.+1-732-363-2100 F.+1-732-364-6084 • www.DustlessMadeSimple.com Sales@JClayton.com...
- Page 18 Clayton products are proudly made in the USA • • • Repair or Warranty Contact Clayton Associates, Inc. 1650 Oak Street Lakewood, New Jersey 08701 P.+1-732-363-2100 F.+1-732-364-6084 • www.DustlessMadeSimple.com Sales@JClayton.com...
