Safety – Operation – Maintenance
Keep this document in a safe place
Read and understand this manual before operating your air tool
WartHog Vacuum Tank
Poly General Dust
Models: 603-105G, 603-107G, 603-115G
Scan this QR code for
online instructions and
documentation, or visit
www.ClaytonHowTo.com
WH-1xxG_cover_A
603-105G
WARNING
SAFETY LEGEND
Read and understand operator's manual before
using this equipment.
Hearing protection is recommended when
operating this equipment.
• A HEPA filter must be installed in this vacuum at all times.
• If this vacuum is used to collect hazardous material, personal protective equipment should be used when opening the vacuum or
emptying its contents.
• Any alteration to this equipment by a third party will nullify its warranty
WH-1xxG
WH-1xxG_cover_B
603-107G
WARNING
WARNING
WH-1xxG_cover_C
603-115G
WARNING
Eye protection is required when operating this
equipment.
WARNING
Respiratory protection is recommended
operating this equipment.
August 03, 2021
