Safety – Operation – Maintenance
Keep this document in a safe place
Read and understand this manual before operating your air tool
BACKPACK™ HEPA VACUUM SYSTEMS
Model: BP-125-0
Scan this QR code for
online instructions and
documentation, or visit
www.ClaytonHowTo.com
WARNING
SAFETY LEGEND
Read and understand operator's manual before
using this equipment.
Hearing protection is required when applicable
PEL (permissible exposure limit) is exceeded.
This manual is intended as a complete operations manual for owners and users of the Clayton Backpack™ Series HEPA Vacuums and equipment
packages which incorporate the Clayton Backpack™ Series HEPA Vacuums. Although this manual details maintenance and operation of Clayton
pneumatic tools in conjunction with the vacuum, these tools may be sold separately or as part of a kit. Pneumatic tools, hoses, or accessories are
available directly from Clayton Associates, Inc.
WARNING
WARNING
WARNING
Eye protection is required when operating
this equipment.
WARNING
Respiratory protection is required when
applicable PEL (permissible exposure limit)
is exceeded.
October 2019
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Clayton BACKPACK HEPA
Summary of Contents for Clayton BACKPACK HEPA
- Page 1 This manual is intended as a complete operations manual for owners and users of the Clayton Backpack™ Series HEPA Vacuums and equipment packages which incorporate the Clayton Backpack™ Series HEPA Vacuums. Although this manual details maintenance and operation of Clayton pneumatic tools in conjunction with the vacuum, these tools may be sold separately or as part of a kit.
-
Page 2: Table Of Contents
Important Safety Instructions ........................3 Save These Instructions ......................... 3 • Grounding Instructions ........................3 • Warnings Applicable To Hazardous Materials Clayton Vacuum Systems ........4 • Explanation of Hazardous Warning Symbols ................4 • Hazardous Materials Warning ....................... 5 •... -
Page 3: Important Safety Instructions
No adaptor should be used with this appliance. Figure 1: Grounded Outlet and Plug • • • Repair or Warranty Contact Clayton Associates, Inc. 1650 Oak Street Lakewood, New Jersey 08701 P.+1-732-363-2100 F.+1-732-364-6084 • www.DustlessMadeSimple.com Sales@JClayton.com... -
Page 4: Warnings Applicable To Hazardous Materials Clayton Vacuum Systems
SAVE THESE INSTRUCTIONS WARNINGS APPLICABLE TO HAZARDOUS MATERIALS CLAYTON VACUUM SYSTEMS 1. Warnings for hazardous materials listed in this manual are designed to warn personnel of hazards associated with such items when they come in contact with them by actual use. Additional information related to hazardous materials is provided in OPNA VINST 5100.23, Navy Occupational Safety and Health (NAVOSH) Program Manual, NAVSUPINTST 5100.27, Navy Hazardous Material Control Program,... -
Page 5: Hazardous Materials Warning
The Clayton Backpack HEPA Filtered Vacuums consist of a polyethylene tank and a base enclosure with an electric motor. The vacuums are mounted to an ergonomic backpack harness and can be used as a backpack vacuum or placed on a dry surface during use. -
Page 6: Preparation For Use
If an extension cord must be used, ensure that the cord is UL Listed, CSA Certified, 12AWG minimum, and approved for indoor/ outdoor usage. Backpack vacs are designed for use with a 1.5” Clayton cleanup hose. One end of the hose has a rubber cuff. Push this end over the vacuum inlet tube on the top of the vacuum tank. -
Page 7: Maintenance
Keep the unit away from moisture or harsh environments whenever possible. Store unit in a dry location. Never use the Clayton Backpack Vacuum for wet vacuuming. The system is designed to extract dry dust and debris, and is not equipped for fluid extraction. -
Page 8: Warranty
Within the continental U.S.: During the first 90 days of the warranty period, Clayton will at no charge to the customer, provide parts and labor at the customer’s site. From day 91 onward, Clayton will provide parts to the customer’s site at no charge and will perform labor at no charge for products returned to its factory at the customer’s expense. -
Page 9: Illustrated Parts Breakdown
Screw – Motor To Mounting Plate Plastic Washer For Well Nut Extension Cord Yellow Illuminated (50 ft. 16-3 SJTW 125V) • • • Repair or Warranty Contact Clayton Associates, Inc. 1650 Oak Street Lakewood, New Jersey 08701 P.+1-732-363-2100 F.+1-732-364-6084 • www.DustlessMadeSimple.com Sales@JClayton.com... - Page 10 Clayton products are proudly made in the USA • • • Repair or Warranty Contact Clayton Associates, Inc. 1650 Oak Street Lakewood, New Jersey 08701 P.+1-732-363-2100 F.+1-732-364-6084 • www.DustlessMadeSimple.com Sales@JClayton.com...
