Inclusion Not Successful (Self-Destruct)
Ring Alarm Contact Sensor – Exclusion
Removing Ring Alarm Contact Sensor from a Z-Wave Network
Exclusion Instructions:
1. Initiate remove "Ring Alarm Contact Sensor" flow in the Ring Alarm mobile application – Select the settings icon from device
details page and choose "Remove Device" to remove the device. This will place the controller into Remove or "Z-Wave
Exclusion" mode.
2. With the controller in Remove (Z-Wave Exclusion) mode, use a paper clip or similar object and tap the pinhole button. The
device's red LED turns on solid to indicate the device was removed from the network.
Ring Alarm Contact Sensor – Factory Reset
Factory Default Instructions
1. To restore Ring Alarm Contact Sensor to factory default settings, locate the pinhole reset button on the device. This is found
inside the battery compartment on the back of the device after removing the back bracket.
2. Using a paperclip or similar object, insert it into the pinhole, press and hold the button down for 10 seconds.
3. The device will rapidly blink green continuously for 10 seconds. After about 10 seconds, when the green blinking stops,
release the button. The red LED will turn on solid to indicate the device was removed from the network.
Note: Use this procedure only in the event that the network primary controller is missing or otherwise inoperable.
Wake-Up Notification
The sensor will wake up every so often to send a Wake-Up Notification to allow the life line master node controller that the sensor is
now available for any queued messages that the controller may have for the sensor. The time between Wake-Up Notifications can be
configured with the Wake-Up Notification command class according to the following configurable values:
• Min Value 1 hr
• Max Value 24 hr
• Default Value 12 hours (12 * 60 * 60 seconds)
• Wake Up Interval Step Seconds 1 hour (3600 seconds)
