Sensor Condition
Sensor Case Fastened
Comm Test Button Pressed
Watchdog Notification
Magnetic Tamper
Magnetic Tamper Clear
Software Fault (Ring)
Software Fault (SDK)
Pin Reset (soft reset)
Date:
Command Class and Value
Notification Report
Type: Home Security 0x07
State: Previous Events Cleared 0x00
Event Parameter: 0x03
Notification Report
Type: System 0x09
Event: Heartbeat 0x05
Notification Report
Type: System 0x09
State Value: 0x04 System Software Failure
State Parameter Value = 0x55
Notification Report
Type: Home Security 0x07
State: 0x0B (Magnetic field interference detected)
Notification Report
Type: Home Security 0x07
State: Previous Events Cleared 0x00
Event Parameter: 0x0B
Notification Report
Type: System 0x09
State Value: 0x04 System Software Failure
State Parameter Value = 0xAA (Ring Value for Soft Fault)
Notification Report
Type: System 0x09
State Value: 0x04 System Software Failure
State Parameter Value = 0xA9 (SDK Value for Soft Fault)
Notification Report
Ring Alarm Contact Sensor User Manual
Version: 0.1
Association Group
1 (Lifeline)
1 (Lifeline)
1 (Lifeline)
1 (Lifeline)
1 (Lifeline)
1 (Lifeline)
1 (Lifeline)
1 (Lifeline)
Page:
- 9 -
