H-System – Isolated Barriers and Termination Boards for HIMA
Technical Specifications
6.4.2
Housing Types Termination Boards
HiC Termination Boards for 16 Modules
Figure 6.3
HiC Termination Boards for 32 Modules
Figure 6.4
42
253 mm (9.96 inch)
163 mm (6.42 inch)
253 mm (9.96 inch)
163 mm (6.42 inch)
266 mm (10.47 inch)
432 mm (17 inch)
