H-System – Isolated Barriers and Termination Boards for HIMA
Installation
3.2.2 Isolated Barriers Mounting
Mounting the Isolated Barriers on the Termination Board
1. Push the Quick Lok bar (1) into the upper position.
2. Center the pins (2) above the contact elements of the termination board. Note
3. Center the locking pins (3) above the locking elements of the
4. Carefully push the device into the contacts and locking elements.
5. Push the red Quick Lok bar (1) down on either side of the device.
Figure 3.5
1
2
3
24
the connection direction of the device.
termination board.
The device is now mounted.
Mounting of an H-System isolated barrier
Quick Lok Bar
Coding pins
Adjustment pins
1
3
2
