Components
A
2 x Support Tube
B
3 x Glass Shelf
C
3 x Metal Bar
Fittings
4 x Screw
B
A
4 x Wall Plug
B
C
6 x Small Screw
D
4 x Plastic Plug
1 x Fixing Template
Wall Rack With Glass Shelves
Simple Assembly Instructions
IMPORTANT
1. Read these instructions carefully and
familiarise yourself with the procedure
before assembling the unit.
2. Check that you have all the component
parts following the list on the back
cover and familiarise yourself with
each part before proceeding.
-
Please keep for future reference
3. Take all the fittings out of the plastic bag
and separate them into their groups.
4. Ensure you have enough space to lay out
all the parts before assembly.
5. To avoid scratching it is recommended
that you assemble the unit on a soft
level surface.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Argos 832/2292
Summary of Contents for Argos 832/2292
- Page 1 Components Wall Rack With Glass Shelves 2 x Support Tube Simple Assembly Instructions Please keep for future reference 3 x Glass Shelf 4 x Plastic Plug 3 x Metal Bar Fittings IMPORTANT 4 x Screw 1 x Fixing Template 3. Take all the fittings out of the plastic bag 1.
- Page 2 Stage 1 – Stage 2 – Fitting the Support Tubes Fitting the Glass Shelves BS 7449:1991 IMPORTANT: Model / Catalogue Number: 832/2292 Retailer: ARG Retailer address: Keep these instruction for future 489-499 Avebury Boulevard, Saxon use. Gate West, Central Milton Keynes,...
- Page 3 Assembly Instructions Assembly Instructions Stage 3 – Stage 4 – Fitting the Plastic Plugs Finishing the Unit NOTE: The maximum safe load for each shelf is 3kg evenly distributed along the length of the shelf. WARNING: • Do not place very hot or very cold items on the glass surface(s) unless adequately thick tablemats are used to prevent such items from coming into...
